Lava Rock Natural Gas Fire Bowl
!
If the information in this manual is not
followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
Installation and service must be
!
performed by a qualified installer,
service agency or gas supplier.
Improper installation, adjustment,
!
alteration, service or maintenance can
cause injury or property damage.
!
DANGER
If you smell gas:
away from the appliance and
immediately call your gas supplier
Restoration Hardware Customer Service: 1-800-816-0901
For Technical Support
Please Contact Us At:
Warning:
!
!
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
!
Save these instructions for future
reference. If you are assembling
this unit for someone else, give
!
this manual to him or her to read
and save for future reference.
!
WARNING
Do not store or use gasoline or other
vicinity of this or any other appliance.
This unit not for use with propane.
Use only with Natural gas.
1-800-654-1704
Advertisement
Table of Contents
Related Manuals for Restoration Hardware Lava Rock
Summary of Contents for Restoration Hardware Lava Rock
- Page 1 Style # 26100182 Lava Rock Natural Gas Fire Bowl For Technical Support Engineered and Please Contact Us At: Manufactured by: 1-800-654-1704 Warning: IMPORTANT SAVE THESE If the information in this manual is not Read the installation, operation followed exactly, a fire or explosion...
-
Page 2: Table Of Contents
such as a camper,tent,car or home. Table of Contents Important Safety Information Natural Gas Warnings Parts List and Descriptions Pre-Use Instructions Insert Lava Rock Install Battery in Igniter Connecting/ Disconnecting the Gas Supply Lighting Care and Cleaning Gas Component Connection Checks... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING FIRE BOWL IS FOR OUTDOOR USE ONLY WARNING NOT FOR USE WITH LIQUID PROPANE IF YOU SMELL GAS: Shut o gas supply to the fire bowl. Extinguish any open flame. o not try lighting any appliance. Do not touch any electrical switch;... - Page 4 IMPORTANT SAFETY INFORMATION (Continued)
-
Page 5: Natural Gas Warnings
IMPORTANT SAFETY INFORMATION (Continued) DANGER NATURAL GAS DANGERS AND WARNINGS... - Page 6 NATURAL GAS DANGERS AND WARNINGS (Continued) Never store or use gasoline or other volatile substance in the vicinity of this fire bowl. Natural Gas Connection the type resistant to the action of Natural Gas on all male pipe threads. Connect the end, with the Caution: During any high pressure testing of the gas supply piping system at test pressures in excess of 1/2 psi (3.5 kPa), your gas fire bowl and its individual shuto valve must be disconnected...
-
Page 7: Parts List And Descriptions
Parts List Fire Bowl 05633101 Small Lava Rock 05603408 Large Lava Rock 05633403A Natural Gas Hose and Quick Connect 056NG010 AAA Battery 00500000... -
Page 8: Pre-Use Instructions
Pre-Use Instructions WARNING Before using this outdoor fire bowl, make sure you have read, understand and are following all information provided in the Important Safety Information section of this manual. Failure to follow those instructions can cause death, serious injury or property damage. Prior to each gas fire bowl opration, check the hose and valve for evidence of excessive abrasion or wear through the visual check hole on the side of the base. -
Page 9: Insert Lava Rock
Next place the Large Lava Rock 19kgs (2b) around the perimiter of the fire bowl and across the top of the small lava rock. Make sure that you do not block the igniter box with lava rock to ensure proper ignition. -
Page 10: Connecting/ Disconnecting The Gas Supply
Connecting your fire bowl to the Natural Gas source: recommended by the National Fuel Gas Code. Socket connection must be made outdoors. Shut-o Valve Connecting the Socket Coat the gas supply pipe nipple with gas resistant pipe compound or approved teflon tape. Screw socket onto gas supply pipe (house gas source) as shown to the right, and wrench tighten. -
Page 11: Lighting
Lighting Instructions Using the Igniter 1. Read and understand all operating instructions before lighting. Ensure that all protective film has been removed from stainless burn tray prior to lighting. 2. Burner control knob must be in the “OFF” position. 3. Connect Natural Gas source (see above pages). 4. -
Page 12: Care And Cleaning
6. If damage to any component is detected, DO NOT operate until the proper repairs have been made. WARNING DO NOT tamper with this appliance. This is DANGEROUS and will void the warranty. Any part found to Real Flame at: 1-800-654-1704. For replacement parts contact Restoration Hardware at: 1-800-816-0901. General Care and Cleaning ARNING cool to the touch. -
Page 13: Gas Component Connection Checks
Gas Component Connection Checks If the burner will not light or stay lit, please perform the following checks. 1. Make sure the electrode wire is correctly connected. Both electrode wires must be fully inserted into the igniter box. 2. Make sure that the pilot housing is unobstructed. Clear any debris on top of the pilot housing and make sure there is no debris between the igniter pin, thermocouple and the burner tube. - Page 14 Gas Component Connection Checks (Cont.) Thermocouple Igniter Pin 3. Make sure that the igniter pin and thermocouple are correctly positioned. - The igniter pin should be pointed straight to the thermocouple. - The thermocouple should be positioned 5mm away from the burner tube. Valve Thermocouple Thermocouple Wire...
-
Page 15: Troubleshooting
Possible Cause 2: Flame is being obstructed at burner ports. -Make sure that the gas ports on the burner are free of any lava rocks so that the flame can flow naturally. For Technical Support Contact Real Flame at: 1-800-654-1704 Restoration Hardware Customer Service: 1-800-816-0901... - Page 16 Possible Cause 3: Excess flow valve tripped. -Refer to “Problem: Sudden drop in gas flow” If these trouble shooting steps are unable to resolve the problem, please call the numbers listed below. For Technical Support Contact Real Flame at: 1-800-654-1704 Restoration Hardware Customer Service: 1-800-816-0901...
-
Page 17: Optional Accessories
Optionial Accessories Style # 64990270 Lava Rock Fire Bowl Cover Protect your Firebowl with this durable table cover available through Restoration Hardware. Please contact Restoration Hardware if you are interested in purchasing any of the above items.
