Synapse SNAP Quick Start Manual

SNAP® Link Serial Wireless Adapters
QUICK START: PLEASE READ THIS FIRST
Power
1.
2.
Pairing
1. Press and hold the MODE button on the first unit
for over 5 seconds; release when LED "A" turns
red. It will now flash red.
2. Standing near the first unit, press and hold the
MODE button on unit 2; release when LED "A"
turns red. The units are now paired.
3. Once paired, LED "A" flashes green to indicate
good signal quality.
A flashing amber color indicates successful pairing, but
with a weak signal.
Connect units to existing devices
How to reset to factory defaults:
1. Unplug the device.
2. While holding down the MODE button, plug the
device back into a power source and wait until
all LEDs turn amber, about 6 seconds.
3. Release the MODE button. LED "A" turns off to
indicate success.
How to drop out of pairing mode:
1. Hold down the MODE button next to LED "A" for 5 seconds on one of the paired units.
2. It will drop out of paired state and go back into "pairing mode", indicated by the flashing
red LED "A." If you click once quickly on that same unit, it should "re-pair" to the unit it was
previously paired with.
Apply power to Unit 1 using either the wall plug or a PC.
Apply power to Unit 2.
SNAP® Link Serial Wireless Adapters
QUICK START: PLEASE READ THIS FIRST
Power
1.
2.
Pairing
1. Press and hold the MODE button on the first unit
for over 5 seconds; release when LED "A" turns
red. It will now flash red.
2. Standing near the first unit, press and hold the
MODE button on unit 2; release when LED "A"
turns red. The units are now paired.
3. Once paired, LED "A" flashes green to indicate
good signal quality.
A flashing amber color indicates successful pairing, but
with a weak signal.
Connect units to existing devices
How to reset to factory defaults:
1. Unplug the device.
2. While holding down the MODE button, plug the
device back into a power source and wait until
all LEDs turn amber, about 6 seconds.
3. Release the MODE button. LED "A" turns off to
indicate success.
How to drop out of pairing mode:
1. Hold down the MODE button next to LED "A" for 5 seconds on one of the paired units.
2. It will drop out of paired state and go back into "pairing mode", indicated by the flashing
red LED "A." If you click once quickly on that same unit, it should "re-pair" to the unit it was
previously paired with.
Apply power to Unit 1 using either the wall plug or a PC.
Apply power to Unit 2.
