Aussie AS-PTZRR-23 User Manual

Intelligence ir medium speed dome camera
Hide thumbs

Advertisement

Quick Links

Download this manual
USER MANUAL
INTELLIGENCE IR MEDIUM
SPEED DOME CAMERA

Advertisement

loading
Need help?

Need help?

Do you have a question about the AS-PTZRR-23 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aussie AS-PTZRR-23

Summary of Contents for Aussie AS-PTZRR-23

  • Page 1 USER MANUAL INTELLIGENCE IR MEDIUM SPEED DOME CAMERA...

  • Page 2: Table Of Contents

    USER MANUAL Contents 1 Product Features 2 Installtion 2.1 Dip Switch Setup 2.2 Cabling 3 PTZ Smart Setup 4 Special Preset Table 5 Simple Troubleshooting&Maintenance 5.1 Simple troubleshooting Table 5.2 Notice...

  • Page 3: Product Features

    USER MANUAL Product Features Powerful Intelligent Function ● Identify various control protocols automatically,such as PELCO D/P, Hikvision, Dahua,etc. ● Identify 2400, 4800, 9600 baud rate automatically ● Identify RS-485 Positive and negative connections automatically ●Support 3D Positioning of Hikvision, Dahua DVR Powerful PAN/TILT Rotation ●Vector drive technology, Pan/Tilt function make the video image look more natural.

  • Page 4: Dip Switch Setup

    USER MANUAL ●Continuous Scanning:Call the specified special preset, PTZ scan continuously. PTZ Control ●RS-485 Communication Protocol ●Pan 360°rotate continuously.Tilt 90°autoflip.After 180°, endless monitoring, no surveillance blind zone ● Pan speed max.60°, Tilt speed max.50° Smart Installation 2.1 Camera ID and Dip Switch Setup Please set up Camera ID before using camera via dip switchor soft address.

  • Page 5: Cabling

    USER MANUAL Camera ID Code Table Camera OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF 2.2 Cabling Instruction Power supply: DC 12 V 3 A interface The line: 485 line...

  • Page 6: Ptz Smart Setup

    USER MANUAL 2.2.1 Powersupply Connection Note: please check carefully rated voltage and power supply, rated voltage and current are as follows: rated voltage rated voltage range current ±10% DC 12V 2.2.2 Control Cable Connection PTZ Control: RS-485 connect controller keyboard or DVR. And control one or more PTZ camera,RS-485 control cable setup is twisted pair status.
  • Page 7 USER MANUAL 3.1 Power up self test PTZ power up and self test,firstly,rotate PAN & TILT,camera lens WIDE,stop till TELE.Self test ensure PTZ operate well. ： Control PTZ up-down,left-right rotation After selecting one PTZ(Call special preset command, * * + CALL please check preset commands table for reference;...
  • Page 8 USER MANUAL move to next preset according to preset order. Call specia preset#200~215,preset dwell time,the corresponding dwell time is 5,6,7...20 sec; (1) Call 99 preset , start 1 to 20 preset cruise; (2) Call 88 preset, start 1 ~ 10 preset cruise; (3) Call 89 preset, start 11 ~ 20 preset cruise;...
  • Page 9 USER MANUAL (User set up PAN/TILT angle according to necessity),And Call preset#98, PTZ PAN 360° sc anning continouskt at specified speed, Call special preset#225 ~ #229 to ensure scanning speed is level1 ~ 5; 3.8. Intermittent scanning PTZ is in a certain position via Controller Keyboard Joystick (User set up PAN/TILT angle according to necessity),then Call preset#92;...
  • Page 10 USER MANUAL (4) Call Preset#194,skip to Preset#1 (5) Call Preset#195,skip to Preset#8 (6) Call preset #196 ， Preset Cruise 1 (7) Call preset#197, Preset Cruise 2 (8) Call preset#198, Preset Cruise 3. (9) Call preset#199, Preset Cruise 4 3.11.Idle Action It means PTZ hasn't any more operatio n ,after specified waiting time, automove Idle Adtion, like continous scanning, intermittent scanning,Swing and Preset Cruise.etc via Call Preset#181~#189.It...

  • Page 11: Notice

    USER MANUAL Special Presetsl Function Table Notice：XX+CALL :Call Preset#XX ；XX+PRESET: Set XX preset Special Preset Functions 0~79 preset Normal presets 95 + call Enter camera menu XXX + PRESET Set preset XXX XXX + CALL Call Preset XXX 82 + CALL Start scanning the current zone 83 + CALL Clear all presets...
  • Page 12 USER MANUAL 164+CALL idle dwell time 19 sec 165+CALL idle dwell time 20sec 166+CALL idle dwell time 21 sec 167+CALL idle dwell time 22 sec 168+CALL idle dwell time 23 sec 169+CALL idle dwell time 24 sec 170+CALL idle dwell time 30 sec 171+CALL idle dwell time 35 sec 172+CALL...
  • Page 13 USER MANUAL 193 + CALL Start Power up action to Swing 194 + CALL Start Power up action to Preset 1 195 + CALL Start Power up action to Preset 8 196 + CALL Start Power up action to Preset cruise 1 197 + CALL Start Power up action to Preset cruise 2 198 + CALL...

  • Page 14: Troubleshooting And Maintenance

    USER MANUAL 231 + CALL Set up camera protocol to SONY 232 + CALL Set up camera protocol to CNB 233 + CALL Set up camera protocol to SANYO 234 + CALL Set up camera protocol to LG 235 + CALL Set up camera protocol to SAMSUNG 236 + CALL Set up camera protocol to York...
  • Page 15 USER MANUAL 5.2 Notice 1. Careful shippment Please prevent the damage from heavy weight, Severe vibration and soak during shipping, keeping and installation. 2.Installing Zoom Camera carefully Specially, handle with care. Do not oppress zoom camera and structure parts, to prevent camera failure. For safety, please don't power up before installing the camera cover.
  • Page 16 USER MANUAL 6. Strictly sealed to prevent the liquid spill or objects fall in side the camera, otherwise it will cause permanent damage to the equipment. 7. Don't use the speed dome camera when exceed the limit tem perature , humidity state The camera using temperature is from -25℃to 50℃,humidity less than 90% 8.
