Ko Propo KR-411FH Instruction Manual

KR-411FH
2.4GHz FHSS 4ch Receiver
For your safety
Please note the handling and use of this product.
The contents of this display show a possibility of
death or where a serious injury may occur or a highly
substantial damaging accident may occur.
This product is manufactured for surface use radio controls. *Discontinue use for all other purposes.
Discontinue use in the event of a thunder storm. *There is danger of a lightening bolt striking the antenna of the
transmitter.
Discontinue use when consuming alcohol or medication that may hinder concentration or judgement.
*Unexpected accidents are caused with a judgement mistake.
When rain and puddles are present, please discontinue use.
*There are times when water enters into the equipment and control will be lost.
Only use the batteries specified in the instruction manual of the transmitter.
To turn the system on, start by turning on the transmitter then the receiver.
To turn off the system, turn off the receiver first, then the transmitter in this sequence.
Please be sure to use only our products for the transmitter and servos.
*Concerning the damage and the like, which is generated when combining products that are not our company's
genuine products we do not owe responsibility.
Altering the transmission module is inhibited by law and is subjected to penal code violations. Resolution remodel-
ling of all products may result in the cause of a short and other accidents. In addition, if this product is altered we will
refuse repair service.
Please do not use this product inside an airplane, hospital, near any automatic control equipment, medical electrical
machinery and apparatus such as fire alarms.
In addition with respect to the law, if this product effects other radio equipment and electronic equipment, use must
be discontinued at once.
Our company cannot owe responsibility from the nature of the radio control models
and the customer assumes all responsibilities that result from this product being used.
About this products
Technical Specifications / Name of Parts
KR-411FH
(Receiver)
Number of Channels
Power source
Size
Weight
D.D.S. compatible
Fail safe system
Response Mode Compatible
( U LT R A / A DVA N C E D / S U PE R / N O R M A L / D D
ADVANCED / DD HI SPEED / DD NORMAL)
When a channel is not in use and
to prevent dirt and dust, attach
the provided connector cap.
Corresponding products
Please use this product with FHSS RF-Modules.
Corresponding Transmitters
EX-10 eurus / Helios
EX-1 UR
ESPRIT-3 UNIVERSE
Corresponding RF-Modules
RF-903FH
RF-904FH
Corresponding Servos
Digital Servos
WARNING
: 4 CH
: 4.8 v - 7.4 V
: 28 x 18.3 x 18.5 mm
LED Lamp
: 7.5 g
About Repairs
When breakdown repair it is requested, please report the breakdown status in as much detail
as possible. By noting the problem, repairs are performed quicker.
Instruction
manual
Antenna
Set Up Button
When you believe you have a breakdown.
Please refer to your manual once more and please inspect.
When you do not understand something, please inquire our service department.
When inquiring to our service department about a breakdown, please include in as much
detail as possible of the contents mentioned below about your problem.
Name of products (battery, car, transmitter & motor) used.
When breaking down, usage condition and description of breakdown condition.
Your address, name and telephone number.
When a repair is being requested, please be sure to send the memo which includes the
above-mentioned contents in as much detail as possible.
At this time we would like to thank you for purchasing our
product. Please read this instruction manual before using
this product. Also please read the instruction manual of
the transmitter being used.
ATTENTION
This displays shows the possibility or a
substantially damaging accident which
can cause injury.
P l e a s e av o i d s to r a g e i n a p l a c e of h i g h
temperatures and high humidity because it
m ay c au s e th e b re a kd ow n, d a m ag e a n d
deformation of the product.
Please note when using with an engine model,
place where exhaust and the waste oil will not
come into contact with the product. *In case
of submerging in oil or water, please send it
out for repair.
This product's performance is designed for
use in the shown specified usage which is
based on this instruction manual and the
instruction manual of the transmitter which is
u s e d . W h e n t h e i n s t r u c t i o n s a r e n o t
u n d e r s to o d, p l e a s e c o nt a c t o u r s e r v i c e
department for advise.
After verifying the safety of use, think of all the
accidents possible and please enjoy with
responsibility.
3/4 : Channels 3 and 4 connect
to other devices.
2 : Channel 2 Throttle servo or
ESC are connected.
1 : Channel 1 Steering servo is
connected.
B : Battery Channel Battery is
connected.
KONDO KAGAKU CO.,LTD.
4-17-7 Higashi-Nippori, Arakawa-ku, Tokyo Japan
Phone : +81-03-3807-7648
Website : http://www.kopropo.co.jp
