1. WHAT IS THE VC-HD....................................................................
2. SUPPORTED MEDIA FORMATS................................................
3. IN THE BOX.....................................................................................
4. SETUP INSTRUCTIONS................................................................
5. REMOTE CONTROL......................................................................
6. SETTINGS OPTIONS.....................................................................
7. ADDITIONAL VIDEO & SLIDESHOW OPTIONS....................
8. CONTENT ACTIVATION OPTIONS...........................................
9. PROGRAMMING CONTENT.......................................................
LOOPING...............................................................
BUTTON................................................................
PIR............................................................................
10. PIR & BUTTON CABLE WIRING...............................................
(from previous VC-HD models).......................
1
1
1
1
2
3
4
5
5
5
6
8
9
10
Advertisement
Table of Contents
Related Manuals for blackbox-av VideoClip-HD
Summary of Contents for blackbox-av VideoClip-HD
-
Page 1: Table Of Contents
VideoClip-HD user manual v1.3 contents 1. WHAT IS THE VC-HD..............2. SUPPORTED MEDIA FORMATS..........3. IN THE BOX..................4. SETUP INSTRUCTIONS..............5. REMOTE CONTROL..............6. SETTINGS OPTIONS..............7. ADDITIONAL VIDEO & SLIDESHOW OPTIONS....8. CONTENT ACTIVATION OPTIONS........... 9. PROGRAMMING CONTENT............ -
Page 2: What Is The Vc-Hd
Page 1 WELCOME 3.IN THE BOX Thank you for purchasing the VideoClip The VC-HD is one of a range of products we offer specific to the heritage marketplace. We are confident that we have other products you will find useful and Power Supply look forward to dealing with you again soon. -
Page 3: Remote Control
Page 2 5.REMOTE CONTROL FRONT VIEW Cover Fixings Power: Press to power VC-HD on/off Press to view information for content currently playing INFO Press to mute audio output, press to unmute Mute Button input 6 -1 Infrared SDHC Card USB Slot Press to play content in corresponding folder (folder 1, 2, 3 etc.) Slot REAR VIEW... -
Page 4: Settings Options
Page 3 6.SETTINGS OPTIONS AUDIO Using the Remote Control you can access a number of settings options for the VC-HD by pressing the ‘Setup’ button. Here you have access to ‘System, Audio, Video and Misc’ settings. Navigate between options using the ‘< ^ > v ok’ buttons. SYSTEM VIDEO... -
Page 5: Additional Video & Slideshow Options
Page 4 MISC image i 7.ADDITIONAL VIDEO & SLIDESHOW OPTIONS To access additional Video & Slideshow options the player must be currently playing either a video (for video options) or image (for slideshow and image options). Whilst playing either a video or image press the ‘Menu’ button. SLIDESHOW Here you can access slideshow options including repeat, transition and timing (see image i);... -
Page 6: Content Activation Options
Page 5 LOOPING EXAMPLE 1: LOOPING VIDEO 8.CONTENT ACTIVATION OPTIONS The VC-HD can play video, audio and image filetypes. These can be set to play in a looping fashion (requiring no user input) or can be button activated in a number of ways;... -
Page 7: Button
Page 6 With this configuration the player will loop constantly through all videos and then all Buttons are programmed using an ‘autoplay.txt’ file that is added to the SDHC or USB images in the following order: 1 Welcome Video -> 2 Battle of the Somme ->... - Page 8 Page 7 Button 1 plays folder ’01’ Button 1 plays folder ‘01’ Button 2 plays folder ‘02’ Button 3 plays folder ‘03’ Button 2 plays folder ‘02’ Button 4 plays folder ‘04’ Button 3 plays next file Button 5 plays folder ‘05’ Button 4 plays previous file Button 6 plays folder ‘06’...
-
Page 9: Pir
Page 8 Button 1 plays all files in folder ‘01’ Button 2 plays file ‘01’ in folder ‘01’ Button 1 plays next file Button 3 plays file ‘02’ in folder ‘01’ Button 2 plays previous file Button 4 plays file ‘03’ in folder ‘01’ Button 3 increases volume Button 5 plays file ‘04’... -
Page 10: Pir & Button Cable Wiring
10.PIR & BUTTON CABLE WIRING Information on wiring buttons and PIR connections, Button cables are provided with the VC-HD however the PIR is sold seperately (we recommend PIR’s supplied by blackbox-av); PIR: Sensor Senso The above content will loop through 3 images ‘01’ , ‘02’ and ‘03’ until the PIR is activated it will then play the video located in folder ‘01’... -
Page 11: Update Notes (From Previous Vc-Hd Models)
Page 10 11.UPDATE NOTES Updates to the original VC-HD version 1.1 (may 2014) November 2014 v1.2 - Added ability to set button as noninterruptible (add ‘n’ in text file) - 6 x Terminal block button adapters included with VC-HD - SD Card slot cover included January 2015 v1.3 - Added ‘PIR &...
