Tiptop Audio ZEUS Series microZEUS User Manual

Uzeus is a 4hp power supply module for eurorack format synthesizers

Advertisement

TM
ZEUS Series:
microZEUS

Power Supply

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZEUS Series microZEUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tiptop Audio ZEUS Series microZEUS

  • Page 1: Power Supply

    ZEUS Series: microZEUS Power Supply...
  • Page 2 Provided with the module is a 1000mA +15VDC unregulated wall adapter with a 2.5mm positive center pin connector. Tiptop Audio has the following recommendations for connecting your modules and using your uZEUS: To insure long life for the power supply, you should be aware of the total power consumption of your system.
  • Page 3 Zeus Series: microZEUS with Flying Bus Boards Wall Adapter Information: The Triad Magnetic wall adapter supplied with the uZEUS can deliver current in excess of 1000mA. The Ault wall adapter supplied with the Happy Ending kit is rated 1000mA and it is strongly recommended that it be kept at that limit. Please be sure to check the temperature of your wall adapter about 20 minutes after power up.
  • Page 4 Zeus Series: microZEUS with Flying Bus Boards Using the –12V Rail: The –12V rail uses a switching regulator. This switching regulator needs to have a minimum load of 100mA (out of 500mA) at any given time. The uZEUS has a factory setting to self consume this current.
  • Page 5 Zeus Series: microZEUS with Flying Bus Boards The uZEUS terminals GROUND (GND) +12V -12V *VR is used with Tiptop Audio ZEUS Passive Bus Board. VR Should be left open if connected to other bus boards.
  • Page 6 Zeus Series: microZEUS with Flying Bus Boards Connecting the uZEUS to the ZEUS Passive Bus Board +12V +12V +12V +12V +12V +12V +12V +12V GATE GATE GATE GATE GATE GATE GATE GATE GATE GATE GATE +12V +12V +12V +12V +12V +12V +12V +12V...
