INSTALLATION AND OPERATING INSTRUCTIONS
Shown with
Log Set
VDY30D3R
Shown with
Log Set
VDY24/18D4
Natural Gas or Propane/LPG
Approved to ANSI Z21.60
This gas log set is to be installed only
in a solid-fuel burning fireplace with a
working flue constructed of noncom-
bustible material.
Shown with
Log Set
VDY24/18D2A
MODELS: VDY24/18 • VDY30
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
–
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
• Immediately call your gas supplier from a neighbor's
• If you cannot reach your gas supplier, call the
–
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
READ AND SAVE THESE INSTRUCTIONS
Shown with
Log Set
VDY24/18D5
Control Type: Manual and Millivolt
WARNINGS
phone in your building.
phone. Follow the gas supplier's instructions.
fire department.
Advertisement
Table of Contents
Related Manuals for MHS Boilers VDY24/18
Summary of Contents for MHS Boilers VDY24/18
- Page 1 Shown with Log Set Log Set VDY24/18D2A VDY24/18D4 MODELS: VDY24/18 • VDY30 Natural Gas or Propane/LPG Control Type: Manual and Millivolt WARNINGS If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
