- Page 1 Harvest Grove Outdoor Kitchen Side Burner Instruction Manual...
- Page 2 Notes: If installing your side burner on an unstructured base, please ensure to follow these steps: • Excavate area approx. 9” below grade • Excavate approx. 6” larger than your actual kit dimensions to ensure a stable base.
- Page 3 1-piece ebony accent 4” x 4” x 12” quarry stone 1-piece ebony countertop propane line splitter kit slide-in double side burner (propane only) For any issues on Sunstone steel components or warranty claims, please call Texas BBQ Wholesalers at 888-934-9449 or email them at...
- Page 4 Note: Certain steps indicate the use of landscape glue. This is for added stability but it’s optional and at the discretion of the user. STEP 1 Lay down the stone pattern shown using 12” standard pieces. Check that stones are level at every step. Use included shims for adjustments. If installing with the bbq grill, do so on the right-hand side of the bbq.
- Page 5 STEP 3 Repeat the pattern from Step 1. STEP 4 Lay down the stone pattern shown using 12”, 8”, and 4” standard pieces.
- Page 6 STEP 5 Repeat the pattern from Steps 1 & 3. STEP 6a Repeat the pattern from Step 4. Refer to Step 6b if installing beside the bbq grill.
- Page 7 STEP 6b If installing side burner beside the outdoor grill, lay down the stone pattern shown of 12”, 8” and 4” standard pieces. STEP 7 Lay down the 1-piece ebony accent band as shown, and make sure it is level. Glue...
- Page 8 STEP 8 Lay down the stone pattern shown using 12”, 4” standard and 4”x4”x12” pieces. STEP 9 Lay down the stone pattern shown using 12”, 4” standard and 4”x4”x12” pieces. Make sure that all pieces on this layer are level to receive the countertop.
- Page 9 Lay down the 1-piece ebony countertop as shown, and make sure it is level. Glue this down to the quarry stone below. STEP 11 Place the slide-in double side burner into the space provided. Refer to the Sunstone manual included with the slide-in double burner for proper use and installation.
- Page 10 PROPANE LINE SPLITTER KIT INSTALLATION (PROPANE KIT ONLY) STEP 1 Attach the longer hose (with 90-degree elbow) onto the side burner. STEP 2 Pull the shorter hose and T-Connection with shut-off valve through the hole left between BBQ Grill and Side Burner onto the BBQ Grill side.
- Page 11 Attach the shorter hose onto the BBQ Grill. STEP 4 Attach the regulator hose included with the BBQ or Side Burner onto the open threaded end of the T-Connection with shut-off valve. Refer to the Sunstone manual included with the 4 Burner Grill 34 IR for Leak...
- Page 12 Harvest Grove Outdoor Kitchen Kits BARKMAN CONCRETE LIMITED Steinbach Office 152 Brandt Street, Steinbach, MB R5G 0R2 T 204 326 3445 or 1 800 461 2278 F 204 326 5915 steinbach@barkmanconcrete.com Winnipeg Office 909 Gateway Road, Winnipeg, MB R2K 3L1...
