LightSpeed Technologies DRQ Specification Sheet

DRQ
™
LightSPEED's
DRQ ceiling speakers deliver high-quality, full-range
sound evenly throughout the classroom. With the supplied T-bridge and
integrated enclosure, the DRQ is easily installed into an acoustic ceiling
tile. When used with a LightSPEED Classroom Amplification System, four
DRQs project the teacher's voice evenly throughout the classroom allow-
ing every child to hear every word. The speaker grille is flush mounted
to the ceiling tile, and wires are routed overhead, making for a clean and
unobtrusive installation.
overview
Four DRQ speakers will cover classrooms
of up to 1600 square feet with 9 to
12 foot ceilings.
• Ideal option for rooms with
suspended ceilings
• Two-way speaker system produces
high-quality, full-range sound
• Integrated speaker enclosure
improves sound quality and reduces
bleed over
• Easy mounting makes for a
simple installation
• Stylish grille blends into classroom
surroundings
DRQ
™
Description
Driver Size
Frequency Response
Impedance
Power Handling
Dimensions
Weight
Enclosure
Tile Support
ceiling speaker
room coverage
ceiling speaker
LightSPEED Technologies
Top View of Room
Covers up to 1600 sq. ft.
(Example: 40 ft. x 40 ft.)
profile
Front View
9.5" diameter
Side View
Two-way speaker system
6.5" driver; 1" horn
40 Hz–20 kHz
8Ω
30 W
9.5" diameter; 5.5" deep
5.9 lbs.
White ABS ceiling-mount
housing with metal grille;
UL listed fire-retardant ABS
back-enclosure
20-gauge metal tile bridge
www.lightspeed-tek.com
800.732.8999
6.5" Speaker Size
8.125" Rough Opening
5.5"
i
imagine...
