The HH5i stove hasbeen exempted under the clean air act of 1993 as suitable for use in smoke control areas when
burning seasoned wood logs. The stove contains a factory fitted secondary air stop which ensures that the
secondary air is permanently open 3.5mm minimum. Please carefully read the instructions on wood burning
contained in this manual, these MUST be adhered to at all times. Please see page 15 of the manual for further
reference to the clean air act of 1993
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
For safety reasons it is essential that your stove is correctly installed and operated. Hothouse cannot
accept responsibility for any fault or consequential problems arising through incorrect installation or
operation.
INSERTSTOVE
Please fix label with serial number and stove
typehere before putting manual into stove
Installation and Operating
Instructions
Hothouse Inspired Products Ltd
Express Trading Estate
technical@hothouseproducts.co.uk
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
HH5i
Imperial Point
Stonehill road
Farnworth
Bolton BL4 9TN
Advertisement
Table of Contents
Related Manuals for HotHouse HH5i
Summary of Contents for HotHouse HH5i
- Page 1 The HH5i stove hasbeen exempted under the clean air act of 1993 as suitable for use in smoke control areas when burning seasoned wood logs. The stove contains a factory fitted secondary air stop which ensures that the secondary air is permanently open 3.5mm minimum.
-
Page 2: Table Of Contents
Notes on Wood Burning Notes on Burning Solid Fuel Re-fuelling Refuelling onto a Low Firebed Fuel Overloading Shutting down Maintenance Seasonal Use 7. Safety Notes for your Guidance 8. Stove Dimensions 9. Frequently Asked Questions 10. HH5i Spare Parts List & Codes HH5i12/09/13... -
Page 3: List Of Components
Fig 2 – HH5i Stove Assembly and controls 2. Component Identification and Installation Your Hothouse Stove comes packed in a cardboard box. Carefully remove any straps and remove all cardboard and any plastic packaging, open the door and remove all the contents. See Listof Components section and check contents carefully. -
Page 4: Installation Instructions
Create a seal with the fascia of the fireplace. Place hand through the stove flue collar and tighten the wingnut onto the tightening bar. The fixing bar creates pressure when it contacts the chimney/lintel. The stove should be tightly sealed to the fireplace fascia. Insulate the space between the fireback and the stove –... -
Page 5: Installation Information
Safety at Work Act 1974) and comply with the Health and Safety rules contained therein, and any new regulations introduced during the lifetime of these instructions. Handling Adequate facilities must be available for unloading and site handling. Hothouse Stoves are very heavily built so always ask for assistance when lifting and siting the stoves. Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. -
Page 6: Material Clearances
Hearths: Hothouse stoves require a 125mm thick non-combustible constructional hearth beneath them to protect the building, this can include any solid non-combustible floor. A non-combustible superimposed hearth forming an apron of at least 225mm at the front of the stove and 150mm on either side must also be provided. The superimposed hearth must not be less than 12mm thick and must have a clearly defined edge (change of level) to discourage placing of any combustible materials on or partially over it. -
Page 7: Technical Data
Advise the user on what to do should smoke or fumes be emitted into the room from the stove – see Safety Notes section. The user should be warned that they MUST use a suitable fireguard in the presence of children, aged and/or infirm persons. -
Page 8: Cleaning
open some way whilst burning unless the stove is being shut right down for a long period. Moving the sliding control towards the wide side of the arrow increases the burn rate whilst moving it towards the narrow side reduces it. Tertiary Air This appliance is also fitted with a preheated tertiary air system which burns otherwise uncombusted gases in the products of combustion thereby improving efficiency, increasing heat output and decreasing unwanted... -
Page 9: Notes On Burning Solid Fuel
Always make sure that flames are visible above the wood after re-fuelling for cleanest burning. Open the air wash full for 1 to 2 minutes to achieve full flames above the fuel.Carefully adjusting the secondary air controls and fuel load will then control the burn rate of the stove. Wood burns most efficiently with the primary air controls closed and the secondary (air wash) controls openabout 25%, this setting will give the stoves nominal output of approximately 5kW. -
Page 10: Shutting Down
Four good size logs is a sufficient quantity of fuel to achieve the rated output from this appliance. Never exceed this amount of fuel and never stack the fuel too high in the stove so as it touches the baffle or blocks the tertiary air holes as this may cause smoke to be produced. -
Page 11: Stove Dimensions
If the wall is becoming hot, move the furniture away. Ensure that the Fire Brigade can gain access to your roof space in order to check this area for signs of fire spread 8.0 Stove Dimensions Fig. 3 – HH5i Insert Stove All dimensions in mm unless otherwise stated. Dimensions are approximate and are subject to change without prior notice. -
Page 12: Frequently Asked Questions
A call out charge will apply if our engineer attends any stove problem that is not related to product failure. 6 Where can I get spare parts? Your local Hothouse Stove retailer will be pleased to supply spare parts and to provide any other information you require. -
Page 13: Hh5I Spare Parts List & Codes
10.0 HH5i Spare Parts List & Codes Component HH5i Component HH5i Door Glass Y1HHI04D01E Ashpan Y1HDID28E Glass Brackets and Screws Y1HDID02E Glove Y1HD29E Door Handle assembly Y1HHI04D03E Ashpan Tool Y1HD31E Coalcatcher Y1HDF04D04E Door Y1HHI04D32A Back Plate/fireboard Y1HDI04D05E Primary Air Control including handle... - Page 14 HH5i12/09/13...
-
Page 15: The Clean Air Act 1993 And Smoke Control Areas
Ltd Approval does not cover the use of other fuels either alone or mixed with the recommended fuels listed above, nor does it cover instructions for the use of other fuels. Hothouse Inspired Products Ltd, Imperial Point, Express Trading Estate,...
