I. Quick Start
Welcome: Thanks for purchasing a falcon ™, a full-size Bluetooth multi-platform keyboard with
thumb controlled optical mouse in the spacebar and finger tip activation buttons. You are invited
to read Operation Manual to get the most from this new computer component. This Operation
Manual is available at: www.falconBTkeyboard.com
On/Off
LEDS:
F1
F2
F3
What is in the Box?:
• Bluetooth keyboard with 'falcon™' mouse
• USB charging cable
• Quick Start instructions
Getting Started
• Perform charging from a PC or authorized power source not exceeding 5.0 DCV, using the
USB charging cable provided with your keyboard until red charging light turns green.
™
Operation Manual
Activation Keys
Left Click
Up Dn
Model: BT1311
USB Charging
Port
Right Click
CAPS Num Power Sync
Cursor Port
R14
Sync Switch
LEDS:
1
Advertisement
Table of Contents
Related Manuals for Falcon BT1311
Summary of Contents for Falcon BT1311
- Page 1 Operation Manual I. Quick Start Welcome: Thanks for purchasing a falcon ™, a full-size Bluetooth multi-platform keyboard with thumb controlled optical mouse in the spacebar and finger tip activation buttons. You are invited to read Operation Manual to get the most from this new computer component. This Operation Manual is available at: www.falconBTkeyboard.com...
- Page 2 • The use of a mouse, thumb pad, or track ball is habit forming. To get the most from the falcon™, hide your mouse where it cannot be reached and disable the track ball or thumb pad. You will have to form a new habit in the use of your thumb or finger tip to become proficient with the falcon™...
- Page 3 unit. Fn + F2 together, then sync your second unit. Fn +F3 together, then sync for the third unit. • Precise location of the cursor on the monitor can be assisted by varying the DPI (dots per inch-the accuracy of the picture being taken) Changing from 400, 600, 800 or 1200 DPI is performed by pressing Fn + S together.
- Page 4 Operation: • The falcon™ keyboard has a built-in mouse operation that allows the user to move the cursor on the monitor almost identical to using a normal mouse. Instead of moving the mouse over a surface to move the cursor, the edge of the thumb or tip of a finger, is moved over the 'lens' in the space bar to move the cursor.
- Page 5 FN+R+L at the same time. Pressing FN+R+L again returns to normal. • A new right hand user of the falcon™ may find it easier to use the Left Hand Keyboard Operation setup so that the left hand can be used for Left and Right click while the right hand thumb is used to move the cursor without worrying about the right hand finger activation of selection keys.
-
Page 6: Appendix A Falcon™ Specifications
Appendix A falcon™ Specifications Item Specification Product Name Falcon BT Keyboard Keys Key Travel 1.6 mm +/- 0.2 mm Key Touch 45-60 gm Soft tactile rubber dome Dimensions 380 x155 x 12 x +/- 2mm Weight 586 +/- 10 gm Interface Bluetooth ver. -
Page 7: Appendix B Bluetooth Unit Syncing
• When the device displays "Available Devices, touch to pair"..Touch the screen. • A 4 or 6 digit number will appear. Type that number on your falcon™ keyboard, and then press "Enter". Be sure to press "Enter to complete syncing. Once paired, it should remain... - Page 8 • When the device displays "Available Devices, touch to pair"..Touch the screen. • A 4 or 6 digit number will appear. Type that number on your falcon™ keyboard, and then press "Enter". Be sure to press "Enter to complete syncing. Once paired, it should remain paired on subsequent uses.
-
Page 9: Appendix C Certifications
Appendix C Certifications Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 10: Industry Canada Statement
C.2 Industry Canada statement: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
