Syncom technologies g8p-65 User Manual

Gigabit PoE+ Switch
8 port Giga with 4 PSE L2 switch
User's Manual
Package Contents
Before you start to install this switch, please verify your package
that contains the following items:

One PoE Gigabit Switch

One Power Cord
 One User's Manual
Note: If any of these items is found missing or damaged, please
contact your local supplier for replacement.
Product Features

8-port 10/ 100/ 1000Mbps RJ-45 w/ 4-port PoE/ PSE
functions

Complied with IEEE 802.3 10Base-T
FCC Warning
This device has been tested and found to comply with limits
for a Class A digital device, pursuant to Part 15 of FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment
is operated in a commercial environment. This equipment
generates and radiates radio frequency energy and, if not
installed and used in accordance with the user's manual, it
may cause interference in which case users will be required
to correct interference at their own expenses.
CE Warning
This is a Class A product. In a domestic environment, this
product may cause radio interference in which case the user
may be required to take adequate measures.
Introduction
This switch supports 5-port 10/ 100/ 1000Mbps RJ-45 and
1-port 1000Mbps SFP with 4 PoE. It was designed for easy
installation and high performance in an environment where
traffic is on the network and the number of users increases
continuously.
It consists of 4 PSE/ PoE ports. That can solve the limitation
of the power outlet location and offer the system designer a
flexible solution to locate the network device everywhere.
The compact rigid desktop size was specifically designed for
small to medium workgroups. It can be installed where space
is limited; moreover, it provides smooth network migration
and easy upgrade to network capacity.

Complied with IEEE 802.3u 100Base-TX

Complied with IEEE 802.3ab 1000Base-T

Complied with 802.3x Flow Control

Complied with IEEE 802.3at and backward compatible with
IEEE 802.3af

Complied with class 3/ class 2/ class 1 and IEEE802.3at
classes

Max. 30Watt per PoE/ PSE port

Flow control: back pressure in Half-duplex and IEEE
802.3x in Full-duplex

Auto-MDIX function

2000Mbps Full-duplex bandwidth each port

Broadcast storm control and Store & Forward

Non-blocking & Non-head-of-line blocking wired speed
forwarding

Auto-learning networking configurations

2K MAC table, 96K byte buffer memory

Filtering/Forwarding
100Mbps/148,800pps; 10Mbps/14,880pps

Packet length 1522 bytes/ Maximum 1536bytes

Jumbo frames: 9K

Status LEDs: System Power, Link/Activity, and PoE/ PSE

Network Transmission Media: 10Base-T Cat. 3, 4, 5
UTP/STP; 100Base-TX Cat. 5 UTP/STP, 1000BASE-T Cat.
5E UTP/STP.

External switching power supply AC 110 ~ 240V to DC 53V
output
 PoE+ Green Power Built-in Features

Link up mode: Auto detection of level class of Powered
device, output power budgets each port

Power down mode: Auto detection of No Link or Standby of
Powered device.
Rate: 1000Mbps/1488,000pps
