Summary of Contents for Ask HDSW0024M1
- Page 1 User Manual 3 Port HDR HDMI Switcher Model:HDSW0024M1...
- Page 2 INTRODUCITON Picture 1.0 front panel showing Picture 1.1 rear panel showing Picture 1.2 IR panel showing * Please take out the film at the rear of the remote before you use. Please insert the film to remote rear if you do not use the remote for long time.
- Page 3 Connection and operation: 1. To use HDMI cable to connect the HD source with the HDMI input port of device. 2. To use HDMI cable to connect the HDMI output port of device with the display. 3． To use the USB 2.0 TO DC 5.5MM power cable to connect the DC5V Port of the device with USB Power source like TV or USB Power Docking.
- Page 4 Spec: Mode No HDSW0024M1 Mode name 3 Port HDR HDMI switcher Input channel 3 port Output channel 1 port Video format 480P/720P/1080P/2160P Deep color 8/10/12Bit@480P/720P/1080P 8Bit@2160P Audio format Dolby HD/DTS HD/Dolby Atoms/Dolby AC3/DTS/LPCM..Transmission bandwidth 25~600MHz Transmission rate 0.75~18Gbps Auto switch...
