REF.NO.
PART NO.
D0004
645 081 8813 DIODE SK34
F0001
645 081 9063 FUSE
IC004
645 081 8806 TRANSISTOR SI9435A
IC005
645 081 8806 TRANSISTOR SI9435A
Q0001
645 079 9860 TRANSISTOR DTC144EKA
Q0002
645 079 9860 TRANSISTOR DTC144EKA
U0002
645 081 8769 IC BQ2057C
U0003
645 081 8790 TRANSISTOR FDS9926F
U0005
645 081 8776 IC S8232B
Z0001
645 079 9938 DIODE ZENER 9.1V
645 081 9100 LED
645 081 9445 LED SUPPORT,FOR LED
DVD MAIN P.W.BOARD ASSY
REF.NO.
PART NO.
20
614 334 7941 ASSY,PWB,DVD MAIN
CON01
645 075 8805 SOCKET 24P
CON02
645 075 8799 SOCKET 13P
CON03
645 076 9252 SOCKET 8P
D0001
645 075 8508 DIODE IN5819
D0002
645 068 5262 DIODE 1N4148
D0003
645 068 5262 DIODE 1N4148
D0004
645 068 5262 DIODE 1N4148
D0005
645 068 5248 DIODE ZENER 4.3V
D0006
645 075 8508 DIODE IN5819
D0007
645 075 8508 DIODE IN5819
D0008
645 075 8508 DIODE IN5819
D0011
645 076 9115 DIODE SK34
D0012
645 068 5262 DIODE 1N4148
D0013
645 068 5231 DIODE ZENER 15V
D0014
645 068 5262 DIODE 1N4148
F0001
645 076 9122 FUSE
J0004
645 068 5446 DC INPUT JACK
J0005
645 076 9283 SOCKET 18P
J0006
645 076 9245 SOCKET 7P,
J0007
645 068 5453 9P CONNECTOR,
J0012
645 075 8768 DIGITAL OUT JACK
J0015
645 076 9276 VIDEO IN OUT JACK
J0022
645 073 2164 HEADPHONE JACK
L0001
645 068 4869 MAGNET BEAD
L0002
645 075 8492 COIL 47UH
L0003
645 068 4913 MAGNET BEAD 33OHM
L0004
645 076 9092 COIL 100UH
L0005
645 068 4913 MAGNET BEAD 33OHM
L0006
645 068 4913 MAGNET BEAD 33OHM
L0007
645 076 9061 MAGNET BEAD 33 OHM
L0008
645 076 9085 COIL 47UH
L0009
645 068 4913 MAGNET BEAD 33OHM
L0011
645 068 4913 MAGNET BEAD 33OHM
L0012
645 068 4913 MAGNET BEAD 33OHM
L0013
645 075 8324 CHIP CHOKE 1.8 UH
L0014
645 075 8492 COIL 47UH
L0015
645 068 4913 MAGNET BEAD 33OHM
L0017
645 068 4913 MAGNET BEAD 33OHM
L0018
645 068 4913 MAGNET BEAD 33OHM
L0019
645 075 8324 CHIP CHOKE 1.8 UH
L0020
645 076 9061 MAGNET BEAD 33 OHM
L0021
645 076 9108 COIL 47UH
L0022
645 068 4913 MAGNET BEAD 33OHM
L0023
645 075 8324 CHIP CHOKE 1.8 UH
L0024
645 068 4913 MAGNET BEAD 33OHM
L0025
645 068 4913 MAGNET BEAD 33OHM
L0026
645 075 8324 CHIP CHOKE 1.8 UH
L0029
645 068 4913 MAGNET BEAD 33OHM
L0031
645 068 4913 MAGNET BEAD 33OHM
L0035
645 076 9054 CHOKE 10UH
L0036
645 076 9054 CHOKE 10UH
L0045
645 068 4913 MAGNET BEAD 33OHM
L0046
645 068 4913 MAGNET BEAD 33OHM
L0047
645 068 4913 MAGNET BEAD 33OHM
L0048
645 068 4890 MAGNET BEAD CHIP 3.3
L0049
645 076 9054 CHOKE 10UH
DESCRIPTION
DESCRIPTION
FOR MONITOR MAIN PCB
FOR SPEAKER LEFT & RIGHT
REF.NO.
PART NO.
LED01
645 068 5163 LED
Q0002
645 068 5125 TRANSISTOR 3906
Q0003
645 075 8461 TRANSISTOR AO3407
Q0004
645 075 8478 TRANSISTOR 8550
Q0005
645 068 5118 TRANSISTOR 3904
Q0006
645 068 5118 TRANSISTOR 3904
Q0007
645 068 5118 TRANSISTOR 3904
Q0008
645 068 5118 TRANSISTOR 3904
Q0009
645 075 8478 TRANSISTOR 8550
Q0010
645 068 5125 TRANSISTOR 3906
Q0011
645 068 5125 TRANSISTOR 3906
Q0012
645 075 8461 TRANSISTOR AO3407
Q0013
645 068 5118 TRANSISTOR 3904
Q0014
645 075 8447 TRANSISTOR 2907
Q0015
645 068 5118 TRANSISTOR 3904
Q0016
645 068 5125 TRANSISTOR 3906
Q0019
645 068 5118 TRANSISTOR 3904
Q0020
645 068 5095 TRANSISTOR 2SB1182
Q0021
645 075 8454 TRANSISTOR 2SK3018
Q0022
645 068 5118 TRANSISTOR 3904
Q0023
645 075 8454 TRANSISTOR 2SK3018
Q0024
645 068 5118 TRANSISTOR 3904
Q0025
645 075 8461 TRANSISTOR AO3407
Q0026
645 068 5118 TRANSISTOR 3904
Q0027
645 068 5118 TRANSISTOR 3904
Q0028
645 075 8461 TRANSISTOR AO3407
Q0029
645 068 5118 TRANSISTOR 3904
Q0030
645 068 5118 TRANSISTOR 3904
Q0031
645 068 5125 TRANSISTOR 3906
Q0032
645 068 5118 TRANSISTOR 3904
Q0034
645 068 5095 TRANSISTOR 2SB1182
RN001
645 068 4678 CHIP RES 33OHM X4 +-5%
RN002
645 068 4678 CHIP RES 33OHM X4 +-5%
RN003
645 068 4678 CHIP RES 33OHM X4 +-5%
RN004
645 068 4678 CHIP RES 33OHM X4 +-5%
RP002
645 076 8903 SVR WHE 1022-C10K,VOLUME
SW001
645 068 5347 SWITCH TACT
SW002
645 068 5347 SWITCH TACT
SW004
645 076 9191 SWITCH TACT
SW016
645 076 9191 SWITCH TACT
U0001
645 075 8430 IC WM8714ED
U0002
645 068 4968 IC TDA2822
U0003
645 068 5019 IC BA5954
U0004
645 075 8423 IC 6849
U0005
645 075 8362 IC K4S641632H
U0006
645 075 8409 IC 4052
U0007
645 068 4999 IC C4558
U0008
645 075 8379 IC AAT1343
U0010
645 075 8393 IC AT24C02N
U0011
645 068 4975 IC ZA3020LV,DC-DC REGULATOR
U0012
645 075 8348 IC A29800
U0014
645 068 4999 IC C4558
U0015
645 075 8409 IC 4052
U0016
645 076 9078 IC MT1389QE
Y0001
645 068 5330 CRYSTAL 27MHZ
645 076 9344 LED SUPPORT,FOR LED01
645 068 5316 FUSE CHIP,FOR F1
645 076 9139 REMOTE VRM-5052,FOR REMOTE1
DVD KEY P.W.BOARD ASSY
REF.NO.
PART NO.
37
614 334 7965 ASSY,PWB,DVD KEY
SW001
645 081 8974 SWITCH TACT,MENU
SW002
645 081 8974 SWITCH TACT,OK
SW003
645 081 8974 SWITCH TACT,RIGHT
SW005
645 081 8974 SWITCH TACT,LEFT
SW006
645 081 8974 SWITCH TACT,DOWN
SW007
645 081 8974 SWITCH TACT,WIDE
SW009
645 081 8974 SWITCH TACT,PLAY
SW010
645 081 8974 SWITCH TACT,STOP
SW011
645 081 8974 SWITCH TACT,FF
SW012
645 081 8974 SWITCH TACT,REW
- 5 -
