Summary of Contents for Tyco Electronics ET2639L
- Page 1 ET2639L 26” LCD Touchmonitor User Guide...
- Page 2 Elo TouchSystems ET2639L 26” LCD Touchmonitor User Guide Revision B P/N E983412 Elo TouchSystems 1-800-ELOTOUCH www.elotouch.com...
- Page 3 Elo TouchSystems to notify any person of such revisions or changes. Trademark Acknowledgments IntelliTouch, SC (Surface Capacitive), APR (Acoustic Pulse Recogni- tion), Elo TouchSystems, TE Logo, and Tyco Electronics are trade- marks. Other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Elo TouchSystems claims no interest in trademarks other than its own.
-
Page 4: Table Of Contents
Appendix A: Touchmonitor Safety ..............22 Care and Handling of Your Touchmonitor ................23 Appendix B: Technical Specifications ............24 ET2639L Specifications ..................... 25 ET2639L 26” LCD Touchmonitor Dimensions ..............27 Regulatory Information ....................... 28 Warranty ........................... 31 Elo TouchSystems ET2639L User Guide 4... -
Page 5: Chapter 1: Introduction
C H A P T E R INTRODUCTION About the Product Your new ET2639L Elo TouchSystems Touchmonitor combines the reliable performance of touch technology with the latest advances in Liquid Crystal Display (LCD) design. The monitor comes with the following features: •... -
Page 6: Chapter 2: Installation And Setup
C H A P T E R INSTALLATION AND SETUP This chapter discusses how to install and set up your LCD touchmonitor and how to install Elo TouchSystems driver software. -
Page 7: Unpacking Your Touchmonitor
Check that the following items are present and in good condition: Power cable Touchmonitor DVI-D cable (not in- USB Cable Analog Video cable cluded with ET2639L-xxxx-x-A-x models) CD and Quick Install Guide OSD Control Box Serial Cable (not included with ET2639L-Axxx models) Elo TouchSystems ET2639L User Guide 7... -
Page 8: Interface Connection
Tighten by turning the two thumb screws clockwise to ensure proper grounding. Connect the other end to your computer. Connect the OSD control box to the monitor. Press the power button on the rear panel to turn the monitor on. Elo TouchSystems ET2639L User Guide 8... -
Page 9: Installing The Touch Driver
Insert the Elo CD-ROM in your computer’s CD-ROM drive. If Windows XP, Windows 2000, Windows 98, or Windows Me start the Add New Hardware Wizard, follow these steps (if it does not open, follow steps 1a through 2a): Elo TouchSystems ET2639L User Guide 9... - Page 10 2a Follow the directions on the screen to complete the driver setup for your version of Windows. If the AutoStart feature is not active: Click Start > Run. Click the Browse button to locate the EloCd.exe program on the CD-ROM. Elo TouchSystems ET2639L User Guide 10...
- Page 11 Click Open, then OK to run EloCd.exe. Follow the directions on the screen to complete the driver setup for your version of Windows. Elo TouchSystems ET2639L User Guide 11...
-
Page 12: Monitor Mounting Orientation
Alternatively, the monitor may be mounted in the portrait orientation. For this orientation, the cable connection panel may be on either side, as shown in the illustrations below. Rear View of Monitor—Portrait Orientation Elo TouchSystems ET2639L User Guide 12... - Page 13 Landscape Mounting Orientation Angle Views The mounting orientation can be up to a 90° angle from vertical, as shown in the illustrations below. 90º 90º Elo TouchSystems ET2639L User Guide 13...
- Page 14 Portrait Monitor Orientation Angle Views The mounting orientation can be up to a 90° angle, as shown in the illustration below. 90° 90° Elo TouchSystems ET2639L User Guide 14...
-
Page 15: Chapter 3: Operation
Note: Do not operate the touchmonitor if you see the OOR mes- sage, or LCD damage may result. If you see the OOR message, set the video mode to one within the allowable range. Elo TouchSystems ET2639L User Guide 15... -
Page 16: On-Screen Display (Osd) Control Box
2) Decreases value of OSD adjustment choice AUTO/SEL 1) Automatically adjusts the image on the screen (this function not available for ET2639L-xxEx models) 2) Selects adjustment choices from the OSD menus. After adjusting the values, the monitor will automatically save the changes. - Page 17 Continue to hold the buttons down for another 2 seconds and the window toggles to “Power Lock.” NOTE: By default, the OSD screen will disappear if no input activities are detected for 30 seconds. Elo TouchSystems ET2639L User Guide 17...
-
Page 18: Osd Control Options
OSD Timeout • Adjusts amount of time that the OSD menu is displayed. Language • Selects the language used for the OSD menu from English, French, German, Spanish, Italian, Traditional Chinese, Simplified Chinese, or Japanese. Elo TouchSystems ET2639L User Guide 18... - Page 19 • Restores original factory settings for all other parameters and video inputs, except language (VGA and DVI). Miscellaneous Sharpness • Adjusts sharpness of video. Display Information • Frequency of the input horizontal/vertical synchronizing signal is indicated. Elo TouchSystems ET2639L User Guide 19...
-
Page 20: Preset Display Modes
The monitor comes with preset settings for commonly used video modes. It will automatically adjust the picture size and centering for any of the video modes listed in Appendix B, ET2639L Specifications table, under “Preset Display Modes.” If you make any adjustments to the H-position, V-Position, Clock and... -
Page 21: Chapter 4: Troubleshooting
See Chapter 3 and Appendix B for more information on allowable video modes. Make sure the USB or serial cable is Touch doesn’t work securely attached at both ends. Elo TouchSystems ET2639L User Guide 21... -
Page 22: Appendix A: Touchmonitor Safety
Do not block or insert anything inside the venti- lation slots. It is important that your touchmonitor remains dry. Do not pour liquid into or onto your touchmonitor. If your touchmonitor be- comes wet do not attempt to repair it yourself. Elo TouchSystems ET2639L User Guide 22... -
Page 23: Care And Handling Of Your Touchmonitor
Waste Electrical and Electronic Equipment (WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. Elo TouchSystems ET2639L User Guide 23... -
Page 24: Appendix B: Technical Specifications
APPENDIX TECHNICAL SPECIFICATIONS... -
Page 25: Et2639L Specifications
Input Video Signal • RGB Analog Video (0.7V p-p, 75 ohm; separate syncs, composite sync, or sync-on-green; TTL positive or negative) • DVI Video (not available for ET2639L-xxxx-x-A-x models) Input Video Range Horizontal scan frequency: 30 to 75 KHz Vertical frame rate range: 48 to 63 Hz... - Page 26 Altitude: 0 to 3,658 m Storage Conditions Temp: -20°C to 60°C Humidity: 10% to 90% (No Condensation) Altitude: 0 to 12,192 m Dimensions (HxWxD) 650 x 397 x 98 mm Weight (Unpackaged) 14.2 kg Elo TouchSystems ET2639L User Guide 26...
-
Page 27: Et2639L 26" Lcd Touchmonitor Dimensions
ET2639L 26” LCD Touchmonitor Dimensions Note: Detailed mechanical files can be found at: www.elotouch.com Elo TouchSystems ET2639L User Guide 27... -
Page 28: Regulatory Information
This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accor- dance with the instructions, may cause harmful interference to radio communications. Elo TouchSystems ET2639L User Guide 28... - Page 29 The user is cautioned that changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Elo TouchSystems ET2639L User Guide 29...
- Page 30 If you need additional help, consult your dealer, manufacturer, or an experienced radio or televi- sion technician. III. Safety Label The following marks have been issued for the unit and appear on the safety label as shown in the illustration below: Elo TouchSystems ET2639L User Guide 30...
-
Page 31: Warranty
Seller’s facilities or at Buyer’s premises. If Seller is unable to modify, repair, or replace a Product to conform to the war- ranty set forth above, then Seller shall, at Seller’s option, either refund Elo TouchSystems ET2639L User Guide 31... - Page 32 Products made or authorized by Buyer. Buyer will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses (including reasonable attorney’s fees) attribut- able to Buyer’s products or representations or warranties concerning same. Elo TouchSystems ET2639L User Guide 32...
-
Page 33: Product Information
Japan Belgium Germany (800) ELO-TOUCH Tel +49 (0)(89) 60822-0 Tel +81(45)478-2161 (800) 356-8682 Tel +32(0)(16)35 21 00 Fax +49(0)(89) 60822-180 Fax +81(45)478-2180 Tel 650-361-4800 Fax +32(0)(16)35 21 01 elosales@elotouch.com www.tps.co.jp Fax 650-361-4747 elosales@elotouch.com eloinfo@elotouch.com Elo TouchSystems ET2639L User Guide 33...
