1450
ELECTRIC
PRESSURE WASHER
Instruction Manual
Model No.: AP-1450PW
Manufacturer No.: SPW704
If you have any questions or comments, please call our toll free
1-866-924-7626
PLEASE KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT.
BEFORE OPERATING THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND
RETAIN IT FOR FUTURE REFERENCE.
IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS
BELOW 41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE
TO WINTERIZE THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY.
WARRANTY REGISTRATION BY INTERNET, WWW.ACTIVEPRODUCTS.COM.
SPW704US_11/2006_REV.1
Advertisement
Table of Contents
Related Manuals for ActiveProducts 1450
Summary of Contents for ActiveProducts 1450
-
Page 1: Pressure Washer
IF YOU MUST STORE YOUR PRESSURE WASHER IN A PLACE WHERE TEMPERATURE IS BELOW 41ºF (5ºC), YOU MUST APPLY WINTERIZING PROCEDURE TO PROTECT IT. FAILURE TO WINTERIZE THE UNIT MAY PERMANENTLY DAMAGE PUMP AND VOID THE WARRANTY. WARRANTY REGISTRATION BY INTERNET, WWW.ACTIVEPRODUCTS.COM. SPW704US_11/2006_REV.1... -
Page 2: Table Of Contents
TABLE OF CONTENTS Warranty ........... Precautions . -
Page 3: Warranty
United States. This warranty gives you specific legal rights. You may have other rights, which vary by state. If you have any questions or comments, visit our web site at www.activeproducts.com or call our toll free customer service line at 1-866-924-7626... -
Page 4: Precautions
IMPORTANT PRECAUTIONS – READ FIRST! Safety Warnings Warnings Do not use with flammable liquids and toxic When using this product, basic precautions should • chemicals. always be followed: Injection Hazard: Equipment can cause serious • Read all the instructions before using the product. •... -
Page 5: Safety Features And Electrical Power Information
SAFETY FEATURES AND ELECTRICAL POWER INFORMATION The pressure washer is equipped with a stop Extension Cords device that will sense when the trigger on the gun If possible, do not use extension cords with this is released. It will open the power circuit to the motor product. -
Page 6: Parts Diagram And List
PARTS DIAGRAM AND LIST Parts List Item no. Quantity Part Name Parts No. Pressure washer JH04-001-0000 Water filter JH03-000-0001 Quick-connect coupling & inlet adaptor JH03-050-0000 Gun assembly & pressure hose JH04-090-0000 Adjustable wand JH03-091-0000 Detergent wand & bottle JH04-092-0000... - Page 7 ASSEMBLY AND OPERATING INSTRUCTIONS Water Supply (cold Water Only) Caution Do not draw non-water liquids through the unit. For • use with cold water supply only. • Never use the pressure washer to draw Water hose must be at least a 1/2” in diameter. •...
- Page 8 ASSEMBLY AND OPERATING INSTRUCTIONS – continued Fig.4 Step 4 Attach the high-pressure hose to the water outlet. Twist tightly to avoid leakage. Fig.5 Fig.6 Step 5 Step 6 Attach garden hose to water supply and turn Plug the unit into an outlet. Press “TEST”. water on.
-
Page 9: Assembly And Operating Instructions
ASSEMBLY AND OPERATING INSTRUCTIONS – continued Fig.7 Step 7 Before turning the unit ON, depress the trigger to bleed any trapped air out of the pump and hose. Fig.8 Step 8 Start the pressure washer by turning ON/OFF switch to ON. Surface Preparation Before starting any cleaning task, it is important to inspect the area for objects which could create a hazard. -
Page 10: Using The Accessories
USING THE ACCESSORIES Fig.9 Adjusting The Spray Caution The adjustable spray nozzle can be adjusted from fan to jet. The spray is adjusted from jet Jet spray adjustment is very aggressive. to fan spray by turning the nozzle as shown in Do not adjust while spraying. -
Page 11: Working With Detergent
WORKING WITH DETERGENTS Working with detergent ensures a quick soaking Fig.11 of the dirt, and allows the high-pressure water to penetrate and remove the dirt more effectively. Always spray detergent on a dry surface, do no pre-soak area. Wetting the surface first dilutes the detergent and reduces its cleaning ability. -
Page 12: Taking A Break
SHUTTING DOWN AND CLEANING UP Step 1 Step 4 Turn the switch to “OFF” (0) position and unplug cord Disconnect the garden hose from the water inlet on from outlet. the unit. Step 2 Step 5 Turn off the water supply. Disconnect the high-pressure hose from the high- pressure outlet and engage the gun safety lock. -
Page 13: Winterizing And Long-Term Storage
WINTERIZING AND LONG-TERM STORAGE Optimum Winterizing Procedure Alternative Procedure Winterizing your pressure washer will help protect If you cannot do the Optimum Winterizing pro- and prolong its life. It is strongly recommend you cedure, you can still protect your pressure washer follow the below steps using pump saver. - Page 14 USER MAINTENANCE Connections Connections on pressure washer hoses, gun and spray wand should be cleaned regularly and lubricated with non-water soluable grease. Fig.13 Fig.14 Water Filter Screen Adjustable Nozzle When the nozzle is clogged, it will cause the pump The pressure washer is equipped with a water inlet to build pressure and may cause the unit to surge.
- Page 15 TECHNICAL SPECIFICATIONS Specifications Pump Pressure: 900 PSI Max. Pressure: 1450 PSI Water Flow Rate: 1.3 GPM Power Source Requirement: 120 V, 15 A, 60 Hz Electrical cord: 35’ High-pressure hose: 20’ Current Drawn: 11 A Water supply: Cold tap water...
-
Page 16: Troubleshooting
TROUBLESHOOTING Disconnect the machine from the power source before making any repair. Symptom Cause Solution Motor will GFCI needs to be reset. Press RESET button on the GFCI. not start. On/Off switch is in the Turn switch to the “ON” ( | ) position. “OFF”... - Page 17 Do not use extension cord with this unit—plug directly into power outlet. Pressure washer not Call Customer Service. used for long periods. IF YOU ENCOUNTER ANY ADDITIONAL DIFFICULTIES NOT LISTED, VISIT OUR WEBSITE AT WWW.ACTIVEPRODUCTS.COM OR CALL CUSTOMER SERVICE AT 1-866-924-7626 FOR ASSISTANCE.
