Introduction

Thank you for purchasing our REVOLTEC CARDMAGIC USB 2.0 card reader/writer
with built-in USB hub. Our card reader/writer allows you to read, write, and erase data
from the most popular cards such as CompactFlashTM Card Type I & II (CF Type I & II),
IBM MicrodriveTM, Memory Stick ® (MS), Memory Stick PRO®(MS PRO),
MultiMediaTM Card (MMC), SecureDigitalTM Card (SD), SmartMediaTM Card (SM),
and xD** Picture Card. The USB 2.0 hub allows you to add multiple USB 2.0 peripheral
devices to your PC and your USB 1.1 devices can function as usual. This device is
small, light, easy to carry, and easy to use.
**Not all types of Card Reader/Writers support xD Picture Card. Please
check the package or the vender for the xD card support.

Package Contents

· USB Card Reader/Writer with 3-port Hub
· Power Adapter
· USB Cable (optional)
· Driver CD
· Quick Installation Guide

Safety Instructions

1. Always read the safety instructions carefully.
2. Keep the User's Manual for reference.
3. Keep the equipment away from humidity.
4. Lay this equipment on a reliable flat surface before setting it up.
5. If any of the following situations arises, please contact a service technician for
diagnostics:
· The equipment has been exposed to moisture.
· The equipment has been dropped or damaged.
· If the equipment has obvious sign of breakage.
· The equipment has not been working well or it is still not functioning after you refer
to the User's Manual.

Specification

USB 2.0 Card Reader/Writer
· Four slots:
· CF Type I & II/ Microdrive.......................................1
· MS/ MS PRO................................ .............................1
· SD/ MMC......................................................................1
· SM or SM/ xD**..........................................................1
· Compliant with Hi-Speed USB 2.0 CompactFlash, Memory Stick, MultiMedia,
SecureDigital, Smart Media Standard Specifications
· Transfer rate: 480 Mb/sec (maximum)
· Hot-Swapping allowed between all cards
· True plug-and-play function
· No driver needed for Windows ME/2000/XP
**Not all types of Card Reader/Writers support xD Picture Card. Please
check the package or the vender for the xD card support.
USB 2.0 Hub
Power:
· Bus-power: 5V 500mA
· Self-power: 5V 2.5A
· Adapter: Input: 100~240V 50Hz-60Hz
Output: 5V 2.5A
· Compliant with Universal Serial Bus Specification Revision 2.0 (Data Rate
1.5/12/480 Mbps)
2
