Simplex 3000 Assembly Instructions

Simplex 3000 Drive Assembly - Instructions
TABLE OF CONTENTS

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . .1

Tools Required for Installation . . . . . . . . . . . . . . . . .1

A. Hardware Disassembly . . . . . . . . . . . . . . . . . . . .1

Cam Plug Handing . . . . . . . . . . . . . . . . . . . . . . . .2
B. Stile Preparation For Combination Side Of Door 2
C. Stile Preparation Of Trim Plate Side Of Door . . . .3
D. Drill Lock And Trim Plate Mounting Holes . . . . .3
E. Hardware Assembly . . . . . . . . . . . . . . . . . . . . . . .3
Package Contents:
1 x drive assembly
1 x cam plug
1 x cardboard template
1 x cam plug cover ( /
31
2 x mounting screws 10-24 thd x 1
2 x threaded sex nuts
2 x mounting bushings
Read all instructions before starting installation
Installation
A HARDWARE DISASSEMBLY
A-1 Remove face plate from edge of door exposing
the cylinder set screws (See Figure 1).
A-2 Loosen the cylinder set screw (securing key
cylinder to latch) and remove the cylinder from
the dead latch assembly (See Figure 1).
A-3 With the exception of the dead latch assembly,
remove all other hardware from door: knob,
handle, etc (See Figure 1).
lpro
Simplex Digital Lock
" backset only)
32
1 / "
2
First Choice for Locking Solutions
®
T 01202 676262
Tools Required For Installation
• tape
• electric drill (variable speed recommended)
• small flat head screwdriver
• medium flat head screwdriver
• large phillips head screwdriver
• center punch
• ( / ") drill bit
31
32
• ( 3 / ") drill bit
8
• ( / ") hole saw
7
8
• ( / ") drill bit
1
8
• ( 1 / ") drill bit
4
• hammer
• deburring tool
• safety goggles
Warnings & Cautions
Important: Carefully inspect windows, doorframe,
door, etc. to ensure that the recommended
procedures will not cause any damage. Warranty
does not cover damages caused by installation.
Caution: Wear safety glasses when preparing door.
FIGURE 1
Dead Latch
Assembly
F 01202 680101 E alpro@iecltd.co.uk
Cam Plug in
Narrow
Cylinder Hole
Stile
Cam Plug
Mortise
Cylindrical
Cylindrical
Set Screw
Face Plate
W www.alpro.co.uk
