Falcon BT1311 Operation Manual

Operation Manual
I. Quick Start
Welcome: Thanks for purchasing a full-size Bluetooth multi-platform keyboard with thumb
controlled falcon™ (optical mouse in the spacebar and finger tip activation buttons) on board.
You are invited to read this Operation Manual to get the most from this new keyboard. This
Operation Manual is also available for download at falconkeyboard.com.
Activation Keys
Power
LEDS: Left Click
Up Dn
F1 F2 F3
What is in the Box?
• Bluetooth keyboard with 'falcon™' mouse
• Universal Serial Bus (USB) charging cable (standard USB to micro USB)
• Operation Manual with Quick Start instructions
Falcon Enterprises
17150 Via Del Campo, Ste 206
San Diego, CA 92127
866-450-8932 (tel) • 858-408-4571 (fax) • falcon@falconkeyboard.com • http://falconkeyboard.com
Model: BT1311
R17
Micro USB
Sync Switch
Charging Port
LEDS:
Right Click
CAPS Num Power Sync
Optical
Mouse
1
Getting Started
• Charging the Battery
Charge the internal battery from a standard powered USB port (PC or powered USB hub) or mobile
device power source not exceeding 5.0 VDC, using the USB charging cable provided with your
keyboard, through the micro USB charging port until red battery light turns green.
• Synching with your falcon™ keyboard with your Bluetooth device
!
This multi-platform keyboard, is capable of being operated with any personal computer (PC),
iPAD, iPhone, Android or Windows Phone or Tablet equipped with Bluetooth chip set. The synced
device must support the "Bluetooth HID" (Human Interface Design) profile. Microsoft Windows,
Android, OSX and iOS should work whereas the Blackberry will not.
If you plan to have more than one device synced (or paired) to the same keyboard, select Fn+F1,
F2 or F3 before starting the syncing operation so you can assign that device to the appropriate
channel (F1, F2 or F3). Note: F1 is the default channel and the first device will be paired using that
channel if a channel is not selected. The blue LED above the F1, F2 or F3 (determined by channel
in use) key should slowly flash to indicate when the keyboard is connected.
Synching with your iPAD, iPhone, iMac, or other Apple device:
Use the following steps to sync the keyboard:
1. Turn on your keyboard using the upper left hand Power button.
2. Turn on the Apple device to be paired. Open System Preferences (OSX) or Settings (iOS)
on the Apple device.
3. Select (click on or touch select) Bluetooth.
4. Turn Bluetooth on (button turns green in iOS).
5. Press the "Sync" switch on the upper right hand corner of the keyboard.
6. The blue "Bluetooth" LED should start flashing indicating that it is "Now Discoverable".
7. "FALCON" should show up under the Devices listed on the Bluetooth Devices screen with
the notation "Not Paired" (iOS) or "Pair" (OSX).
8. Select (click on or touch select) "FALCON" (iOS) or "Pair" (OSX).
9. A "Bluetooth Pairing Request" will appear with a 4 or 6 digit number along with the words
"Enter the code "XXXX" on "FALCON" followed by the RETURN or ENTER key".
10. Type the number on your keyboard in the primary number line on the QWERTY portion of
the keyboard only and then press "Enter". Be sure to press "Enter" to complete syncing.
The keyboard blue "Bluetooth" LED should turn solid to indicate it has paired successfully
with the Apple device.
Once paired, the notation on the Bluetooth Devices screen should change to "Connected". The
keyboard should remain paired and connect automatically when used with that Apple Device. There
may be a slight delay in connecting on subsequent uses if the keyboard is not constantly in use or
the Apple device goes to sleep or is powered down.
Note: The falcon™ on board will not provide cursor pointing action with a unit that does not
support cursor movement (iPhone or iPad).
2
