Q U I C K - S T A R T I N S T R U C T I O N S
Wireless radiator thermostat set
Order no.: 56 18 00
Q U I C K - S T A R T I N S T R U C T I O N S
Please perform the following steps for commissioning and operation in the indicated order.
For a detailed description of the individual steps and additional information, please read the included main instructions for the product.
Wireless Actuator Assembly
The batteries must not be inserted before assembly!
Inserting batteries into the wireless actuator
Inserting batteries into the wireless basis station
When the batteries are inserted, the wireless basis station will establish contact with the wireless actuator immediately. The flashing reception symbol ((
permanently after successful reception.
Mounting the wireless basis station on the table holder
Wall mounting of the wireless basis station
Remove the old thermostat and install the wireless actuator on the radiator valve instead. Use one of the
enclosed valve adapters if necessary.
Mount the base plate of the cashing on the wall with the marked screw apertures. Then you can lock the other casing half on
the basic plate (also see Mounting the wireless basis station on the table holder).
1
The wireless actuator now automatically calibrates for the installed heating valve
(display shows AD) and then goes into reception operation for no more than 60
minutes (the reception icon ((
in the display flashes).
www.conrad.com
Version 02/11
in wireless actuator display lights

Advertisement

loading
Need help?

Need help?

Do you have a question about the 56 18 00 and is the answer not in the manual?

Questions and answers

Summary of Contents for Conrad 56 18 00

  • Page 1 Version 02/11 Wireless radiator thermostat set Order no.: 56 18 00 Q U I C K - S T A R T I N S T R U C T I O N S  Please perform the following steps for commissioning and operation in the indicated order.
  • Page 2 Time  If no button is pressed for 15 seconds during setting, programming must be restarted. Press TIME Set day with +/-. Press the button as indicated. Press SET to store. 1=Monday to 7=Sunday. Set hours with +/-. Press the button again. Set minutes with +/-.
  • Page 3 Times for day/night/sleep (continued) Press the button PROG. Use +/- to set the desired day or Press the button as indicated. days of the week (1-5, for example, is Mon-Fri) for the interval to be programmed. Start programming at 0:00 Set the time at which another Assign the desired mode to Press SET to store the settings.
  • Page 4 Keep the button TIME pressed until the key symbol appears in the display. To unlock, keep the button TIME pressed again until the key symbol disappears. These operating instructions are published by Conrad Electronic SE, Klaus- Conrad-Straße 1, D-92240 Hirschau/Germany.
