Windows Driver Manual
Label Printer
SLP-TX400 / TX400E
Rev. 1.03
SLP-TX403 / TX403E
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLP-TX400 and is the answer not in the manual?

Questions and answers

Related Manuals for BIXOLON SLP-TX400

Summary of Contents for BIXOLON SLP-TX400

  • Page 1 Windows Driver Manual Label Printer SLP-TX400 / TX400E Rev. 1.03 SLP-TX403 / TX403E http://www.bixolon.com...

  • Page 2: Table Of Contents

    SLP-TX400x/TX403x ■ Table of Contents 1. Manual Information ......................3 2. Operating System (OS) Environment................3 3. Windows Driver Preparation .................... 3 4. Windows Driver Installation ....................4 4-1 Installing on Windows XP/2003 Server ............... 4 4-1-1 Via Serial or Parallel port ..................4 4-1-2 Via USB ........................

  • Page 3: Manual Information

    Windows Driver according to PC operating system (OS). We at BIXOLON maintain ongoing efforts to enhance and upgrade the functions and quality of all our products. In following, product specifications and/or user manual content may be changed without prior notice.

  • Page 4: Windows Driver Installation

    SLP-TX400x/TX403x 4. Windows Driver Installation 4-1 Installing on Windows XP/2003 Server 4-1-1 Via Serial or Parallel port 1) Double-click the Windows Driver installation file. 2) Click the “Next” button. Rev. 1.03 - 4 -...
  • Page 5 SLP-TX400x/TX403x 3) Select the COM or LPT (Which one you want to use) port to be used and click the “Next” button. 4) When the following message box appears, click the “Continue Anyway” button. Rev. 1.03 - 5 -...
  • Page 6 SLP-TX400x/TX403x 5) Clicking the ”Yes” button will reboot the PC. 6) Open the printer properties window in the Windows OS. 7) Click the “Port Settings” button in the ”Ports” tab. 8) Match the communication settings to those of the printer. (The communication settings of the printer can be performed by conducting a self-test.) Rev.
  • Page 7 SLP-TX400x/TX403x 9) Click the “Print Test Page” button and check printing status. 10) Proper installation of the driver is indicated if the test page is printed normally. Rev. 1.03 - 7 -...

  • Page 8: Via Usb

    SLP-TX400x/TX403x 4-1-2 Via USB 1) Double-click the Windows Driver installation file. 2) Click the “Next” button. Rev. 1.03 - 8 -...
  • Page 9 SLP-TX400x/TX403x 3) Select USB and click the ”Next” button. 4) When the following message box appears, click the “Continue Anyway” button. 5) Click the ”OK” button. 6) Turn on the printer. Rev. 1.03 - 9 -...
  • Page 10 SLP-TX400x/TX403x 7) When the New Hardware Wizard appears for the installation of the Windows Driver, select the option as shown below and click the “Next” button. 8) Click the “Next” button. Rev. 1.03 - 10 -...
  • Page 11 SLP-TX400x/TX403x 9) Click the “Next” button. 10) Click the “Continue Anyway” button. Rev. 1.03 - 11 -...
  • Page 12 SLP-TX400x/TX403x 11) Click the “Finish” button. 12) The USB Port setting can be confirmed in the Windows Driver properties. Rev. 1.03 - 12 -...
  • Page 13 SLP-TX400x/TX403x 13) Click the “Print Test Page” button and check printing status. 14) Proper installation of the driver is indicated if the test page is printed normally. Rev. 1.03 - 13 -...

  • Page 14: Installing Windows Vista/2008 Server/7/8

    SLP-TX400x/TX403x 4-2 Installing Windows VISTA/2008 Server/7/8 4-2-1 Via Serial or Parallel 1) Double-click the Windows Driver installation file. 2) Click the “Yes” button. 3) Click the “Next” button. Rev. 1.03 - 14 -...
  • Page 15 SLP-TX400x/TX403x 4) Select the COM or LPT (Which one you want to use) port to be used and click the “Next” button. 5) When the following message box appears, click the “Install” button. Rev. 1.03 - 15 -...
  • Page 16 SLP-TX400x/TX403x 6) Clicking the ”Yes” button will reboot the PC. 7) Open the printer properties window in the Windows OS. 8) Click the “Port Settings” button in the ”Ports” tab. 9) Match the communication settings to those of the printer. (The communication settings of the printer can be performed by conducting a self-test.) Rev.
  • Page 17 SLP-TX400x/TX403x 10) Click the “Print Test Page” button and check printing status. 11) Proper installation of the driver is indicated if the test page is printed normally. Rev. 1.03 - 17 -...

  • Page 18: Via Usb

    SLP-TX400x/TX403x 4-2-2 Via USB 1) Double-click the Windows Driver installation file. 2) Click the “Yes” button. 3) Click the “Next” button. Rev. 1.03 - 18 -...
  • Page 19 SLP-TX400x/TX403x 4) Select USB and click the ”Next” button. 5) When the following message box appears, click the “Install” button. 6) Click the “OK” button. Rev. 1.03 - 19 -...
  • Page 20 SLP-TX400x/TX403x 7) Turn on the printer. 8) The USB Port setting can be confirmed in the Windows Driver properties. Rev. 1.03 - 20 -...
  • Page 21 SLP-TX400x/TX403x 9) Click the “Print Test Page” button and check printing status. 10) Proper installation of the driver is indicated if the test page is printed normally. Rev. 1.03 - 21 -...

  • Page 22: Detailed Windows Driver Settings

    SLP-TX400x/TX403x 5. Detailed Windows Driver Settings 5-1 Printing Preferences 1) No.Of Copies: The number of copies.. 2) Speed: Set the printing speed (1 ~ 7 ips) 3) Darkness: The darkness level of printouts (0 ~ 20). 4) Portrait: The printer prints in portrait orientation. 5) Landscape: The printer prints in landscape orientation.

  • Page 23: Adding New Paper Size

    SLP-TX400x/TX403x 5-2 Adding new paper size 1) Click the “Preferences…” button Rev. 1.03 - 23 -...
  • Page 24 SLP-TX400x/TX403x 2) Click the “New (N)” button. 3) Set a value you want and then click “OK” button. Rev. 1.03 - 24 -...

  • Page 25: Specifications

    SLP-TX400x/TX403x 6. Specifications 6-1 Resolution BIXOLON SLP-TX400 : 203  203 dpi BIXOLON SLP-TX403 : 300  300 dpi 6-2 Paper Size 1.5 x 1.0 inch (38.1 x 25.4 cm) 4.0 x 2.0 inch (98.9 x 50.8 cm) 1.5 x 1.5 inch (38.1 x 38.1 cm) 4.0 x 3.0 inch (98.9 x 76.2 cm)
