- Page 1 User manual...
-
Page 2: Care And Maintenance
Keep the device clean and dust free with a soft and dry cloth. We recommend you to use the provided cleaning cloth. ≥ Clean the unit while it is turned off and unplugged from electric power. ≥ Do not disassemble the device. Any repairs must be performed by the qualified Energy Sistem Soyntec´s personnel. -
Page 3: Main Features
MAIN FEATURES ≥ High Definition 9.7” IPS screen. ≥ 4:3 screen format. ≥ 1024x768 pixels resolution, 250cd / m2, 500:1. ≥ Compatible with the JPG/JPEG/BMP pictures of the majority of the digital cameras with maximum resolution 8000 x 8000 pixels. ≥... -
Page 4: Product Content
Includes mounting holes on the back to be fixed to the wall. ≥ Slim remote control. ≥ AC/DC power adapter (Europlug). Input 100-240V; Output 5V/1.5A; 50/60Hz. PRODUCT CONTENT ≥ Energy Sistem Photo Frame m10 Ultra Slim. ® ≥ Stand. ≥ Screen cleaning cloth. ≥ User manual. -
Page 5: General Overview
GENERAL OVERVIEW ENERGY m10 Ultra Slim... - Page 6 ON/OFF: Turn on-off the digital photo frame. SETUP: Enter SETTINGS menu. PLAY/PAUSE: Show the selected image in full screen / execute the option currently selected in the menu / change the display mode / reproduce, pause or resume the files of audio and video / enter the current folder.
-
Page 7: Remote Control
REMOTE CONTROL MAIN MUTE RETURN MENU SLIDE 12 11 SETUP SHOW 15 14 VOL- VOL+ ZOOM 18 17 ROTATE MUSIC VIDEO ON/OFF: Turn on/off the digital photo frame. MAIN: Return to main menu. MUTE: Sound Off / On. MENU: Copy file to built-in memory (from Thumbnail Mode only) / delete file (from Thumbnail Mode only). - Page 8 EXIT: Return to the previous screen (menu). PREVIOUS: Show previous image / move the current view up when applying zoom to an image / reduce value in the setting options / BACKWARD function. PLAY/PAUSE: Show the selected image in full screen / execute the option currently selected in the menu / change the display mode / reproduce, pause or resume the files of audio and video / enter the current folder.
-
Page 9: Power Source
MAIN MENU PHOTO. MUSIC. VIDEO. FILE EXPLORER. CALENDAR. SETTINGS. POWER SOURCE Your Energy™ Photo Frame m10 is powered through the AC/DC 5V adapter provided with the product. Please firstly connect the photo frame with the power adapter then connect the power adapter with electrical outlet. The remote control is powered by a CR2025 3V lithium battery that you can easily replace when depleted by releasing the battery compartment in the back of the remote control. -
Page 10: Switching On/Off
SWITCHING ON / OFF To power on your Energy™ Photo Frame m10 just plug in the provided power adapter to a 100-240V AC source and press the ON/OFF button located on the back side of the frame or press the ON/OFF button from remote control. To turn off your photo frame, simply press the ON/OFF button on the back side of the frame or press the ON/OFF button from remote control. -
Page 11: Slideshow + Music
SINGLE To change the display mode to “SINGLE”, you can press again the PLAY/PAUSE button and you can manually move to the next pictures, using the PREVIOUS and NEXT buttons. In this display mode, you can rotate and make zoom on the currently selected photo with the “RORATE”... - Page 12 MUSIC Play music: you can access to this function from the main menu of your Energy™ Photo Frame m10, by selecting the “MUSIC” option with the PREVIOUS / NEXT and PLAY/PAUSE buttons. After that, you will see a list of audio files stored in the memory device (e.g.
-
Page 13: File Explorer
FILE EXPLORER You can access to this function from the main menu of your Energy™ Photo Frame m10 , by selecting the “FILE EXPLORER” option with the PREVIOUS / NEXT and PLAY/ PAUSE buttons. You can explore the folders and files stored in the memory device (e.g., pendrive or memory card). -
Page 14: Photo Setup
PHOTO SETUP ≥ Display mode: Slideshow, Thumbnail and Single. ≥ Image mode: * Auto Fit: The image is adjusted to display in the screen, respecting the original proportions. * Optimal: The image expands vertically and horizontally to fit the (full) screen, respecting the original proportions and the screen resolution. -
Page 15: Music Setup
MUSIC SETUP ≥ Play mode: Allows selecting the mode (order) of reproduction among options of “Repeat”, “Random” and “Once”. ≥ Music effect: Allows selecting the music effect among 7 different options. ≥ Show spectrum: Allows enabling or disabling the demonstration of spectrum during playback ≥... -
Page 16: Calendar Setup
CALENDAR SETUP ≥ Display mode: Monthly calendar, calendar and analogic clock. ≥ Date format:There are 3 date formats available for setting the calendar. ≥ Date: Allows updating the date used by the system. ≥ Clock mode: Allows setting the time format between 12 hours and 24 hours. ≥... -
Page 17: Troubleshootings
USB HOST Your Energy™ Photo Frame m10, as well as showing your favorite pictures stored in SDHC/SD/MMC/MS memory cards, can also load and display pictures from USB memory devices such as pen drives. Just plug in the pen drive to the USB HOST input located on the back side of the digital photo frame, the system will detect the compatible image files stored in the USB memory device. -
Page 18: Warranty Procedure
WARRANTY ≥ Energy Sistem Soyntec SA is liable for any lack of conformity which exists at the time the goods were purchased during a period of 36 months. Batteries are excluded from the 36-month warranty, having a warranty period of 12 months. - Page 19 Important: This warranty doesn’t cover any damage or loss to any data stored in the product memory, therefore Energy Sistem’s Technical Service will not assume any loss of the above mentioned information so it is recommended to make a backup of your data and to remove any data or personal info from its internal memory before you send the product, or to send it only with the original factory default values.
-
Page 20: Declaration Of Conformity
902 119 034 NIF: A53107488 We declare under our own exclusive responsibility that the product: Energy Sistem® Digital Frame Energy™ Photo Frame m10 Ultra Slim Manufacturing country: China Is in compliance with the essential norms and standards of the Directive 2004/108/EC of the European Parliament and of the Council of December 15th 2004.
