2.

Technical Specifications

Electrical Characteristics
Operating Voltage
Maximum Input Current
General Inputs
Relay Outputs
Reader Ports
Visual Indicators
Audio
Battery Standby Time
Communication Characteristics
RS-232
RS-485
TCP/IP
Speed Options
Page 7
Technical Specifications
13.8V DC 1.5A from PS-33
AC-225:
Standby: 80mA
Maximum: 325mA
AC-225IP:
Standby: 120mA
Maximum: 370mA
4 supervised high impedance inputs.
8 or 12 supervised inputs when using
MD-D02 or MD-IO84 expansion boards
Maximum voltage: 5V DC
4 Relay outputs
8 supervised outputs when using MD-
D02 or MD-IO84 expansion boards
5A Relay N.O. and N.C. options
Standard = 2 Reader ports
With MD-D02 = 4 Reader ports
Output voltage: 12V DC
Max. Current: 245mA
LED control output D0/D1, tamper
input
11 LEDs
Built in sounder (bell, chime and siren)
3 hours (for w/12V battery
Terminal Block
Molex and Terminal Block
On-board RJ-45 connector
(AC-225IP and AC-225IPU have an
internal IP module)
9600 bps
19200 bps
57600 bps
115200 bps
AC-225 Hardware Installation and User Guide
