Page 1: User Manual
Leica GKL341 User Manual Version 1.0... - Page 2 Read carefully through the User Manual before you switch on the product. Product identification The type and serial number of your product are indicated on the type plate. Always refer to this information when you need to contact your agency or Leica Geosystems authorised service workshop.
-
Page 3: Description Of The System
Description of the System Main Components Not included in the delivery: GKL341 GEV223 GDC221 (Country-specific cable; refer to "Power Supply") 006324_001 GKL341, Description of the System... - Page 4 GKL341, Description of the System Charger Components 12/24 V 100-240 V 006325_001...
- Page 5 Ni-MH GEB222 GEB242 Leica Leica GEB211 GEB331 GEB212 Li-Ion, Li-Po 006326_001 Power supply 230 V SAE J563 (21 mm) ISO 4165 (12 mm) 120 V 220 V GDC221 230 V 230 V 12/24 V 006340_001 GKL341, Description of the System...
- Page 6 GKL341, Description of the System Charging function / Calibration function Calibration Charging 006327_001...
- Page 7 Charging times ...4h ...8h 006328_001 GKL341, Description of the System...
-
Page 8: Operation
GKL341, Operation Operation Connecting the charger 100-240 V 12/24 V GDC221 100-240 V 0-240 V 12/24 V 12/24 V 100-240 V 12/24 V GDC221 D D C2 D D C GDC221 006329_001... -
Page 9: Charging Function
Charging Function Inserting and charging the batteries ...30% 0%-30% ...60% 31%-60% ...90% 61%-90% ...100% 91%-100% 006330_001 GKL341, Operation... - Page 10 GKL341, Operation Charging priority 100% 100% 006331_001...
- Page 11 Change of charging priority 100% 100% 100% 100% 006332_001 GKL341, Operation...
-
Page 12: Calibration Function
GKL341, Operation Calibration Function Option 1: Charger recommends a Calibration Carry out calibration? ...10s 006333_002... - Page 13 Estimated ...5s calibration time <8h 8-12h 12-16h 16-24h 0%-24% 25%-49% 50%-74% 75%-99% 100% 006342_002 GKL341, Operation...
- Page 14 GKL341, Operation Option 2: Request a calibration Calibration 006334_002...
- Page 15 Estimated ...5s calibration time <8h 8-12h 12-16h 16-24h 0%-24% 25%-49% 50%-74% 75%-99% 100% 006342_002 GKL341, Operation...
-
Page 16: Firmware Update
GKL341, Operation Firmware update Firmware Update 100-240 V GEV223 100-240 V 12/24 V Firmware max. 1 min 100% Firmware Firmware > 1 min 006335_001... -
Page 17: Troubleshooting
Troubleshooting Error indication 50°C 50°C 0°C 0°C Input Voltage! 006336_001 GKL341, Troubleshooting... - Page 18 Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com...
- Page 19 Leica GKL341 User Manual Version 1.0 English...
-
Page 20: Safety Directions
GKL341, Safety Directions Safety Directions General Introduction Description The following directions enable the person responsible for the product, and the person who actually uses the equipment, to anticipate and avoid operational hazards. The person responsible for the product must ensure that all users understand these direc- tions and adhere to them. - Page 21 All instructions required in order to operate the product to a basic level are contained in this User Manual. Provides an overview of the system together with technical data and safety directions. Refer to the following resources for all GKL341 documentation: • http://www.leica-geosystems.com/downloads GKL341, Safety Directions...
-
Page 22: Definition Of Use
+10°C to +20°C/+50°F to +68°F if possible. • It is normal for the battery to become warm during charging. Using the chargers recom- mended by Leica Geosystems, it is not possible to charge the battery if the temperature is too high. -
Page 23: Limits Of Use
• To ensure that it is used in accordance with the instructions. • To be familiar with local regulations relating to safety and accident prevention. • To inform Leica Geosystems immediately if the product and the application becomes unsafe. • To ensure that the national laws, regulations and conditions for the operation of e.g. -
Page 24: Hazards Of Use
• Using the product after incorrect attempts were made to carry out repairs Precautions: Do not open the product. Only Leica Geosystems authorised service workshops are entitled to repair these products. Using the charger inside a driving vehicle can lead to dangerous situations which may result WARNING in damage or personal injury. - Page 25 Precautions: Make sure that the ventilation slots are not covered by any objects while the product is being used. If charged or discharged, batteries not recommended by Leica Geosystems may be WARNING damaged. They may burn and explode. Precautions: Only charge and discharge batteries recommended by Leica Geosystems.
- Page 26 Dispose of the product appropriately in accordance with the national regu- lations in force in your country. Always prevent access to the product by unauthorised personnel. Product-specific treatment and waste management information can be downloaded from the Leica Geosystems home page at http://www.leica-geosystems.com/treatment or received from your Leica Geosystems dealer.
-
Page 27: Electromagnetic Compatibility (Emc)
CAUTION Although the product meets the strict regulations and standards which are in force in this respect, Leica Geosystems cannot completely exclude the possibility that the product may be disturbed by intense electromagnetic radiation, for example, near radio transmitters, two-way radios or diesel generators. -
Page 28: Fcc Statement, Applicable In U.s
GKL341, Safety Directions If the product is operated with connecting cables attached at only one of their two ends, CAUTION for example external supply cables, interface cables, the permitted level of electromagnetic radiation may be exceeded and the correct functioning of other products may be impaired. -
Page 29: Care And Transport
Care and Transport Transport Shipping When transporting the product by rail, air or sea, always use the complete original Leica Geosystems packaging, transport container and cardboard box, or its equivalent, to protect against shock and vibration. Transport in a road Never carry the product loose in a road vehicle, as it can be affected by shock and vibration. -
Page 30: Cleaning And Drying
GKL341, Care and Transport Shipping, transport of When transporting or shipping batteries, the person in charge of the product must ensure batteries that the applicable national and international rules and regulations are observed. Before transportation or shipping, contact your local passenger or freight transport company. -
Page 31: Technical Data
Protection against solid Type Protection objects GKL341 IP30 (IEC 60529) Protected against solid objects > 2.5 mm Cell type Li-Ion and Li-Po Charging times • 1-2 batteries: up to 4.0 h • 3-4 batteries: up to 8.0 h GKL341, Technical Data... -
Page 32: Conformity Declarations
• FCC Part 15 (applicable in US) regulations • Hereby, Leica Geosystems AG, declares that the GKL341 is in compliance with the essential requirements and other relevant provisions of the applicable European Directives. The declaration of conformity may be consulted at... - Page 34 Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Phone +41 71 727 31 31 www.leica-geosystems.com...
