LightSpeed Technologies CS-Q Specification Sheet

CS-Q
™
In classrooms where recessed ceiling speakers are not practical,
the CS-Q ™ wall speaker is an excellent alternative. Lightweight,
sturdy and easy to install, these speakers deliver superb full-
range sound with optimum clarity.
Two CS-Q ™ wall speakers and a LightSPEED Classroom Amplifica-
tion System are all that is needed to guarantee that everyone
hears the same great audio quality throughout the classroom.

overview

Two CS-Q wall speakers are ideal for
™
classrooms of up to 1200 square feet
with 8 to 12 foot ceilings.
• New Curved Design
• Two Speakers Fill Entire Room
•
Elegant Cabinet Styling
Protected by Steel Mesh
• Horizontal or Vertical Mount
•
Delivers a rich, full sound
CS-Q
™
Speaker Type
Speaker Cone Size
Frequency Response
Impedance
Power Handling
SPL @ 1w/1m
Dimensions (L x H x D inches)
Weight
wallspeaker

room coverage

wall speaker specifications

LightSPEED Technologies
Top View of Room
Covers up to 1200 sq. ft.
(Example: 30 ft. x 40 ft.)
profile
Front View
13.0"
Side View
13.0"
www.lightspeed-tek.com
800.732.8999
Twin-cone
6.5-inch
110 Hz –20 kHz ±6 dB
8Ω
10 W
94 dB
13 x 9.45 x 3.54
1.56 lbs.
