Summary of Contents for Time Guard TS800B
- Page 1 24 HOUR PLUG-IN TIME CONTROLLER Cat. No TS800B...
- Page 2 TS800B 24 Hour Plug-In Time Controller Self- Time cancelling indicator override switch Setting pins Front socket Protective face lobes 24hr programme ring (inner holes = ON Tough flame outer holes = OFF) retardant casing...
- Page 3 1 To programme the controller:- a Decide what times you would like the Timecontroller to switch on and off. b Insert the setting pins into the programme ring according to your requirements. To switch ON insert the pins into the inner circle of holes. To switch OFF insert the pins into the outer circle of holes.
- Page 4 3 Turn the programme ring clockwise until the correct time of day is directly above the time indicator at the top of the front socket face (see diagram). 4 Plug the Timecontroller into a socket and switch socket ON if necessary. 5 Plug your appliance into the Timecontroller and switch the appliance 6 You can switch your appliance ON and...
- Page 5 Points to note a Each time the Timecontroller has carried out an automatic switching operation the manual switch cannot be operated for about 15 minutes before and after automatic switching because it is mechanically locked for this period. b If required you can programme your Timecontroller to switch off only by inserting just a single pin.
- Page 6 5 amp inductive rating. Certain washing machines require the power to be permanently connected and they cannot be controlled by the TS800B. This is also true of tumble dryers with push button start. Note: Minimum setting interval = 15 minutes.
-
Page 7: Specifications
Specifications Operating Temp: 0°C to 40°C Operating Voltage: 230V AC 50Hz Switch Rating: 230V AC 13 amp resistive (3kW) 5 amp inductive 400W Filament Lighting 100W Low Energy or any type of Fluorescent Lighting Conforms to Directives: 73/23/EEC & 89/336/EEC Not suitable for discharge lighting (eg SON or Halide) 3 Year Guarantee... - Page 8 HELPLINE 020-8450-0515 or email helpline@timeguard.com For a product brochure please contact: Timeguard Ltd. Victory Park, 400 Edgware Road, London NW2 6ND Tel: 020-8452-1112 or email csc@timeguard.com Group company 67-058-269...
