- Page 1 ONVERTER RS232 <=> RS485 Operating instructions MAKE YOUR BUSINESS SAFE...
-
Page 2: Table Of Contents
SPECIFICATIONS __________________________________________6 Environmental conditions and type tests _____________________6 Main features ____________________________________________8 INSTALLATION ____________________________________________9 Mounting/removal ________________________________________9 Connections____________________________________________10 LED Indicators __________________________________________10 DIP switch settings ______________________________________11 FUNCTIONAL DESCRIPTION ______________________________13 Field of application ______________________________________13 APPLICATION EXAMPLE __________________________________15 SOCOMEC - Ref. : 874 666 B GB... -
Page 3: General Information
No maintenance is required provided that the equipment is used under the conditions specified. Introduction The RS232<=>RS485 converter has been designed to In this way, the converter can also be used to connect convert signals between an RS232/V.24 interface and equipment which has no handshaking signal. -
Page 4: Approvals And Conformity
Emission standard for residential environments FCC part 15 Class B EN 50121-4 Railway applications: immunity for signalling and telecommunications apparatus. IEC 62236-4 Railway applications: immunity for signalling and telecommunications apparatus. Safety EN 60950 IT Equipment SOCOMEC - Ref. : 874 666 B GB... -
Page 5: Declaration Of Conformity
Converter APPROVALS AND CONFORMITY RS232 <=> RS485 Declaration of conformity SOCOMEC - Ref. : 874 666 B GB... -
Page 6: Specifications
2 Kv rms 50Hz 1 Min. Signal ports to all other 3 Kv rms 50Hz 1 Min. Supply ports to all 2 Kv rms 50 Hz 1 Min. (@ rated voltage<60V) other SOCOMEC - Ref. : 874 666 B GB... - Page 7 PC / ABS Flammability class V-1 Dimensions LxHxD 35 x 121 x 119 mm Weight 0.19 kg Protection index IEC 529 Unit IP 21 Cooling Convection Mounting Horizontal on 35 mm DIN-Rail SOCOMEC - Ref. : 874 666 B GB...
-
Page 8: Main Features
Speed 1200 bit/s – 115.2 kbit/s Data format 7 or 8 bits, Odd, Even or None parity, 1 or 2 stop bit Connection 9 pin D-sub female DCE Transmission range 15 m SOCOMEC - Ref. : 874 666 B GB... -
Page 9: Installation
* Allow the correct space (Right/Left) to ensure correct operation across the full range of temperatures. 25 mm REMOVAL Press down on the black clip on the top of the unit. (See figure) SOCOMEC - Ref. : 874 666 B GB... -
Page 10: Connections
DC:Voltage + LED Indicators Status Description Operating Not operating Transmitted data: data received from local RS232 port No data transmitted Received data: data sent to the RS232 port No data received RTS signal active on RS232 interface RTS inactive CTS signal active on RS232 interface... -
Page 11: Dip Switch Settings
1 2 3 4 5 6 7 8 switches are not effective. RTS control 1 2 3 4 5 6 7 8 Transmitter always active 1 2 3 4 5 6 7 8 SOCOMEC - Ref. : 874 666 B GB... - Page 12 Speed: 9600 bit/s Data format: 10 bits 1 2 3 4 5 6 7 8 Bus format: 2 wire Termination and fail-safe on 1 2 3 4 Note: SW1: 8 not used. SOCOMEC - Ref. : 874 666 B GB...
-
Page 13: Functional Description
T– T– T– = Termination 32 connections max Note: T+/T– are not standard. Connection problems may be resolved by switching the + and – wires if the equipment does not operate correctly. SOCOMEC - Ref. : 874 666 B GB... - Page 14 • Do not drop, knock, or shake the unit: rough handling or use beyond the recommendations may cause damage to internal circuitry. • Do not clean the unit using harsh chemicals, cleaning agents or strong detergents. SOCOMEC - Ref. : 874 666 B GB...
-
Page 15: Application Example
Converter APPLICATION EXAMPLE RS232 <=> RS485 RS232 RS232 <=> RS485 RS485 Diris A40 RS485 ATyS 6m RS485 Countis RS485 Countis SOCOMEC - Ref. : 874 666 B GB... - Page 16 F - 67235 Benfeld Cedex - FRANCE Tél. +33 (0)3 88 57 41 41 - Fax +33 (0)3 88 74 08 00 scp.vex@socomec.com www.socomec.com This document is not a contract. SOCOMEC reserves the right to modify features without prior notice in view of continued improvement.
