Section 3: Setup
InfraRGB Source Sequence
Select one of these options to set how IR is generated from the input source(s):
• Simultaneous RGB + IR (Main): The RGB and IR signals are both taken from the main input.
• Interleaved RGB (Main), IR (Secondary): The RGB signal is taken from the main input, and the IR
signal is taken from the secondary input.
• Interleaved RGB+IR (Main), RGB+IR (Secondary): Both RGB and IR signals are taken from both
channels.
Main Input
Select the slot or input for RGB from the drop-down list.
Secondary Input
Select the slot or input for IR from the drop-down list.
Swap Main & Secondary Input
Click to swap between the Main and Secondary inputs.
Edit Secondary Channel Settings
Select to allow independent secondary channel control during interleaved operation. By default, size and
position controls act on both channels at the same time.
Selected Lighting Mode
The Lighting mode sets the RGB and IR illumination brightness. Choose the Lighting mode to set the RGB
and IR brightness for the RGB video source. A factor of 100 is the full brightness of the available video.
Selecting one of the other presets reduces the brightness, as outlined below.
Brightness of the video can be affected by Geometry and Color. For example, if you have reduced the
NOTE:
power for the Red part of Red to 240, the brightest red can get is 240 using an RGB brightness of 100.
3-12
PRESET NAME
Daylight
Urban
Semi-Urban
Moonlight
Half-moon
Quarter-moon
Starlight
Cloudy starlight
IR Only
User
RGB BRIGHTNESS
100
80
70
60
30
15
5
2.5
0
100
IR BRIGHTNESS
100
100
100
100
50
25
15
7.5
100
100
