Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However, your
overall safety can be increased by
proper installation ... and thought-
ful operation on your part. DO
NOT INSTALL, OPERATE OR
REPAIR THIS EQUIPMENT
WITHOUT
READING
THIS
MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED
THROUGHOUT. And, most
importantly, think before you act
and be careful.
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
RETURN TO MAIN MENU
EAGLE
10,000
For Machines with Code Number: 11096
R
C
US
OPERATOR'S MANUAL
• World's Leader in Welding and Cutting Products •
Copyright © 2005 Lincoln Global Inc.
IM830
November, 2005

Advertisement

Table of Contents
loading

Summary of Contents for Lincoln Electric EAGLE IM830

  • Page 1 EAGLE For Machines with Code Number: 11096 Safety Depends on You Lincoln arc welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation ... and thought- ful operation on your part. DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT...
  • Page 2: California Proposition 65 Warnings

    351040, Miami, Florida 33135 or CSA Standard W117.2-1974. A Free copy of “Arc Welding Safety” booklet E205 is available from the Lincoln Electric Company, 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199. BE SURE THAT ALL INSTALLATION, OPERATION, MAINTENANCE AND REPAIR PROCEDURES ARE PERFORMED ONLY BY QUALIFIED INDIVIDUALS.
  • Page 3: Electric Shock Can Kill

    ELECTRIC SHOCK can kill. 3.a. The electrode and work (or ground) circuits are electrically “hot” when the welder is on. Do not touch these “hot” parts with your bare skin or wet clothing. Wear dry, hole-free gloves to insulate hands.
  • Page 4 WELDING SPARKS can cause fire or explosion. 6.a. Remove fire hazards from the welding area. If this is not possible, cover them to prevent the welding sparks from starting a fire. Remember that welding sparks and hot materials from welding can easily go through small cracks and openings to adjacent areas.
  • Page 5 PRÉCAUTIONS DE SÛRETÉ Pour votre propre protection lire et observer toutes les instructions et les précautions de sûreté specifiques qui parraissent dans ce manuel aussi bien que les précautions de sûreté générales suiv- antes: Sûreté Pour Soudage A L’Arc 1. Protegez-vous contre la secousse électrique: a.
  • Page 6 This statement appears where the information must be followed to avoid minor personal injury or damage to this equipment. for selecting a QUALITY product by Lincoln Electric. We want you to take pride in operating this Lincoln Electric Company product •••...
  • Page 7: Table Of Contents

    Auxiliary Power While Welding, Standby Power Connections ...A-8 Premises Wiring ...A-9 ________________________________________________________________________________ Operation...Section B Safety Precautions ...B-1 General Description...B-1 Welder Controls Function and Operation ...B-1 Range and Control Switch...B-2 Start in/Shutdown Instructions ...B-3 Starting the Engine...B-3 Safety Precautions ...B-3 Stopping the Engine ...B-3 Break-In Period ...B-3...
  • Page 8: Installation

    (K2343-1) Engine. Kohler Aluminum Alloy CH20S with Cast Iron Liners, Electronic Start RATED OUTPUT @ 104°F (40°C) - WELDER RATED OUTPUT @ 104°F (40°C) - GENERATOR HEIGHT WIDTH 30.3 in. 19.1 in. 770 mm 485 mm 1. Output rating in watts is equivalent to volt - amperes at unity factor.Output voltage is within +/-10% at all loads up to rated capacity.
  • Page 9: Safety Precautions

    To prevent dangerous electric shock, other equip- ment to which this engine driven welder supplies power must: • be grounded to the frame of the welder using a grounded type plug, or be double insulated. Do not ground the machine to a pipe that carries explosive or combustible material.
  • Page 10: Fuel

    Listed below are copper cable sizes recommended for the rated current and duty cycle. Lengths stipulated are the distance from the welder to work and back to the welder again. Cable sizes are increased for greater lengths primari- ly for the purpose of minimizing cable voltage drop.
  • Page 11: Angle Of Operation

    Also, locate the welder so that engine exhaust fumes are properly vented to an outside area.
  • Page 12 For electrode Positive, connect the electrode cable from the LN-25 to the "+" terminal of the welder and work cable to the "-" terminal of the welder. For electrode Negative, connect the elec- trode cable from the LN-25 to the "-" terminal of the welder and work cable to the "+"...
  • Page 13 120/240 VOLT DUAL VOLTAGE RECEPTACLE The 120/240 volt receptacle can supply up to 38 amps of 240 volt power to a two wire circuit, up to 38 amps of 120 volts power from each side of a three wire cir- cuit (up to 76 amps total).
  • Page 14 ELECTRICAL DEVICE USE WITH THE EAGLE 10,000. Type Resistive Capacitive Inductive Capacitive/Inductive The Lincoln Electric Company is not responsible for any damage to electrical components improperly connect- ed to the EAGLE 10,000. INSTALLATION TABLE lll Common Electrical Devices Heaters, toasters, incandescent light bulbs, electric range, hot pan, skillet, coffee maker.
  • Page 15 AUXILIARY POWER WHILE WELDING Simultaneous welding and power loads are permitted by following Table I. The permissible currents shown assume that current is being drawn from either the 120V or 240V supply (not both at the same time). Also, the “Output Control” is set at “10” for maximum auxiliary power.
  • Page 16: Premises Wiring

    CONNECTION OF EAGLE 10,000 TO PREMISES WIRING 240 VOLT POWER 240 Volt 60 Hz. COMPANY 3-Wire Service METER DOUBLE POLE DOUBLE THROW SWITCH RATING TO BE THE SAME AS OR GREATER THAN PREMISES SERVICE OVERCURRENT PROTECTION. 50 AMP, 120/240 VOLT PLUG NEMA TYPE 14-50 50 AMP, 120/240 VOLT RECEPTACLE...
  • Page 17: Operation

    • Insulate yourself from work and ground • Always wear dry insulating gloves. • Always operate the welder with the hinged door closed and the side panels in place. • Read carefully the Safety Precautions page before operating this machine. Always follow...
  • Page 18 “ Process STICK/TIG (constant current) (3 range settings) Never change the “RANGE” Switch setting while welding. This will damage the switch. ------------------------------------------------------------------------ “ Provides a fine welding current adjustment within the Range Switch settings. EAGLE 10,000 APPROXIMATE FUEL CONSUMPTION Low Idle - No Load 2200 RPM High Idle - No Load 3700 RPM...
  • Page 19: Start In/Shutdown Instructions

    STARTING/SHUTDOWN INSTRUCTIONS STARTING THE ENGINE WARNING • Do not touch electrically live parts of electrode with skin or wet clothing. • Keep flammable material away. • Insulate yourself from work and ground. Wear eye, ear, and body protection. • Keep your head out of the fumes. •...
  • Page 20: Welding Process

    WELDING PROCESS For any electrodes the procedures should be kept within the rating of the machine. For electrode infor- mation see the appropriate Lincoln publication. Stick (Constant Current) Welding Connect welding cables to the “+” and “-” studs. Start the engine. The “RANGE” switch markings indicate the maximum current for that range as well as the typ- ical electrode size for that range.
  • Page 21: Summary Of Welding Processes

    CONTROL CABLE PROCESS USED STICK WIRE FEED, LN-25 WITH INTERNAL CONTACTOR TIG, TIG MODULE WITH WITH CONTACTOR KIT CONTROL CABLE, & ARC START SWITCH WIRE FEED, LN-15 ACROSS the ARC (has internal contactor) TYPICAL CURRENT RANGES Tungsten Electrode DCEN (-) DCEP (+) Diameter in.
  • Page 22: Accessories

    OPTIONAL EQUIPMENT K957-1 HEAVY DUTY, TWO WHEEL TRAILER FOR SMALL WELDERS - For road, off-road and in-plant and yard towing. (For highway use, consult applicable federal, state and local laws regarding requirements for brakes, lights, fenders, etc.) Order K957-1 Trailer K958-1 Ball Hitch K958-2 Lunette Eye Hitch K959-2 Fender &...
  • Page 23: Recommended Equipment

    PLASMA CUTTING K1580-1 Pro-Cut 55 Cuts mild steel using the 3-phase AC generator power from the engine driven welder. Accepts 3-phase or 1- phase input power. Requires the K1816-1 Full KVA adapter kit, if connected for 1-phase input power. EAGLE 10,000...
  • Page 24: Maintenance

    SAFETY PRECAUTIONS WARNING Have qualified personnel do the maintenance work. Turn the engine off before working inside the machine. In some cases, it may be necessary to remove safety guards to perform required maintenance. Remove guards only when necessary and replace them when the mainte- nance requiring their removal is complete.
  • Page 25: Oil Filter Change

    Use 4-stroke motor oil that meets or exceeds the requirements for API service classification SG or SH. Always check the API SERVICE label on the oil con- tainer to be sure it includes the letters SG or SH. SAE 10W-30 is recommended for general, all-tempera- ture use, -5 F to 104 F (-20 C to 40 C).
  • Page 26: Engine Adjustments

    • CONNECTING A BATTERY CHARG- ER - Remove battery from welder by disconnecting negative cable first, then positive cable and battery clamp. When reinstalling, connect negative cable last.
  • Page 27: Troubleshooting

    HOW TO USE TROUBLESHOOTING GUIDE Service and Repair should only be performed by Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on this equipment may result in danger to the technician and machine operator and will invalidate your factory warranty. For your safety and to avoid Electrical Shock, please observe all safety notes and precautions detailed throughout this manual.
  • Page 28 Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) No welder or output power. Engine will not idle down to low speed. Engine will not go to high idle when attempting to weld. If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
  • Page 29 Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) Engine will not go to high idle when using auxiliary power. Engine will not crank or is hard to crank. Engine shuts down. Engine does not develop full power. Engine is hard to start. If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
  • Page 30 DIAGRAMS 200A EAGLE 10,000 Enhanced Diagram...
  • Page 31 DIAGRAMS EAGLE 10,000...
  • Page 32 DIAGRAMS EAGLE 10,000...
  • Page 33 NOTES EAGLE 10,000...
  • Page 34 ● WARNING ● Spanish ● AVISO DE PRECAUCION ● French ● ATTENTION ● ● German WARNUNG ● Portuguese ● ATENÇÃO ● Japanese Chinese Korean Arabic ● ● ● ● ● ● ● ● ● ●...
  • Page 35 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● Spanish ● PRECAUCION French ● ATTENTION ● German WARNUNG Portuguese ● ● Japanese Chinese Korean Arabic WARNING AVISO DE ATENÇÃO...
  • Page 36 • World's Leader in Welding and Cutting Products • • Sales and Service through Subsidiaries and Distributors Worldwide • Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com...
