9320
Please record your grill's 10 digit serial number here:______________________________________________
The serial number is located on the black and silver label on the back side of the element control housing.
Please also save your proof of purchase for warranty purposes.
Electric Grill User's Manual
For Outdoor Household Use Only. Not for Commercial Use.
Need Help? Need to Register Your Grill? Looking for Parts & Accessories?
Visit us online at www.onefi regrills.com Or call Customer Service at 1-800-251-7558
• This instruction manual contains important information necessary for the proper assembly and
safe use of this appliance. Failure to follow these instructions could result in death or serious injury
from explosion or fi re.
• Read and follow all warnings and instructions carefully before assembling or using this appliance.
• Keep this manual for future reference.
9300 SERIES
Table Top and Cart
Electric Barbecue Grills
9300
9325
WA R N I N G
!
SAVE THESE INSTRUCTIONS.
9309
03.5875.02 Rev. 20171207
9329
Advertisement
Table of Contents
Related Manuals for One Fire Grills 9320
Summary of Contents for One Fire Grills 9320
- Page 1 Table Top and Cart Electric Barbecue Grills 9300 9309 9320 9325 9329 Please record your grill’s 10 digit serial number here:______________________________________________ The serial number is located on the black and silver label on the back side of the element control housing.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS WA R N I N G Read all instructions and warning labels prior to use. Failure to follow these safeguards may result in serious personal injury or property loss. This appliance is intended for outdoor household, non-commercial use only. •... - Page 3 Features That Make Your MECO Grill Outstanding A New Advancement in State of the Art Outdoor Cooking Uses the energy effi cient concept of infrared refl ectivity to save energy that is normally wasted. It not only gives you steaks seared to perfection, but also cooks chicken to tender, succulent doneness without burning. It totally eliminates the need for lava rock.
-
Page 4: Temperature Control
BREAK-IN: Place your grill in a well ventilated area. Make sure overhead combustible surfaces are at least four feet above grill. If you have a table model grill, put it on a sturdy surface, away from the edge, and out of the reach of children. Keep the electrical cord out of walkways so it will not be tripped over. -
Page 5: Preparation For Cooking
THERE ARE THREE WAYS TO COOK ON YOUR EASY STREET ELECTRIC GRILL: (1) The Direct method is for steaks, chops, chicken pieces, and other foods that require SETTING 3 (High) heat and short cooking time. Just put the meat directly on the grid for cooking this way. (2) The Indirect method is for cooking large roasts and poultry that requires SETTING 1 (Low) heat and long cook- ing times. -
Page 6: Care And Maintenance
Care and Maintenance - End of Cooking Session WA R N I N G To reduce risk of serious injury or death from fi re or burn hazard: • Allow grill and grease in the Grease Cup to completely cool before emptying, cleaning, moving, or storing grill. •... - Page 7 Basic Table Top Model 9309 Basic Table Top Model PLUS 9300 - Window - Rotisserie Kit (Spit, Forks, Bracket & Motor) 9309 9320 Basic Cart Model 9325 Basic CART Model 9320 PLUS - Two WPC Slat Folding Side Tables 9325 9329...
- Page 8 Item Part / Desc. Part # Model Owner’s Manual 03.5875.02 All 9300 series Hood / Bowl Assembly 9300, 9320, 9325 Hood / Bowl Assembly 9309, 9329 Bolt #10-24 x 1/2“ 03.0201.02 All 9300 series Rotisserie Lock 17.1698.00 All 9300 series Acorn Nut #10-24 03.5000.55...
- Page 9 MECO 9300 Series Parts List and Illustrations...
-
Page 10: Preparation For Assembly
Preparation for Assembly READ ALL INSTRUCTIONS in the Owner’s Manual before you start. VERIFY PARTS. Remove all parts from the box and arrange on a smooth clean surface. Verify that you have all the parts listed in the below “Parts List”. If you have any questions or need help, contact Customer Service at 1-800-251-7558 or go to www.onefi... - Page 11 SHELF & LEG ASSEMBLY (9320 - 9325 - 9329) WIRE LEG SHELF: (FIG C) Make certain "INDENTS" Wire are to the outside on both ROLLER and FIXED LEGS. Leg Shelf Attach a CROSSBRACE to each side of the Legs with #10-24 x 1 1/4"...
- Page 12 WHEEL ASSEMBLY (9320 - 9325 - 9329) (FIG G) Insert an RIVET AXLE through the center hole on the recessed side of the WHEEL. (The op- posite side that is placed against the Leg Tube has a raised cone shaped center.) Insert the end of the Axle, that extends through the Wheel, through the hole in the end of the Leg Tube and fasten in place by inserting the COTTER PIN through the hole in the end of the Axle.
- Page 13 DRIP PAN/HOLDER ASSEMBLY (9320 - 9325 - 9329) Top Frame Brace Holder Hook Hang DRIP PAN HOLDER by one side on the Top Frame Brace. (FIG L) grasp the opposite side of the Holder with index fi ngers and pull up over the Top Frame Brace.
-
Page 14: Final Assembly
Bumps in the back of the Grill Bowl and the two Support Tubes in the front of the Bowl. (FIG Q) 9320 - 9325 - 9329 Install the Foil Drip Pan and the Drip Pan Holder. (FIG R) 9320 - 9325 - 9329... - Page 15 P/N 03.5875.02 Rev. 20171207...
