- Page 1 U S E R M A N U A L HIFI 4x2 HDMI Matrix Model No: HDMX0402M2 Enjoy the vivid world !
- Page 2 INTRODUCTION Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Our series of HDMI Converter. switchers, extenders, matrixes and splitters are designed to make your A/V device use more convenient ,more comfortable, more productive and more cost- efficient.
- Page 3 The SPDIF audio output format can be chose by pressing the switch key or the remote. It can come back to the default the input 1 status when restarted or reset. Led Status Light allow the user to know the working status easily. No loss of quality Installs in minutes Need DC5V/2A power supply...
- Page 4 B ：HDMI B output led status light B (1- 4)： 1-4 input led status light when output from B ARC：ARC Led Status Light SPDIF：SPDIF Port Led Status Light 2CH：2CH Audio Led Status Light 5.1CH：5CH Audio Led Status Light ADV: Advance Audio indicator A key: HDMI A output switch button B key: HDMI B output switch button ARC: ARC Functin On/Off Key(only the HDMI output A port supports ARC funciton).
- Page 5 Samsung Galaxy Note Phone HTC One X Samsung SIII HTC Flyer SPECIFICATIONS: HDMX0402M2 HDMI STANDARD……………………………..…..…………………………HDMI support 4K*2K input and 3D HDMI resolution …………………………..24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i Support video color format ……………………………..……. 24bit/deep color 30bit,36bit, 48bit Support audio format………………….DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD Audio output………………………………………………..….………...SPDIF and 3.5mm Stereo Max transmission bandwidth…….………………….……………………………………..340MHz...
- Page 6 Input/Output TMDS signal ………….…………………………..………………… 0.5~1.5Volts p-p Input/Output DDC signal ……………………………………………….………… 5Volts p-p (TTL) Input cable distance..…... ………………………….…….…≤15m AWG24 HDMI standard cable Output cable distance…………………………….….……...≤25m AWG24 HDMI standard cable Max working current…………………………………………………………………………1300mA Power adapter format………………..Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A Operating Temperature range……..…………….………………………………… (-15 to +55℃) Operating Humidity range………………………….….……….5 to 90%RH (No Condensation) Dimension (L x W x H) ……………………………….……………………..…250X27X75 (mm)
- Page 7 1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty, Erosive, and oxidative environment. 2. All parts will be free from the strong shake, hit, fall. 3. Touching the power adaptor with the wet hands is prohibited. 4.
