- Page 1 RAY 7R MOVING BEAM USER MANUAL...
-
Page 2: Table Of Contents
Control panel menu functions: 10 The Control Panel: 12 Function Table of DMX Control Channel 14 5. Trouble Shooting 17 6. Technical Specifications 19 2 Ray 7R Moving Beam – User manual... -
Page 3: Product Introduction
1. SUMMARY Thank you for purchasing our Ray 7R Moving Beam. Please read these instructions carefully before operating the system to avoid any possible damage or misuse. PRODUCT INTRODUCTION The Ray 7R Moving Beam is an ultra-quiet product that encompasses advanced stage light technology which is smart, efficient, and smooth to operate. -
Page 4: Safety Instructions
Immediately replace the lamp if it is damaged or deformed. o The products referred to in this manual conform to the European Community Directives to which they are: o Low Voltage 2006/95/CE o Electromagnetic Compatibility 2004/08/CE 4 Ray 7R Moving Beam – User manual... -
Page 5: Product Diagram
Gobo wheel: 17 fixed gobos + white circle; o Prism wheel: includes an eight-prism, and can rotate in both a positive and negative direction with 16 macro functions; o Dimming :0%~100% Linear dimming; 5 Ray 7R Moving Beam – User manual... -
Page 6: Installation
There are transport protection locks on the X and Y axis to facilitate installation and removal. The specific method is as shown below. X-axis of the lock-bit pattern (2) Y-axis of the lock-bit pattern (3) 6 Ray 7R Moving Beam – User manual... -
Page 7: Device Power
7. Unlock the protection lock after the installation to avoid damaging the fixture DEVICE POWER Fuse: Power supply Fuse 200-250V 5A ( main fuse) 100-120V 7A （main fuse） 7 Ray 7R Moving Beam – User manual... -
Page 8: Light Bulb Instructions
Y-axle locked. 2. Screw off the four cross screws of the 4*12 type on the top. 3. Screw off the three wires of the speed fan of 80*80 type. 8 Ray 7R Moving Beam – User manual... -
Page 9: Operating And Control Methods
This is convenient whilst the fixture is hanging upside down! Please note that when upside down, the S and E function key will be opposite 9 Ray 7R Moving Beam – User manual... -
Page 10: Control Panel Menu Functions
4.Lamp on via DMX Light English 5.Lamp off via DMX Mode Light 6.Reset via DMX Time 7. Lamp on by powon Display Inverse 10 Lamp off if no DMX Ray 7R Moving Beam – User manual... - Page 11 6.Test control values 3.Adj 1.Lamp 2.Reset on or Function 2.Run program values Reset Lamp on 7.Advanced Reset Access code Lamp off Effect _ _ _ _ Reset Pan/Tilt 11 Ray 7R Moving Beam – User manual...
-
Page 12: The Control Panel
(For hanging lamps ) Lamp on via ON /OFF Choose to use the control table to open the bulb Lamp off ON /OFF Choose to use the control 12 Ray 7R Moving Beam – User manual... - Page 13 Motor Correct stepper motor site _ _ _ _ correction to bring out the full potential of the equipment (the function is suitable for persons familiar with stage 13 Ray 7R Moving Beam – User manual...
-
Page 14: Function Table Of Dmx Control Channel
Strobe (quick close)fast->slow Linear 161-166 Turn on Single step 136-160 Strobe (quick start)fast->slow Linear 128-135 Turn on Single step 72-127 Symmetry strobe slow->fast Linear 64-71 Turn on Single step 14 Ray 7R Moving Beam – User manual... - Page 15 5seconds 0—25 Free CH17 The speed of DMX value Effect Attribute XY axle 251-255 The Fastest Linearity 1-250 Speed Linear reduction Linearity The Fastest Linearity 15 Ray 7R Moving Beam – User manual...
- Page 16 Do NOT use solvent or alcohol. 6. Deliver the light to professionals to apply a routine maintenance after one year of use. 16 Ray 7R Moving Beam – User manual...
-
Page 17: Trouble Shooting
D. Check whether the plug-in on the PCB and IC components is loose, has poor connection or is damaged. E. Check whether the power output voltage suitable F. Motor or PCB is damaged 17 Ray 7R Moving Beam – User manual... - Page 18 A. The set may have a poor connection because of the vibration during The set cannot be the transportation. Check the panel started Note: Seek advice from a professional prior to authoring any repairs 18 Ray 7R Moving Beam – User manual...
-
Page 19: Technical Specifications
IP protection grade :IP20 o Electric ballast AC/DC power supply o Flight case size : 75CM （length）×46CM （width）×69CM（height） o 2Sets within one case ,face up . o Net weight ：19.5KG 19 Ray 7R Moving Beam – User manual...
