- Page 1 Operating Instructions (Automatic) Streamline Supplies Pty.Ltd. 9 Joseph Baldwin Place, Shepparton Victoria 3630 Ph: 03 5831 5555 Fax: 03 5821 3633...
- Page 2 Congratulations! The Butterfly A1 espresso machine has been conceived in response to the increasing demand from those who wish to enjoy the enticing aroma and taste of a freshly- made espresso or cappuccino, wherever a traditional machine would be too bulky or expensive, be it at home, or even at a special reception venue.
- Page 3 Instructions for use This machine is designed for the sole purpose of producing coffee, hot water and steam for hot drinks. All other uses are incorrect and, therefore, dangerous. This machine is designed for professional use only. The machine components are made of non-toxic and long lasting parts which are easily accessed for cleaning and maintenance.
- Page 4 Espresso Coffee Machine Range Lever Espresso coffee machine with lever operated manual dosing control. Automatic water boiler refill is standard. Built-in pump. Semi – Automatic Espresso coffee machine with switch operated manual dosing control. Automatic water boiler refill is standard. Built-in pump.
-
Page 5: Description Of External Components
Description of external components. water tank Cup tray guard underneath cup tray Cup tray steam wand control knob water storage warning lights (LED) (when flashing) Hot water wand control knob pressure gauge touch pad for coffee for boiler delivery control Hot water wand coffee brewing group... - Page 6 Function of the machine The main components of the espresso coffee machine are the following: BOILER HOT-WATER TAP Contains hot water and steam. This delivers hot water. COFFEE DELIVERY GROUP AND CONTROL & MONITORING DEVICES HEAT EXCHANGERS Pressure gauge The delivery group is the component Indicates the boiler pressure and the where the filter holder is inserted.
-
Page 7: Installation Warnings
Installation Warnings Please read carefully The Manufacturer has tried to foresee all possible safety devices to ensure the safety of the users. However, different conditions of installation can cause situations which cannot be controlled or foreseen. Therefore, it’s absolutely necessary to evaluate all remaining risks and to care about the following suggestions: - This machine is safe only if appropriately connected to an efficient grounding system complying with the safety standards in force in the Country where the machine will be... -
Page 8: Important Notice
Start up Remove machine from packing, fill-up the internal water tank and connect the machine to an appropriate power outlet through the power supply cable. Please perform installation procedure in accordance with the local country’s safety regulations. A correct start-up procedure can be performed by following the steps listed here below. -
Page 9: Steam Delivery
Preparing Espresso Coffee Espresso coffee can be prepared by using the following essential accessories: Coffee dosing grinder (not included) Single spout (1 cup) filter holder (included) Twin spouts (2 cups) filter holder (included). Twin espresso cups; proceed as follows: Single espresso cup: proceed as follows: 1. -
Page 10: Hot Water Delivery
Milk Frothing Techniques Considering that the Butterfly A/1 has a limited steam capacity(compared to the bigger units), the steam wand is fitted with a limited-size 4 hold steam tip to extend the steaming time, rather than the steaming flow-rate. In this way, the machine heating element can produce a faster steam pressure recovery. -
Page 11: Coffee-Dose Setting
Coffee-Dose Setting With reference to picture below: 1. Prepare and fill filter holder in due time with 9 grams perfectly-ground coffee and attach it to the brewing group. Place the appropriate cup(s) under the filter holder spout(s). 2. Push and hold the “star” key pressed for a few seconds until LED’s on touch-pad are switched ON to enter in the programming mode. -
Page 12: Maintenance
- Clean the plastic receptacle located in the part under the drip tray. Use a spoon for this purpose. - Clean the body-work with a non abrasive damp cloth. Never use aggressive products or alcohol. - Periodic regeneration of water filter. Streamline Supplies Recommends the use of:... -
Page 13: Technical Data
Dismantling and Disposal Of The Machine The machine can only be dismantled by an authorized technician. To this purpose, perform the following procedures: • Remove pressure from hydraulic circuits • Disconnect the machine from the electrical mains • Treat potentially harmful fluids and solids appropriately and do not discard them into the open environment. - Page 14 Electrical and Thermo-Hydraulic Features • Manual refill type tank, made of food-compatible plastic material, capacity 3 litres. • Twin-sensor based electronic minimum-level control of internal tank via electronic card, with automatic total-block of all machine functions in case of missing water. •...
- Page 15 TROUBLE CAUSE SOLUTION the appliance doesn’t 1. main switch is off 1. set main switch to on switch ON 2. appliance switch if off 2. set appliance switch to pos. 1 3. wrong connection to mains 3. contact service for check Missing hot water in boiler 1.
-
Page 16: Warranty Conditions
For no reason can the buyer delay or suspend the payment agreed, this forfeits all rights and the guarantee. Streamline Supplies 9 Joseph Baldwin Place, Shepparton Victoria 3630...
