operator manual
Mini-Conveyor Toaster
Model ST-1
This document includes:
• Safety Notices
• Specifications
• Installation Instructions
• Operating Instructions
• Cleaning Instructions
• Warranty Statement
Revision: B
P/N: 07023
Merco Savory, LLC
1111 North Hadley Road
Fort Wayne, Indiana 46804
United States of America
Technical Support Hotline: (800) 678-9511
Telephone: (260) 459-8200
www.mercosavory.com
Advertisement
Table of Contents
Related Manuals for Savory Mini-Conveyor Toaster ST-1
Summary of Contents for Savory Mini-Conveyor Toaster ST-1
- Page 1 operator manual Mini-Conveyor Toaster Model ST-1 This document includes: • Safety Notices • Specifications • Installation Instructions • Operating Instructions • Cleaning Instructions • Warranty Statement Revision: B P/N: 07023 Merco Savory, LLC 1111 North Hadley Road Fort Wayne, Indiana 46804 United States of America Technical Support Hotline: (800) 678-9511 Telephone: (260) 459-8200...
-
Page 2: Important Warning And Safety Information
IMPORTANT WARNING AND SAFETY INFORMATION This manual contains important safety and installation-operation instructions. Require all operators to read this manual thoroughly before installing, operating or NOTE: servicing this equipment. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. To avoid electrical shock that can cause injury or death, always unplug the unit prior DANGER! to proceeding with any and all maintenance or cleaning procedures! -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Install the ST-1 in the most convenient location for ease of cleaning, maintenance and general operation. Avoid installing in locations with drafts, close proximity to grease or vapor-producing appliances or other high ambient heat equipment. Allow approximately 1” clearance on sides and back of unit for proper air circulation. Allow sufficient overhead clearance for proper heat dissipation. -
Page 4: Control Panel Features
CONTROL PANEL FEATURES MAIN POWER SWITCH This switch is located to the left of the panel and has three (3) positions: Stand-By, Off, and Full Power. It controls the power going to the conveyor system and the two (2) heating zones. When the switch is in the “Full” position, all available power is reaching the heating elements. -
Page 5: Cleaning Instructions
OPERATION INSTRUCTIONS (CONT’D) 7. When toaster is not in constant use, set switch to the “STAND-BY” position. When switching to this position, always come to a full stop at the “Off” position first to CAUTION: avoid damage to the switch. When returning to “Full”... - Page 6 SCHEMATIC 120V Unit SCHEMATIC 208/240V Unit ST-1 Mini-Conveyor Toaster Operator Manual...
- Page 7 LIMITED WARRANTY FOR COMMERCIAL PRODUCTS LIMITED WARRANTY Merco/Savory LLC, ("Merco”) warrants this product to be free from defects in material and workmanship for a period of: • One (1) year from the date the product is installed or eighteen (18) months from the date of shipment from our facility, whichever comes first.
- Page 8 ST-1 Mini-Conveyor Toaster Operator Manual...
