B2 Mono Quattro Owner's Manual

High performance amplifiers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
HIGH PERFORMANCE AMPLIFIERS

Advertisement

Table of Contents
loading

Related Manuals for B2 Mono Quattro

Summary of Contents for B2 Mono Quattro

  • Page 1 OWNER'S MANUAL HIGH PERFORMANCE AMPLIFIERS...
  • Page 2 Mono & Quattro has through years of dedication introduced our line of amplifiers. line up are made to fullfil our philosophy for amplifiers; A variety of applications, highest possible efficiency and great appearance. amplifiers are designed to produce high power levels even from stock electrical systems. High efficiency is created from updating every stage through the amplifiers' circuit.
  • Page 3 3. CONTROL & CONNECTION Mono 3-1. CONTROL & CONNECTION INPUT BASS BOOST Connect preamp signal cables from Variable bass boost from 0-9 dB @ 45 Hz Mono the headunit to RCA Input of REMOTE LEVEL CONTROL PORT Connection of external level control. OUTPUT Output RCA for signal routing to another amplifier.

  • Page 4: Control & Connection

    Before you start your installation, please take all steps into consideration. Otherwise, please go to www.b2-audio.com for authorized distributors or contact us directly for support. 4-1. MOUNTING PREPARATION Disconnect the negative ( ) battery cable before mounting series or making any connections.

  • Page 5: Power Connection

    For safety purposes, install the amplifier in a dry and well ventilated location and make sure no cables or other harness of the car is interfaced with the mounting location or will present a hazard to the cars' cable, control cables, fuel lines/tanks, hydraulic lines or other components of the vechicle.

  • Page 6: Speaker Connection

    4-4. SPEAKER CONNECTION amplifier series recommends 12 AWG speaker connecting cables. Run 12 AWG speaker connecting cables from your speakers to amplifiers' mounting location Keep speaker cables away from power cables and series amplifier's input cables. Use grommets anywhere the cables have to pass through the holes in the metal frame or sheet metal.
  • Page 7 Quattro SPEAKER CONNECTION DIAGRAM i Tweeter Passive MidRange /Bass MidRange /Bass Passive Tweeter Quattro SPEAKER CONNECTION DIAGRAM ii Tweeter Passive MidRange /Bass 8 ohm ~ 4ohms Quattro SPEAKER CONNECTION DIAGRAM iii Tweeter Passive MidRange /Bass Passive MidRange /Bass Tweeter 8 ohm ~ 4ohms...

  • Page 8: Daisy Chain Connection

    Mono 4-5. DAISY CHAIN CONNECTION Daisy chain connection allows linking of 2 mono amplifiers to work as 1. Please read the following connection diagram cautiously to ensure the correct connection. Step 1 Mono . Connect the master amplifier to the head-unit and set its output master and input slave switch to the output master position.
  • Page 9 Headunit FUSE 360A GROUND 8 ohm ~ 2ohms Main Battery CAUTION Mono Minimum daisy chain connection impedance is 2 ohm Do not use daisy chain connection in 1 ohm Mono working Voltage is 9V ~ 16V.
  • Page 10 5. TROUBLE SHOOTING TIPS NO SOUND ( NO OUTPUT ) Mono & Quattro 1) Pls check all connections, cables' rounting, short, voltage at amplifiers and headunit 2) Pls check fuses ,If they are blown, pls replace with new ones. 3) Pls check whether speakers are functional. You can connect a AA battery to the speaker terminals to see if there is any movement of the speaker cone.
