Tiptop Audio uzeus User Manual

Zeus series: microzeus with flying bus boards

ZEUS Series:

microZEUS with

Flying Bus Boards

Table of Contents

Need help?

Do you have a question about the uzeus and is the answer not in the manual?

Page 1 ZEUS Series: microZEUS with Flying Bus Boards...
Page 2 Once you have successfully powered your uZEUS, all you have left to do now is play! It is important to note that the front panel of the uZEUS may get very warm. Please do not be alarmed as this is normal and is part of the standard operation of the uZEUS, more on that in the next pages, please continue reading.
Page 3 To do so check the heat of your uZeus face plate and the power adapter roughly 10 minutes after power up. If they become almost too hot to the touch then you are overloading one of them and this will cause them to fail.
Page 4 January 2017 Wall Adapter Information The uZEUS is designed to power systems ranging from 3U to 6U of 84HP with mixed analog and digital modules. Please make sure to use o cial Tiptop power adapter as these adapters are specially made to attain the best uZEUS performance and provide maximum power rating.
Page 5 The –12V rail uses a switching regulator. This switching regulator needs to have a minimum load of 100mA (out of 500mA) at any given time. The uZEUS has a factory setting to self consume this current. If your uZEUS is powering more than four (4) analog modules you can then disable this setting if desired to make this 100mA available for use by your modules.
Page 6 (right). Please note: As you keep adding more modules to your system make sure to monitor the heat of the uZeus face plate and the power adapter so to not overheat them as they might get damage if overloaded.
