One Fire Grills 3400 User Manual

Charcoal grill
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
The Traveler
100% Portable Charcoal Grill
Simply makes your grill portable and
Charcoal Grill User's Manual
For Outdoor Household Use Only. Not for Commercial Use.
• This instruction manual contains important information necessary for the proper
assembly and safe use of this appliance. Failure to follow these instructions could
result in death or serious injury from explosion or fire.
• Read and follow all warnings and instructions carefully before assembling or using
this appliance.
• Keep this manual for future reference.
Need Help? Need to Register Your Grill? Looking for Parts & Accessories?
Visit us online at www.onefiregrills.com Or call Customer Service at 1-800-251-7558
Just Fold up and Go!
compact for storage.
WARNING
!
Model 3400
SAVE THESE INSTRUCTIONS.
P/N 03.1558.00 Rev. 20121204

Advertisement

Table of Contents
loading

Related Manuals for One Fire Grills 3400

Summary of Contents for One Fire Grills 3400

  • Page 1 100% Portable Charcoal Grill Just Fold up and Go! Simply makes your grill portable and compact for storage. Model 3400 Charcoal Grill User’s Manual For Outdoor Household Use Only. Not for Commercial Use. WARNING • This instruction manual contains important information necessary for the proper assembly and safe use of this appliance.

  • Page 2: Carbon Monoxide Hazard

    D A N G E R CARBON MONOXIDE HAZARD This appliance can produce carbon monoxide, an odorless toxic gas. Using it in an enclosed space can kill you. Never use this appliance in an enclosed space, such as a camper, tent, car, or home. This appliance is not intended for and should never be used as a heater.

  • Page 3: Preparation For Assembly

    Preparation for Assembly TOOLS NEEDED: Straight and Phillips head Screwdrivers and a 3/8” open end wrench or a pair of pliers. Pull the Cooking Grid straight up until it snaps out of the Bowl and lay it aside. Note that the Cooking Grid fits tight to remain in place when you transport your Traveler grill.
  • Page 4 Step 2 LEG ASSEMBLY TO BOWL Place the Bowl on its side on the floor or on a flat work sur- face. Orient the Leg Assembly as shown with the loose leaf of the hinges facing the center of the Bowl. Align the outer hole in each hinge with the corresponding holes in the Bowl Washer Locknut and put a 10 -24 x 1/2”...
  • Page 5 Step 5 1/2” Screw (Phillips Head) HINGE ASSEMBLY Acorn Locknut Align holes in the Left Hand Hinge Assembly with the two matching holes on the left inside of the Bowl. The short hinge with the bend should be nearest the rear of the bowl. Put a 10-24 x 1/2”...

  • Page 6: Using Charcoal

    USING CHARCOAL To reduce the risk of serious injury or death from explosion or fire: • Be careful when burning charcoal to avoid getting burned from flame, heat or hot coals. • Be aware of the wind blown sparks. • The use of alcohol, prescription or non-prescription drugs could impair the consumer’s ability to properly assemble or safely operate this appliance.
  • Page 7 STARTING A CHARCOAL FIRE IN YOUR ONE FIRE TRAVELER GRILL STEP 1. Use a high quality hardwood charcoal to make sure you get a good fire. Charcoal briquettes made from maple, oak, birch or elm woods will burn clean with very little smoke and without unpleasant odors. STEP 2.
