- Page 1 FastCam Outdoor Speed Dome Camera CC-9760 & CC-9760-I USER INSTRUCTION MANUAL Version: V1.2 Doc No.: 20051114001...
-
Page 2: About This Guide
A BOUT THIS GUIDE Conventions used in this guide To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual. CAUTION: Information to prevent damage to the components when trying to complete a task. NOTE: Tips and additional information to aid in completing a task. - Page 3 If light sources such as spot light cause burn-in on the display screen, part of image may discolor due to deterioration of color filter in CCD when changing aim of the camera etc. 5 Do not install this camera upside down. This camera is designed for mounting on the ceiling or wall.
- Page 4 DIMNSION Speed Dome Camera Wall Bracket...
- Page 5 CONNECTIONS DC12V Power Input Video Output RS485 data Aluminum Die Cast Housing Acrylic dome Camera Green RS485+ RS485 data Yellow RS485- Yellow & Green Blue Ground Brown + DC12V BNC Video output The camera has build in heater and fan for temperature control. If the temperature lower than 15º, the heater will be turned on automatically.
-
Page 6: Installation
INSTALLATION 1. Installing speed dome camera to the bracket using 4 piece M6 Screws. 2. Installing the bracket to an existing structure. ID address LED INDICATOR There are two LED on the Controller Board, the function description as below: Red LED：The LED will be on when connect to the power. Green LED：The LED will be flash when receive the control signal, otherwise the LED always on. -
Page 7: Setting Baud Rate
ID SETING 6 7 8 9 10 Unscrewing the screws to remove the cover of Speed dome that you will find out the Dip Switch. Please refer to Table 1 to setup the ID address by Dip Switch. SETTING BAUD RATE You can select the baud rate by the Dip Switch, please refer to the table as below: Dip Switch S 10... - Page 8 ID/ Switch … … … … … … … … … Table 1...
-
Page 9: System Configuration
SYSTEM CONFIGURATION Star configuration If you connect the cable on the “ Box “ of CC-9755. You must follow up: Connect O/R with RS-485+ A (Y); Connect S/L with RS-485- B (Z) Daisy Cain configuration ..ON OFF PRES CLOS CALL 1 2 3 SYSTEM KEYBOAR D... -
Page 10: Operation
OPERATION The speed dome camera can be controlled remotely horizontal and vertical movement. It is used with a system controller, separately. It is controlled remotely from the controller through a serial connection to the RS-485 connector using a twisted-pair cable. Preset Memory The preset memory function will memories camera positions and zoom, focus, etc. -
Page 11: Zoom Function
Zoom Function Press TELE the LCD displays Zoom Tele. Press WIDE the LCD displays Zoom Wide. Backlight Function To turn on Backlight function of camera: + PRESET To turn off Backlight function of camera: + CALL Auto Pan Scan Function The auto pan scan function allows you to have the camera move back and forth automatically with a preset speed between the 2 preset camera positions. -
Page 12: Specification
SPECIFICATION Item \Model CC-9760 High Sensitive 1/4" Sony Super HAD CCD Image Sensor Pixels Number NTSC: 811 x 508 / PAL: 795 x 596 Resolution 480 TV Lines S/N Ratio More Than 48dB (AGC Off) 1.0 Vp-p (75 Ohms, composite) Video Output 27X (F1.5) -
Page 13: Troubles Shooting
TROUBLES SHOOTING Problems Possible Causes Remedies Power supply damaged Replace or insufficient power No action and images Wrong connection of when power is switched Correct power supply Faults in engineering Remove circuits Mechanical fault Repair Abnormal self-inspection. Images Tilting camera Place uprightly with roaring sound of Insufficient electrical...
