- Page 1 Operating Instructions Streamline Supplies 9 Joseph Baldwin Place, Shepparton Victoria 3630 Ph: 03 5831 5555 Fax: 03 5821 3633 w w w . s t r e a m l i n e s u p p l i e s . c o m . a u...
- Page 2 Introduction Please read this technical handbook carefully since it provides important information on the correct installation, use and maintenance. Keep this handbook in a safe place for further consultation. The Manufacturer is not responsible for any damage caused by incorrect or unreasonable use and maintenance. The Manufacturer accepts no responsibility for damage to persons or objects caused by incorrect installation.
- Page 3 Instructions for use This machine is designed for the sole purpose of producing coffee, hot water and steam for hot drinks. All other uses are incorrect and, therefore, dangerous. This machine is designed for professional use only. The machine components are made of nontoxic and long lasting parts which are easily accessed for cleaning and maintenance.
- Page 4 Espresso Coffee Machine Range Automatic Espresso coffee machine with microprocessor controlled volumetric dosing control & programming via digital keyboard. Automatic and manual boiler water refill is standard. Volumetric pump with motor for remote installation on 3 & 4 group machines. Machine available with 1 –...
-
Page 5: Description Of External Components
Description of external components. Attention: The 4 – group machine has two separate control circuits each controlling two groups; for this reason it is necessary to program the 1st group with the 2nd Keyboard for coffee and group and the 3rd group together with hot water delivery control the 4th group. - Page 6 Function of the machine The main components of the espresso coffee machine are the following: BOILER HOT-WATER TAP Contains hot water and steam. This delivers hot water. COFFEE DELIVERY GROUP AND CONTROL & MONITORING DEVICES HEAT EXCHANGERS Pressure gauge This is the component where the filter holder •...
-
Page 7: Main Switch
Main Switch The machine is equipped with a main power supply switch with 3 positions. Pos. 0 No power supply to internal components. Pos. 2 Power supply to function components. Pos. 1 Power supply to functional components and electric boiler heating elements. w w w . -
Page 8: Installation Warnings
Installation Warnings Please read carefully The Manufacturer has tried to foresee all possible safety devices to ensure the safety of the users. However, different conditions of installation or of equipment moving can cause situations which cannot be controlled or foreseen. Therefore, it’s absolutely necessary to evaluate all remaining risks and to care about the following suggestions: - This machine is safe only if appropriately connected to an efficient earth system complying with the safety standards in force in the state where the machine will be... -
Page 9: Installation
Installation Water drain vessel Electric Main switch supply cable Water feed from the mains Water inlet connection Water inlet valve Water Pipe from water filter to drain hose water inlet Water filter Mains switch electrical (not provided) connection to the mains POSITIONING AND CONNECTIONS Before installation the Manufacturer strongly recommends to check the water supply system and the electrical connections. - Page 10 Start up Turn the main switch to pos. “2”. The filling process will proceed automatically. When the boiler is filled, turn the main switch to pos. “1” to activate the heating element’s electrical feed.Wait until boiler pressure reaches maximum working pressure (approx.
-
Page 11: Maintenance
C-0315 C-0314 C-0323 C-0020M C-0324 C-0310 C-0031M C-0016M C-0030M C-0301 C-0022M C-0325 C-0303 C-0021M Streamline Supplies C-0309 Recommends the use of: C-0304 C-0308 230-50/60Hz C-0318 C-0306 V115-60Hz C-0322 C-0311 C-0310 C-0321 C-0307 w w w . s t r e a m l i n e s u p p l i e s . c o m . a u... - Page 12 Electric Diagram The machine is connected to the electric mains by a supply cable. As shown on the electric diagram there are two circuits: - A feeding circuit for electric components (solenoid valves, pump motor, electronic control panel. - A feeding circuit for the heating element. Water Circuit Semi-automatic 2 group.
- Page 13 Electrical Diagram Semi-Automatic Carmen S/1,2,3 230V Pump 11. Boiler filling pilot lamp Main Switch Solenoid - valve 1st group Automatic filling Heating element thermal protector Solenoid - valve 2nd group solenoid valve Pressure switch Solenoid - valve 3rd group Heating element...
- Page 14 Electrical Diagram Automatic Carmen A/4 230V 1 1 12 Hot water delivery solenoid valve Main Switch Heating element thermal protector Keyboard 1st group Pressure switch Keyboard 2nd group Heating element Keyboard 3rd group Mains pilot lamp Keyboard 4th group Boiler level sensor...
- Page 15 TROUBLE CAUSE SOLUTION the appliance doesn’t 1. main switch is off 1. set main switch to on switch ON 2. appliance switch if off 2. set appliance switch in pos. 1 3. wrong connection to mains 3. contact service to check No water in boiler 1.
-
Page 16: Warranty Conditions
For no reason can the buyer delay or suspend the payment agreed, this forfeits all rights and the guarantee. Streamline Supplies 9 Joseph Baldwin Place, Shepparton Victoria 3630...
