Unload the gasket.
Unscrew the bolts and unload the constant temperature set
from the cylinder cover.
11.6.2 Inspection
Inspect whether the cylinder cover is broken.
Inspect the flatness of the bottom surface of the cylinder.
Allowable limit：0.05mm.
Remove the carbon deposit on the cylinder cover
with a bamboo scraper.

11.7 Installation of the cylinder cover

Installation is conducted in the reverse order of disassembly.
constant temperature set
cylinder cover
nut
gasket
constant
temperature set
bolt
Testing gauge
gasket
temperature controller
- 94 -
ruler
cylinder cover
spark plug
