EN
For maximum cooling capacity of your radiator, you can then mount up to two additional 140
mm or 120 mm fans on top of the radiator.
If you use a very large radiator, it may be that the hose connectors block the mounting
screws of the frame. In this case, please use the special, included thumbscrews to fix the
frame to the case.
Radiator
Radiator
with 4 fans
with 2 fans
mounted
mounted
8.2 Installation of a radiator or compact water cooling under the top cover
For the installation of the radiator under the top cover, please use the offset mounting holes,
as shown in the diagrams below. The offset ensures the best possible compatibility with
current motherboards, even when using extra thick radiators.
18
