HOLOPHANE Predator Installation And Maintenance Manual

AFTER INSTALLATION DELIVER THIS
MANUAL TO OWNER

IMPORTANT SAFETY INSTRUCTIONS

WARNING
-READ THESE INSTRUCTIONS
CAREFULLY BEFORE ATTEMPTING TO INSTALL OR
MAINTAIN THIS FIXTURE.
BY QUALIFIED PERSONNEL.
WARNING
-BE CERTAIN THAT ALL ELECTRICAL
POWER IS DISCONNECTED FROM THE FIXTURE
BEFORE INSTALLING OR MAINTAINING THE FIXTURE.
WARNING
-FOLLOW LAMP MANUFACTURER'S
OPERATING AND MAINTENANCE INSTRUCTIONS.
FAILURE TO FOLLOW THESE WARNINGS MAY
RESULT IN DEATH, INJURY OR SIGNIFICANT
PROPERTY DAMAGE.

1. INTRODUCTION

1.1 Product Description.

designed and tested in accordance with UL844 and UL595. These
floodlights comply with applicable paragraphs of Sections 501, 502,
and 503 of the National Electrical Code.
•The fixture identification label provides information regarding
suitable environmental applications.
•The floodlight model size is referred to in Figure 1.
•Major components of the floodlight are identified in Figure 1.
•The Predator floodlights have been designed to allow permanent
installation of the yoke and housing while still providing easy
maintenance and repair.
•The lamp, all electrical components, and the reflector can be
accessed by opening the door.
•Using a socket wrench, the door can be opened by loosening
captive door screws.
Medium Floodlight Hazardous
WORK MUST BE DONE
The Predator floodlights have been
®
Predator
•All electrical components and the lens are contained on the door
and the door can be removed easily and without tools (once the
captive door screws are loosened).
•Doors can be replaced as units and repaired in a shop under
protected conditions.
•The reflector located within the housing can be replaced as
needed. Different types of reflectors will provide different light
distributions.
WHEN INSTALLING OR MAINTAINING EQUIPMENT IN
CLASS II LOCATIONS, PREVENT THE ACCUMULATION
OF THE COMBUSTIBLE DUST IN THE FIXTURE OR
COMPLETELY REMOVE SUCH DUST BEFORE
CLOSING THE FIXTURE.
ELECTRICAL POWER TO THE FIXTURES IN
HAZARDOUS LOCATIONS UNTIL THE FIXTURES HAVE
BEEN COMPLETELY INSTALLED AND PROPERLY
CLOSED. FAILURE TO FOLLOW THESE WARNING
INSTRUCTIONS MAY RESULT IN FIRE AND
SIGNIFICANT PROPERTY DAMAGE.

1.2 Alternate Information Sources.

questions arise relative to the Predator floodlight that this document
or your supplier cannot answer please refer them to:

1.3 Definition of Terms.

Class I, Div. 2 Flammable liquids or gases present in closed
containers or systems and only released accidentally or through
abnormal operation of equipment. Ignitable concentrations of gases
or vapors prevented by ventilation but potentially hazardous if
equipment failure occurs. Areas adjacent to Class I, Div 1.
Class II Combustible dust present or may be present as a result of
GR421
equipment failure.
Class III Easily ignitable fibers or flyings present but are not likely to
be in suspension in the air in sufficient quantities to produce
ignitable mixtures.

2. INSTALLATION

2.1 Tools and Materials Required.

and materials are required during installation of the Predator
floodlight.
TABLE 1. Installation Tools and Materials
DESCRIPTION
3/8" hex head socket wrench
Wrench for 3/4" hex
Wire nuts
Torque wrench
Installation and
Maintenance
Manual
WARNING
DO NOT CONNECT
If additional
Holophane
Field Service Department
P.O. Box 3004
Newark, OH 43058-3004
866-759-1577
The following tools
USE
Captive door screws
Captive door screw
Yoke Mount
IM-64-B
