- Page 1 BUILT-IN COOKING PR60HOBG Instructions for use Installation advice Before operating this cooktop, please read these instructions carefully KEEP IN A SAFE PLACE...
-
Page 2: Dear Customer
Dear Customer, Thank you for purchasing a Prestige Cooking Hob. The safety precautions and recommendations in these instructions are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Precautions And Rec- Ommendations
IMPORTANT PRECAUTIONS AND REC- TIPS FOR THE USER OMMENDATIONS During and after use of the cooktop, After having unpacked the appliance, certain parts will become very hot. Do check to ensure that it is not dam- not touch hot parts. aged. - Page 4 FEATURES Fig. 1.1 CAUTION: COOKING SPOTS If the burner is accidentally extin- 1. Auxiliary burner (A) - 1,00 kW guished, turn the gas off at the con- 2. Semirapid burner (SR) - 1,75 kW trol knob and wait at least 1 minute 3.
-
Page 5: Gas Burners
HOW TO USE THE GAS BURNERS GAS BURNERS LIGHTING THE BURNERS Gas flow to the burners is adjusted by To ignite the burners follow these turning the knob illustrated in fig. 2.1 instructions: which control the safety valves. – Lightly press and turn the knob (fig. Turning the knob so that the indicator 2.2) in an anti-clockwise direction up line points to the symbols printed on the... -
Page 6: Choice Of The Burner
CORRECT USE OF TRIPLE-RING CHOICE OF THE BURNER BURNER (Fig. 2.4a - 2.4b) On the control panel, near every knob, there is a diagram that indicates which Flat-bottomed pans should be placed burner is controlled by that knob. directly onto the pan-support. The suitable burner must be chosen according to the diameter and the When using a WOK always place the... -
Page 7: General Advice
CLEANING MAINTENANCE ENAMELLED PARTS Important: Before cleaning or carrying out All the enamelled parts must be cleaned any maintenance disconnect the with a sponge and soapy water or other appliance from the electrical sup- non-abrasive products. ply and wait for it to cool down. Dry preferably with a soft cloth. - Page 8 CORRECT POSITIONING OF THE PAN SUPPORTS Triple-ring burner Two burners pan support pan support Rear left burner pan support Fig. 3.1 CORRECT Fig. 3.2...
- Page 9 BURNERS CORRECT REPLACEMENT OF THE BURNERS The burners can be removed and washed with soapy water only. It is very important to check that the They will remain perfect if always burner flame distributor F and the cap C cleaned with products used for silver- has been correctly positioned (see figs.
- Page 10 TRIPLE RING BURNER The triple ring burner must be correctly positioned (see fig. 3.5); the burner rib must be enter in their logement as shown by the arrow. The burners must be correctly positioned so that they cannot rotate (fig. 3.6). Then position the cap A and the ring B (fig.
- Page 11 ADVICE INSTALLER FOR THE IMPORTANT The appliance should be installed, regulated and adapted to function with other types of gas by a QUALIFIED INSTALLATION TECHNICIAN. Failure to comply with this condition will render the guarantee invalid. The hob should only be installed by a C.O.R.G.I. registered installer. The appliance must be installed in compliance with regulations in force.
-
Page 12: Installation
INSTALLATION TECHNICAL INFORMATION FOR THE INSTALLER Before installing the hob, remove the protective film. In order to install the cooker top into the kitchen fixture, a hole with the dimensions shown in fig. 4.1 has to be made, bearing in mind the follow- ing: within the fixture, between the bot- tom side of the cooker top and the... - Page 13 INSTALLATION IN KITCHEN CABINET Fig. 4.3 WITH DOOR (fig. 4.3) It is recommended that a 30 mm clear- ance be left between the cooker top and the fixture surface (fig. 4.3). Clearance Door Space for connections FASTENING THE INSTALLATION BRACKETS (fig.
-
Page 14: Gas Section
GAS SECTION GAS INSTALLATION GAS CONNECTION IMPORTANT NOTE The installation of the gas hob to Natural Gas or LP Gas must be carried out by a This appliance is supplied for use on C.O.R.G.I. registered installer. Installers NATURAL GAS only and cannot be shall take due account of the provisions of used on any other gas without modifica- the relevant British Standards Code of... -
Page 15: Conversion To Lpg
CONVERSION TO LPG The burners are conceived in such a 1 - INJECTORS REPLACEMENT OF way so as not to require the regulation HOB BURNERS of the primary air. This appliance is manufactured for conversion to LPG. To purchase an LPG conversion kit telephone acces- sories direct 0870 6052020. - Page 16 TABLE FOR THE CHOICE OF THE INJECTORS Cat: 2H3+ G 30 - 28-30 mbar Nominal Reduced G 20 - 20 mbar G 31 - 37 mbar Power Power BURNERS Ø injectors Ø injectors [kW] [kW] [1/100 mm] [1/100 mm] Auxiliary (A) 1,00 0,30 72 (X)
-
Page 17: Minimum Burner Setting Adjustment
2 - MINIMUM BURNER SETTING ADJUSTMENT Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting. -
Page 18: Electrical Section
ELECTRICAL SECTION For your safety please read the following information Warning: This appliance must be earthed. The appliance must be connected to a 220-240 volts 50 cycle AC supply by means of a three pin socket, suitably earthed and should be protected by a 3 amp fuse in the plug. The appliance is supplied with a rewireable 13 amp 3 pin plug fitted with a 3 amp fuse. - Page 19 Your Prestige from COMET Your new Prestige product comes with 12-month guarantee covering all parts and labour. If your appliance proves to be defective as a result of faulty materials or workmanship during the guarantee COMET will repair or replace it free of charge.
- Page 20 Prestige ® is a registered trademark of Meyer Intellectual Properties Limited and is sold pursuant to a license. code 1102462 ß11...
