DIRECT VENT GAS FIREPLACE
INSTALLATION AND OPERATING INSTRUCTIONS
CDVR33, CDVT33,
CDVR36
WARNINGS
IF THE INFORMATION IN THESE INSTRUCTIONS ARE
NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROPERTY DAMAGE,
PERSONAL INJURY OR LOSS OF LIFE.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
–
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
–
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment,
alteration, services or maintenance can cause injury or
property damage. Refer to this manual. For assistance
or additional information consult a qualified installer,
service agency or the gas supplier.
This appliance may be installed in an aftermarket*,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale, from
the manufacturer.
READ BEFORE INSTALLING. SAVE THESE INSTRUCTIONS
CDV SERIES
MODELS:
CDVT36
AND
CDVT
CDVR
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURE AND SHOULD
STAY AWAY TO AVOID BURNS OR
CLOTHING IGNITION.
Y O U N G C H I L D R E N S H O U L D B E
SUPERVISED WHEN THEY ARE IN THE
SAME ROOM AS THE APPLIANCE.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED ON
OR NEAR THE APPLIANCE.
KEEP THE ROOM AREA CLEAR AND
FREE FROM COMBUSTIBLE MATERIALS,
GASOLINE, AND OTHER FLAMMABLE
VAPORS AND LIQUIDS.
Advertisement
Table of Contents
Related Manuals for MHS Boilers CDVR33
Summary of Contents for MHS Boilers CDVR33
-
Page 1: Installation And Operating Instructions
CDV SERIES DIRECT VENT GAS FIREPLACE INSTALLATION AND OPERATING INSTRUCTIONS MODELS: CDVR33, CDVT33, CDVR36 CDVT36 CDVT WARNINGS IF THE INFORMATION IN THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. -
Page 2: Table Of Contents
Orifice Sizes, Pressures and BTUs ....6 Lighting Pilot..........36 Before You Start..........6 Lighting Burner ..........37 Fireplace Framing - CVDR36 and CDVR33.. 7 To Turn Off Gas .......... 37 Fireplace Framing - CVDT36 and CDVT33 .. 8 Electronic Ignition Operating Instructions ... 38 Fireplace Dimensions........ -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION INSTALLER OWNER Please leave these instructions with the appliance. Please retain these instructions for future reference. • Read this owner’s manual carefully and completely before trying to assemble, operate, or service this fireplace. • Any change to this fireplace or its controls can be dangerous. •... - Page 4 IMPORTANT SAFETY INFORMATION Continued from page 3 IMPORTANT: 12. Do not use this fireplace to cook food or burn paper or PLEASE READ THE FOLLOWING CAREFULLY other objects. It is normal for fireplaces fabricated of steel to 13. Never place anything on top of fireplace. give off some expansion and/or contraction noises during the start up or cool down cycle.
-
Page 5: Product Features
Ignitor On/Off/RS Switch Blower Control Figure 1 - CDVR33, CDVT33, CDVR36 and CDVT36 Fireplace CODE APPROVAL Direct Vent type appliances draw all combustion air from outside of the dwelling through the vent pipe. These appliances have been tested by CSA and found to comply with the established standards for DIRECT VENT GAS... -
Page 6: Pre-Installation Information
3.5" Manifold Press: (W.C.) 10" Maximum Supply Pressure 10.5" Maximum Supply Pressure 13" Minimum Supply Pressure 4.5" Minimum Supply Pressure 11" CDVR36 CDVT36 CDVR33 CDVT33 Model Number Natural Propane Natural Propane Natural Propane Natural Propane Max. Btu/hr Input 20,000 20,000... -
Page 7: Fireplace Framing
" " " " " CDVR33 and CDVR36 Corner Installation " or " CDVR33 and CDVR36 Inside Chase Installation " or " CDVR33 and CDVR36 Recessed Installation or CDVR33 and CDVR36 Outside Chase Stud Location Figure 2 - Framing Dimensions... - Page 8 FIREPLACE FRAMING FIREBOX FRAMING FOR CDVT33/36 Firebox framing can be built before or after the appliance is set in place. Construct firebox framing following Figure 3 and the chart below for your specific installation requirements. See Figure 4 on Page 10 for firebox dimensions. The framing headers may rest on the top of the firebox standoffs.
-
Page 9: Fireplace Dimensions
" Finishing Material Spacers " " " " " " " " " " " " " " 32" B" " " Framing Dimension " " " " Figure 5 - CDVR33 and " CDVR36 " " Fireplace Dimensions Framing Dimension 69D0023... -
Page 10: Fireplace Location
PRE-INSTALLATION INFORMATION FIREPLACE LOCATION Plan for the installation of your appliance. This includes determining where the unit is to be installed, the vent configuration to be used, framing and finishing details, and whether any optional accessories (i.e. blower, wall switch, or remote control) are desired. -
Page 11: Clearances
CLEARANCES CLEARANCES TO COMBUSTIBLES Follow these instructions carefully to ensure safe installation. Failure to follow in struc tions exactly can create a fire hazard. The appliance cannot be installed on a carpet, tile or other combustible material other than wood flooring. If installed on carpet or vinyl flooring, the appliance shall be installed on a metal, wood or noncombustible material panel ex tend ing full width and depth of the appliance. -
Page 12: Securing Fireplace To Floor Or Framing
SECURING FIREPLACE TO FLOOR OR FRAMING The fireplace must be secured to the floor and/or to framing studs as shown in Figure 8. Use two (2) wood screws or masonry/ concrete screws to secure fireplace to the floor. Use four (4) screws to attach fireplace to framing. The side nailing flanges "... -
Page 13: Installation Information
INSTALLATION INFORMATION FINISHING MATERIAL NOTE: Any wiring (i.e. remote control, wall switch, and optional fan) must be done prior to final finishing to avoid costly reconstruction. Never obstruct or modify the air inlet or outlet grills (louvers). This may create a fire hazard. Only noncombustible materials (i.e. -
Page 14: Vent Installation
1 " 3 " 1 " 1 " A Minimum 1" Clearance to Combustibles Permitted All Around Flue at Outside Wall Figure 9 - Combustible Clearances for Vent Pipe - CDVR36 and CDVR33 69D0023... -
Page 15: Top Vent Installation
VENT INSTALLATION TOP VENT INSTALLATION This fireplace must be vented to the outside. The venting system must NEVER be attached to a chimney serving a separate solid fuel burning appliance. Each gas appliance must use a separate vent system. Do not use common vent systems. A Minimum of 3"... -
Page 16: Installation Planning
VENT INSTALLATION INSTALLATION PLANNING There are two basic types of direct-vent installation: • Horizontal Termination • Vertical Termination It is important to select the proper length of vent pipe for the type of termination you choose. It is also important to note the wall thickness. - Page 17 VENT INSTALLATION FOR HORIZONTAL TERMINATION Inside Corner Detail Fixed Closed Opera- Fixed Closed Operable Vent Terminal Air Supply Inlet Area Where Terminals Not Permitted Figure 11 - Horizontal Vent Termination Location MINIMUM DISTANCES A = Clearance above the grade, a veranda, porch, deck, or balcony [*12" (305mm) minimum]. B = Clearance to window or door that may be opened [*12"...
- Page 18 VENT INSTALLATION TERMINATION CLEARANCES FOR BUILDINGS WITH COMBUSTIBLE AND NONCOMBUSTIBLE EXTERIORS Combustible = 6" (152mm) Noncombustible = Combustible = 2” (51mm) 6" (152mm) Noncombustible = 2” (51mm) Inside Corner Outside Corner C = Maximum depth of 48" (1219mm) for alcove location D = Minimum width for back wall of alcove location Combustible - 38"...
-
Page 19: Rear (Through The Wall) Applications
VENTING INSTALLATION REAR (THROUGH THE WALL) APPLICATIONS When installed as a rear vent unit this appliance may be vented directly to a termination located on the rear wall behind the appliance • The maximum horizontal distance between the rear of the appliance and the outside of termination is 20" (508 m). See Figure 14. - Page 20 VENT INSTALLATION REAR WALL VENT INSTALLATION (continued) 4. Apply a bead of non-hardening mastic around the outside edge of vent cap. Position the vent cap in the center of hole on the exterior wall with the word “UP” on the vent cap facing up.
-
Page 21: Horizontal Termination Configuration
VENT INSTALLATION HORIZONTAL TERMINATION CONFIGURATIONS Since it is very important that the venting system maintain its balance between the combustion air intake and the flue gas exhaust, certain limita- tions as to vent configurations apply and must be strictly adhered to. The Vent Graph, showing the relationship between vertical and horizontal side wall venting, will help to determine the various dimensions allowable. -
Page 22: Horizontal Termination Configuration
VENT INSTALLATION HORIZONTAL TERMINATION CONFIGURATION 90° (Continued) • If a 90° elbow is used in the horizontal vent run (level height maintained) the horizontal vent length is reduced by 36". See Figures 21 and 22, page 20. This does not apply if the 90°... -
Page 23: Below Grade Installation
VENT INSTALLATION BELOW GRADE INSTALLATIONS When it is not possible to meet the required vent terminal clearances of 12" above grade level, a snorkel kit is recommended. It allows installation depth down to 7" (178mm) below grade level. The 7" (178mm) is measured from the center of the horizontal vent pipe as it penetrates through the wall. -
Page 24: Vertical Through-The-Roof Installation
VENT INSTALLATION VERTICAL (THROUGH-THE-ROOF) APPLICATIONS This Gas Fireplace has been approved for, • Vertical installations up to 40' (12m) in height. Up to a 10' (3m) horizontal vent run can be installed within the vent system using a maximum of two 90° elbows. See Figure 28. NOTE: Horizontal sections of this vent system require a minimum of 3"... -
Page 25: Installation For Vertical Termination
VENT INSTALLATION INSTALLATION FOR VERTICAL TERMINATION 1. Determine the route your vertical venting will take. If ceiling joist, Roof roof rafters or other framing will obstruct the venting system, Flashing consider an offset. See Figure 30 to avoid cutting load bearing members. -
Page 26: Cathedral Ceiling Installation
VENT INSTALLATION 3. Cut a hole in the roof using the locating hole as a center point. (Cover any exposed open vent pipes before cutting hole in 1/ 2 roof). The 9 "x9 " (241mm x 241mm) hole must be measured on the horizontal. Actual length may be larger depending on the pitch of the roof. -
Page 27: Fireplace Installation
FIREPLACE INSTALLATION CHECK GAS TYPE Use proper gas type for the fireplace you are installing. If you have conflicting gas type, do not install fireplace. See dealer where you purchased the fireplace for proper fireplace for your gas type or conversion kit. INSTALLING GAS PIPING TO FIREPLACE / BURNER SYSTEM LOCATION A qualified installer or service person must connect appliance to gas supply. - Page 28 FIREPLACE INSTALLATION Only persons licensed to work A manual shutoff valve must be with gas piping may make the installed upstream of the appliance. necessary gas connections to Union tee and plugged 1/8" NPT this appliance. pressure tapping point should be installed upstream of the appliance.
-
Page 29: Checking Gas Pressure
CHECKING GAS PRES SURE ELECTRICAL INSTALLATION Check gas type. The gas supply must be the same as stated on the appliance’s rating decal. If the gas supply is different from the fireplace, STOP! Do not install the appliance. Contact your dealer immediately. To ease installation, a 30"... - Page 30 ELECTRICAL INSTALLATION REMOTE WALL MOUNTED SWITCH A remote wall switch and up to fifteen (15) feet of 18 Ga. wire may be used with this appliance. Attach the wall switch in a junc- tion box at the desired location on the wall. See Figure 38. Do not extend beyond the wall switch wire length provided. NOTE: Extended lengths of wire may cause the fireplace not to function properly.
-
Page 31: Electronic Pilot Ignition Wiring
ELECTRICAL INSTALLATION ELECTRONIC PILOT IGNITION WIRING Do not connect 110-120 VAC to the Remote Wall Switch. The appliance Pilot Assembly will malfunction. To Junction Box Spark Sense Ignition Module (Synetek) GREEN WHITE BLACK MAGENTA #5 BLACK WHITE Primary - 120V Electronic Valve Transformer Secondary... -
Page 32: Optional Fan/Blower Systems
ELECTRICAL INSTALLATION OPTIONAL FAN/BLOWER SYSTEMS The junction box for the fan/blower systems has been factory installed. This system requires that 110-120 VAC to be wired to the factory installed junction box before the fireplace is permanently installed. See Figure 41. 120VAC Receptacle Junction... -
Page 33: Glass Removal
4. Set glass frame aside. Glass Frame Clamps Figure 43 - Removing Glass Frame - CDVR36 and CDVR33 Glass Frame Clamps Figure 44 - Removing Glass Frame - CDVT33 and CDVT36 Each clamp has a quick spring force. -
Page 34: Final Installation
FINAL INSTALLATION ROCK WOOL PLACEMENT 1. Place rock wool on burner to provide glowing embers. For best results, pull the rock wool apart Burner into pieces the size of a nickel or smaller. 2. Distribute one layer of rock wool to cover the entire burner. -
Page 35: Millivolt Operating Instructions
MILLIVOLT OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING If you do not follow these instruction exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with a pilot which must be lit with built-in piezo ignitor while following these instructions exactly. -
Page 36: Lighting Pilot
MILLIVOLT OPERATING INSTRUCTIONS LIGHTING PILOT FOR THE FIRST TIME APPROVED LEAK TESTING METHOD You may check for gas leaks with the following methods only: If using a soap and water solution to test for leaks, • Soap and water solution DO NOT spray solution •... -
Page 37: Lighting Burner
MILLIVOLT OPERATING INSTRUCTIONS LIGHTING BURNER MAIN BURNER SWITCH The “ON/OFF/RS” switch for the main burner can be found behind door of the fireplace. This switch allows you to turn on and to turn off the main burner without using the gas valve knob. Make sure the button is in the “ON”... -
Page 38: Electronic Ignition Operating Instructions
ELECTRONIC IGNITION OPERATING INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING A. This appliance is equipped with an ignition device (Piezo) which automatically lights the pilot. Do If you do not follow these instructions NOT try to light the burner by hand. exactly, a fire or explosion may result causing property damage, personal B. -
Page 39: Cleaning And Maintenance
CLEANING AND MAINTENANCE Turn off gas before servicing fireplace. It is recommended that a qualified service technician perform these check-ups at the beginning of each heating season BURNER, PILOT AND CONTROL COMPARTMENT Keep the control compartment, logs, and burner areas surrounding the logs clean by vacuuming or brushing at least twice a year. -
Page 40: Vent System
CLEANING AND MAINTENANCE VENT SYSTEM The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow. Inspect entire venting system to ensure proper function. -
Page 41: Troubleshooting
TROUBLESHOOTING STANDING PILOT IGNITION SYMPTOM POSSIBLE CAUSE ACTION 1. Spark ignitor A. Wire disconnected. A. Open door and check to make sure wire is connected to ignitor. will not light B. Check for spark at electrode and pilot. If no spark and electrode pilot after B. - Page 42 TROUBLESHOOTING ELECTRONIC IGNITION START 1. Turn gas supply off. Check: Line voltage (120VAC) 2. Turn ON/OFF switch to “ON” Low voltage transformer (19.5 minimum VAC) Power to module (24V Normal) ON/OFF switch Wiring connections Is there a spark across Unplug ignition lead and ignitor sensor gap? check spark at module (24VAC normal).
- Page 43 TROUBLESHOOTING GENERAL TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE ACTION 1. Glass Soots A. Flame impingement on logs A. Install log set per the instructions Inspect the injector and air intake area. Make sure this area does not have any blockage from debris and clean. Check gas supply.
-
Page 44: Replacement Parts
ILLUSTRATED PARTS LISTS FIREBOX COMPONENTS (CDVT33 CDVT36) (CDVR33 CDVR36) 69D0023... -
Page 45: Illustrated Parts Lists
ILLUSTRATED PARTS LISTS FIREBOX COMPONENTS Item Description CDVT33 CDVR33 CDVR36 CDVT36 Standard Features Junction Box Assembly 26D2128K 26D2128K 26D2128K 26D2128K Black Louver 54D0246 54D0246 26D0695 26D0695 Glass Frame Assembly 69D0238 69D0238 69D0028 69D0028 Factory Installed Service Parts Brass Louver 54D0249K... -
Page 46: Standing Pilot - Millivolt Control Engine
ILLUSTRATED PARTS LISTS STANDING PILOT — MILLIVOLT CONTROL 11,12,13, 14 69D0023... - Page 47 ILLUSTRATED PARTS LISTS STANDING PILOT – MILLIVOLT CONTROL Item Description CDVR33NV CDVR33PV CDVR36NV CDVR36PV CDVT33NV CDVT33PV CDVT36NV CDVT36PV Gas Valve 37D0117 37D0118 37D0117 37D0118 37D0117 37D0118 37D0117 37D0118 Assembly Pilot Assembly 37D0018 37D0019 37D0018 37D0019 37D0018 37D0019 37D0018 37D0019 Replacement 37D1067 37D1067 37D1067...
-
Page 48: Electronic Ignition Engine
ILLUSTRATED PARTS LISTS ELECTRONIC IGNITION Item Description CDVR33NE CDVR33PE CDVR36NE CDVR36PE CDVT33NE CDVT33PE CDVT36NE CDVT36PE Gas Valve 37D0016 37D0017 37D0016 37D0017 37D0016 37D0017 37D0016 37D0017 Assembly Pilot Assem- 37D0020 37D0021 37D0020 37D0021 37D0020 37D0021 37D0020 37D0021 Burner Tube 54D0288 54D0288 69D0083 69D0083 54D0288... -
Page 49: Logs
ILLUSTRATED PARTS LISTS LOGS CDVR33 and CDVT33 CDVR36 and CDVT36 Item Description Rear Log 54D0121 54D0181 Right Log 54D0147 54D0116 Left Log 54D0146 54D0115 69D0023... -
Page 50: Vent Components
ILLUSTRATED PARTS LIST VENT COMPONENTS Qty/ Simpson Selkirk P/N Item Box Description Duravent MHS P/N Simpson Horizontal High Wind Termination Cap 4DT-HC Horizontal Square Termination Cap with Built-In Vinyl Siding Standoff, Heat BHRTK Deflector and Firestop Horizontal Rigid Pipe Termination Kit with Horizontal Termination Cap with Built-In Vinyl Siding Standoff, Heat Deflector, Firestop, 90°... -
Page 51: Massachusetts Requirements
Massachusetts Residents Only — Please read and follow these special requirements 2. Approved Carbon Monoxide Detectors. Each carbon monoxide NOTE REGARDING VENTED PRODUCTS detector as required in accordance with the above provisions shall This product must be installed by a licensed plumber or gas fitter comply with NFPA 720 and be ANSI/UL 2034 listed and IAS when installed within the Commonwealth of Massachusetts. -
Page 52: Limited Lifetime Warranty Policy
LIMITED LIFETIME WARRANTY POLICY LIFETIME WARRANTY The following components are warranted for life to the original owner, subject to proof of purchase: Firebox, Combustion Chamber, Heat Exchanger, Grate and Stainless Steel Burners. FIVE YEAR WARRANTY The following components are warranted five (5) years to the original owner, subject of proof of purchase: Ceramic Fiber Logs.
