- Page 1 SD-436R USER’S MANUAL VER. : 1.0 2012...
-
Page 2: Table Of Contents
Table of Contents 1 Precautions…. ………………………………………………………… 2 2 Features……... ………………………………………………………… 3 2.1 Built-in Decoder………………………………………………….. 3 2.2 Integrated Universal Speed Change Rotator………………… 3 2.3 Built-in High Definition Color Camera……………………….. 3 2.4 All-weather Outdoor Design…………………………………… 3 3 Technical Data ……………………………………………………….… 4 3.1 Technical Parameters of the High-speed Dome…………… 4 4 Installation Guide……………. -
Page 3: Precautions
1 Precaution 1. Transportation Security No heavy stress, violent vibration or water splash are allowed during transportation, storage. The unit should be transported in separated packing. In shipments of distributor and delivery of maintenance, any damages caused by integral packing are not covered by warranty. 2. -
Page 4: Features
2 Features 2.1 Built-in Decoder ● Power-off protection, no data loss ● 220 programmable presets ● 8 cruising tracks, each cruising track has 32 preset positions ● 8 pattern tours, each one with 180s memory ● RS-485 bus ● 8 groups of auto scan, the left and right boundary and scan speed can be set ●... -
Page 5: Technical Data
3 Technical Data 3.1 Technical Parameters of the High-speed Dome Model SD-436R Power Supply AC24V/2.5A Operating Temperature -35 ° C — — — — 60° C Operating moisture < 95% Power Consumption Communication RS-485 bus, Communication transmission speed 2400/4800/9600BPS Protocols... -
Page 6: Installation Guide
Camera Module Specification Items SD-436R Image Sensor 1/4" SONY Super HAD II (Double Scan)CCD NTSC:768(H)x494(V)/PAL:752x582(V) Picture Elements 700 TV Line(Max) Resolution Video Output 1Vp-p Composite Video(75 ) SYNC System Internal/External (V-Lock) 3.4mm~122.4mm, 1.6~F4.5 Lens Zoom 1152X, 36X Optical,32X Digital 50dB S/N Ratio Color :0.5lux... -
Page 7: Structure
4.2 Structure 4.3 Installation Size... -
Page 8: Installation Procedures
4.4 Installation Procedures *Notice: The wall must be thick enough to install the expansion screws and can bear 4 times the weight of the dome camera itself. (1) Bore 4 holes by using templates included on the wall. (2) Mount 4 expansion screws into the holes. (3) Put the cables through the bracket. - Page 9 (5) Attach the dome cover to the dome base with rope. (6) Set the dome address, system baud rate and protocol by configuring DIP switches SW1 and SW3 located on the side of dome body. The Plug-in on the dome body must be seated rightly with the socket on the dome base.
-
Page 10: Settings
with the dome cover. (8) Fix the dome cover with screws. (9)Cable Connection: 5 Settings 5.1 Interface... -
Page 11: Dome Address, Transmission Speed, Protocol Setting
5.2 Dome Address, Transmission Speed, Protocol Setting Before the dome is installed, the communication protocol, baud rate and dome address, should be confirmed. Set the DIP switch, keeping the setting consistent with the control system. The relative DIP switch site and connecting wires are diagramed below for reference. SW2: SW1:... - Page 12 *Notice: “1” means “on” status and “0” means “off” status. Protocol Setting Protocols Bit 1 Bit 2 Bit 3 PELCO_P PELCO_D PRESET … … … *Notice: The factory default protocol is PELCO_D Transmission Speed Setting Baud Rate 4 Bit 5 Bit 9600 4800 2400...
-
Page 13: The Osd Menu Setting
Address Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8 … … … … … … … … … 6 The OSD Menu Setting 6.1 Operation Method of the Menu The user can call upon preset position 95 to enter the setting interface of the OSD menu. After entering the setting menu, a row of information will be displayed as follows (the screen can only show a single-step item of the following menu): The operations will be implemented by commands as “Focus in/out”... -
Page 14: Osd Menu Tree
“Iris open”: Confirm “Iris close”: Cancel Note: While installing COP camera module after exiting the menu, please do not operate with iris open which may caused abnormal video, and it is suggested to adjust manually again or adjust in the camera menu. - Page 16 MOTION MAIN MENU MOTION ―――――――――――――― ―――――――――――――― <PRESET> LANGUAGE: ENGLISH <SCAN> <SYSTEM INFORMATION> <SEQUENCE> <DISPLAY SETUP> <PATTERN> <DOME SETTINGS> <ZONES> <CAMERA> <TIMING ACTION> <MOTION> <AUTO TRACKING> RESTART FACTORY DEFAULTS BACK EXIT HELP EXIT A. PRESET PRESET MOTION ―――――――――――――― ―――――――――――――― PRESET NO. : 001 ――――――――――――――...
- Page 17 “PRESS IRIS OPEN TO CONFIRM”will appear on the screen. Move the joystick to do PTZ move and press IRIS OPEN to confirm the preset you want. E1.DELETE Move the cursor to DELETE and press IRIS OPEN to delete the current preset position. B.SCAN SCAN MOTION...
- Page 18 Move the joystick upward and downward to select a speed scale, then press IRIS OPEN to confirm. The speed scale ranges from 1~30. C.SEQUENCE SEQUENCE MOTION ―――――――――――――― ―――――――――――――― SEQ NO. : 1 <PRESET> <SCAN> TITLE : SEQ 1 <SEQUENCE> START <PATTERN>...
- Page 19 SEQUENCE SEQUENCE ―――――――――――――― ―――――――――――――― SEQ NO. : 1 INTERVAL PRESET TITLE : SEQ 1 >> 0 0 2 START 0 0 1 - - - <SEQUENCE SET> - - - DELETE - - - - - - EDIT 0 0 3 BACK EXIT BACK...
- Page 20 press IRIS OPEN to confirm. B1. TITLE Move the cursor to TITLE and press IRIS OPEN to enter the edition mode of sequence title. C1.START MOVE the cursor to START and press IRIS OPEN to start the current Pattern. D1. <SET> Move the cursor to SET and press IRIS OPEN the enter pattern setting mode.
- Page 21 C1.<LEFT LIMIT> Move the cursor to <LEFT LIMIT> and press IRIS OPEN to start setting the left limit of the current zone. Then the sentence “PRESS IRIS OPEN TO CONFIRM”will appear on the screen. Move the joystick and press IRIS OPEN to confirm. E1.
- Page 22 C1.STOP Stop time of timing action. D1.MOTION Timing action modes: PRESET 1-8, SCAN 1-4, SEQUENCE 1-4, PATTERN 1-4 E1： ： ： ： ON/OFF Press IRIS OPEN to enable or disable the timing action F1： ： ： ： COPY User can copy a schedule to other 6 days in a week. G1.
-
Page 23: Dome Setting
*Notice: The auto tracking function is only for the speed dome with the camera module which support auto tracking DOME SETTING MAIN MENU DOME SETTINGS ―――――――――――――― ―――――――――――――― <IDLE> LANGUAGE: ENGLISH <ALARM> <SYSTEM INFORMATION> <AUX> <DISPLAY SETUP> <PRIVACY MASK> <DOME SETTINGS> <CLOCK>... - Page 24 scan, sequence or none. B． ． ． ． ALARM ALARM SETTING DOME SETTINGS ―――――――――――――― ―――――――――――――― ALARM NO. <IDLE> INPUT STATE : CLOSE <ALARM> <AUX> ALARM MODE : OFF <PRIVACY MASK> TRIGGER ACTION : NONE <CLOCK> ALARM OUT : OFF/OUT1/OUT2/ALL <PASSWORD> CANCEL TIME : 10SEC <DOME TITLE>...
- Page 25 STOP TIME means the time for closing the alarm when the alarm mode is auto. C. AUX DOME SETTINGS ―――――――――――――― ―――――――――――――― <IDLE> AUX1: OFF <ALARM> AUX2: OFF <AUX> <PRIVACY MASK> <CLOCK> <PASSWORD> <DOME TITLE> <OTHERS> BACK BACK EXIT EXIT Move the cursor to open or close the AUX D.
- Page 26 B1.ENABLE Move the cursor to ENABLE to enable or disable the privacy mask zone. C1.<SET> .Move the cursor to <SET> and press IRIS OPEN to enter the edition mode of privacy mask zone. Then the sentence “PRESS IRIS OPEN TO CONFIRM” will be displayed on the monitor. Use joystick to move the dome to the area you want to cover and press IRIS OPEN to confirm.
- Page 27 PASSWORD DOME SETTINGS ―――――――――――――― ―――――――――――――― <IDLE> <EDIT PASSWORD> <ALARM> ENABLE : OFF <AUX> <PRIVACY MASK> <CLOCK> <PASSWORD> <DOME TITLE> BACK <OTHERS> EXIT BACK EXIT A1.EDIT PASSWORD The factory default password is 111111. The old password is needed before setting a new one. B1.ENABLE Enable or disable the password protection for OSD menu G.
- Page 28 OTHERS DOME SETTINGS ―――――――――――――― ―――――――――――――― <IDLE> TEMP CONTROL : COOL/AUTO/HEAT/OFF <ALARM> PRESET FREEZE : OFF <AUX> AUTO FLIP : ON <PRIVACY MASK> AUTO STOP TIME : 30SEC <CLOCK> MENU OFF TIME : 5MIN <PASSWORD> <NORTH SET> <DOME TITLE> <OTHERS> BACK BACK EXIT EXIT...
- Page 29 MAIN MENU CAMERA SETTING ―――――――――――――― ―――――――――――――― AUTO FOCUS : OFF LANGUAGE: ENGLISH DIGITAL ZOOM : OFF <SYSTEM INFORMATION> BACKLIGHT : OFF <DISPLAY SETUP> IMAGE FREEZE : OFF <DOME SETTINGS> ZOOM SPEED : LOW/ NORMAL/HIGH <CAMERA> DAY NIGHT : AUTO/BW/COLOR <MOTION> <ADVANCED>...
-
Page 30: Command List
E1.EXPOSURE F1.WIDE DYNAMIC *NOTICE: This item is only for the camera module with WDR function. COMMAND LIST Command Command packet Comments N N N N 0 0 0 0 Start Auto Scan Call_99 Start Auto Cruising Call_98 Start Pattern Tour Call_97 Stop checking/End... - Page 31 scan and Presetup right Preset_93 default Presetup No. 1 group; margin qq( speed value)：1-30 scan and Presetup left Preset_92 margin scan Presetup speed Preset_87 + Call_qq Start pattern tour Preset_86 Default as group 1 Presetting Finish pattern tour Call_96 Presetting Start cruising prePreset Preset_84 + Call_pp + …(n)Call_pp Pp: PrePreset number，n is up...
- Page 32 Number Presetting Call_80 Enable guard location Call_79 Stop guard location Preset_79 Enable alarm linkage Call_78 function Close alarm linkage Preset_78 function Pp function number：1-4 Preset guard location Preset_77 + Call_pp 1-prePreset position，default as No. 1； 2-Auto cruising ， default as No.1；...
-
Page 33: Trouble Shooting
Call_80 + Call_2 + Preset_66 + Preset maximum speed of x is Call_qq 12～18 Call_80 + Call_3 + Preset_66 + Preset maximum speed of y is Call_qq 12～15 Recover start angle default Call_80 + Call_1 + Call_66 volume of y is 0 degree recover maximum speed default Call_80 + Call_2 + Call_66 volume is 18 degree... - Page 34 Dome is dirty Change a certified power supply Fan does not rotate Fan is connected wrong Check it For more product information, Please visit us at www.AmebaCCTV.com...
