Summary of Contents for Challenge Xtreme XSZ40
- Page 1 PETROL LAWN MOWER XSZ40 OPERATING INSTRUCTION HELPLINE NO 08454505299 Email Address: customerservices@sumec-europe.com...
-
Page 2: General Power Tool Safety Warnings
ORIGINAL INSTRUCTIONS GENERAL POWER TOOL machine; c) WARNING – Petrol is highly flammable SAFETY WARNINGS - store fuel in containers specifically designed for this purpose; WARNING! Read all safety - refuel outdoors only and do not smoke warnings and all instructions. while refueling;... - Page 3 ORIGINAL INSTRUCTIONS defective guards, or without safety devices, condition; for example deflectors and/or grass b) never store the equipment with petrol in catchers, in place; the tank inside a building where fumes can l) do not change the engine governor reach an open flame or spark;...
- Page 4 ORIGINAL INSTRUCTIONS SYMBOLS Read instruction handbook before operation this machine Keep bystanders away. Beware of sharp blades - remove spark plug lead before mainte- nance Forbid smoking and firing Appropriate ear, eye, and head protection must be worn. Hot surfaces will burn fingers or palms Warning! The lawnmower exhaust gas contain poisonous substan-...
- Page 5 ORIGINAL INSTRUCTIONS Component list 1. Upper handle 2. Blade control lever 3. Throttle control lever 4. starting knob 5. Rope guider 6. lower handle 7. fuel tank cap 8. height adjustment knob 9. spark plug 10. oil dip stick 11. rear flap 12.
-
Page 6: Technical Specifications
ORIGINAL INSTRUCTIONS TECHNICAL SPECIFICATIONS Engine displacement: 149.3cc Engine max. power: 2.1kW Engine speed: 2900rpm Cutting width: 40cm Grass bag capacity: 45L Ignition: T.C.I : 0.8L Fuel tank capacity : 0.6L Oil tank capacity Sound pressure level: 85dB(A) Sound power le vel: 96 dB(A) Vibration: 3.7m/s Weight: 23kg ACCESSORY... - Page 7 ORIGINAL INSTRUCTIONS ASSEMBLY slack. The right clip can fix two cables, the left one fixes a cable. WARNING! Two men are required to take the lawnmower out to carton. Make sure that you have sufficient space to put the lawn mower down. Keep your feet apart so that you have a stable position, bend at the knees and keep your back straight.
- Page 8 ORIGINAL INSTRUCTIONS OPERATION INSTRUCTION 1. BEFORE START THE ENGINE to upper level with the recommended oil (SAE30). Do not overfill. Wipe away any CAUTION! The following procedures spilt oil. and adjustments must be performed before the engine is started. Do not attempt to make any of these adjustments wihle the Maximum engine is running.
- Page 9 ORIGINAL INSTRUCTIONS 6. STARTING THE ENGINE Warning! Do not operate the machine in a closed or poorly ventilated areas as the exhaust gas contain poisonous substance. Keep hands, feet, hair and clothing away from all the moving parts of the machine. The exhaust and other parts of the machine will become hot during use.
- Page 10 ORIGINAL INSTRUCTIONS Clear a flooded engine 9. MOWING If the engine won’t start after you operated Always observe the strictest safety procedures when using the the starter several times, the engine may lawnmower. be flooded with excess fuel. Use following Carefully read the safety instructions procedure to clear and start a flooded of this manual before using the...
- Page 11 ORIGINAL INSTRUCTIONS 11. REPLACING THE BLADE (SEE FIG. H) Never use the lowest cutting height for Maintain the sharpness of the blade the first cut of the season or in drought when cutting grass. If the blade has worn conditions. Only about one thirds of the excessively and become pitted and blunt, grass height should be cut.
- Page 12 ORIGINAL INSTRUCTIONS Ensure the discharge chute and grass discharge flap are clean. The grass bag must always be emptied after use. Make sure that the exterior of the engine is clear of all debris, cuttings and dirt. Maintenance schedule 12 hours of 24hours 36hours of use...
- Page 13 ORIGINAL INSTRUCTIONS A slightly worn blade may be resharpened. Both blade edges must be sharpened equally to ensure balance. Sharpen the blade every 25 mowing hours or more frequently if conditions require. Remove the blade from the mower and clean using a brush and water. Inspect the blade for signs of damage.
-
Page 14: Trouble Shooting
ORIGINAL INSTRUCTIONS TROUBLE SHOOTING PROBLEM POSSIBLE FAULT REMEDY Engine will not turn Engine blade control Operate engine blade control over lever released. lever Incorrect oil level. Check oil level. Obstruction under deck. Remove obstruction. Engine smokes Excess oil level. Check oil level. Air cleaner cartridge oil Service air cleaner. - Page 15 ORIGINAL INSTRUCTIONS Uneven cut Undulating ground Change direction of travel conditions Blade worn Sharpen the blade Blade out of balance Balance the blade Wheels / roller damaged Inspect and replace as necessary Discharge chute Grass is wet Mow dry grass blocks Cut height too low Increase cut height...
