- Page 1 VideoClip-HD16 user manual v3 contents 1. WHAT IS THE VC-HD16..............2. SUPPORTED MEDIA FORMATS..........3. IN THE BOX..................4. SETUP INSTRUCTIONS..............5. REMOTE CONTROL..............6. SETTINGS OPTIONS..............7. ADDITIONAL VIDEO & SLIDESHOW OPTIONS....8. CONTENT ACTIVATION OPTIONS........... 9. PROGRAMMING CONTENT............
-
Page 2: What Is The Vc-Hd16
Page 1 WELCOME 3.IN THE BOX Thank you for purchasing the VideoClip HD16. The VC-HD16 is one of a range of products we offer specific to the heritage marketplace. We are confident that we have other products you will find useful and Power Supply look forward to dealing with you again soon. -
Page 3: Remote Control
Page 2 5.REMOTE CONTROL FRONT VIEW SDHC Card Slot Infrared Power: Press to power VC-HD on/off Press to view information for content currently playing INFO Press to mute audio output, press to unmute Mute USB Slot Volume Button input Speaker Up | Down 9-16 L | R... -
Page 4: Settings Options
Page 3 6.SETTINGS OPTIONS AUDIO Using the Remote Control you can access a number of settings options for the VC-HD16 by pressing the ‘Setup’ button. Here you have access to ‘System, Audio, Video and Misc’ settings. Navigate between options using the ‘< ^ > v ok’ buttons. SYSTEM VIDEO... -
Page 5: Additional Video & Slideshow Options
Page 4 MISC image i 7.ADDITIONAL VIDEO & SLIDESHOW OPTIONS To access additional Video & Slideshow options the player must be currently playing either a video (for video options) or image (for slideshow and image options). Whilst playing either a video or image press the ‘Menu’ button. SLIDESHOW Here you can access slideshow options including repeat, transition and timing (see image i);... -
Page 6: Content Activation Options
Page 5 LOOPING EXAMPLE 1: LOOPING VIDEO 8.CONTENT ACTIVATION OPTIONS The VC-HD16 can play video, audio and image filetypes. These can be set to play in a looping fashion (requiring no user input) or can be button activated in a number of ways;... -
Page 7: Button
Page 6 With this configuration the player will loop constantly through all videos and then all FILE ORDER images in the following order: 1 Welcome Video -> 2 Battle of the Somme -> Simply put the content you wish to be activated Evolution of the Tank ->... - Page 8 The VC-HD16 can be programmed to play content upon PIR activation. NOTE: Compatible PIR’s should be ordered via blackbox-av, they will come with the appropriate voltage designated and teriminals connected. A single PIR can be connected via the 12v supply and button 01 terminal (see image right).
