- Page 1 Atik One User Manual Version 1.0 – March 2014...
-
Page 2: Table Of Contents
1Introduction ........................3 1.1Further information ....................3 2Pack Contents ....................... 4 3Getting to know your camera ..................5 3.1Camera Ports ......................5 3.2Mounting options ....................5 3.3Sensor ........................6 3.4Optical Window ....................6 3.5Analog to Digital Converter (ADC) ..............6 3.6Power Consumption .................... -
Page 3: 1Introduction
Introduction Congratulations on your purchase of an Atik One camera. This manual will help you get the most out of your Atik camera: please take the time to read it thoroughly, and you will be ready to discover new worlds. -
Page 4: 2Pack Contents
Pack Contents This pack includes: 1. Atik One camera 2. USB cable 3. Car lighter type power cable 4. Quick start Guide 5. CD with software and manuals 6. M42-2” adapter 7. 1.5 and 2mm Allen keys... -
Page 5: 3Getting To Know Your Camera
Getting to know your camera Camera Ports Aux Power – 2.1mm center positive socket, for external devices (Max 2A) USB hub – For connecting accessories like guiders, focusers, etc. USB port – For connecting to the computer. DC in – For powering the camera (2.1mm center positive) The USB hub is capable of powering a USB 2.0 class device, like a small guider camera, so that cables are kept to a minimum. -
Page 6: Mounting Options
There are 1/4” tripod threaded holes on each side of the camera. These can be used to mount the camera on a tripod, or as cable fixing points. Sensor The sensors available in the Atik One cameras are listed below: Black and White Atik One 6.0 SONY ICX694/5AL Atik One 9.0... -
Page 7: Power Consumption
The Atik One features a CCD chamber that has been purged with high purity Argon, to eliminate moisture from the sensor and to optimize cooling. - Page 8 Unscrew the M42 adapter Using the supplied tool, place the filter on tool as shown. Insert tool in the opening and gently On Artemis Capture wheel control, tighten the filter. It may help to catch move to filter 2 and repeat the the first thread if you unscrew first.
-
Page 9: Method 2
Method 2 On a clean table, unscrew the 4 front Place the camera sideways and screws. gently separate the wheel module. Turn down the wheel module onto the Lock the motor with the supplied table. 1.5mm Allen key. - Page 10 Unscrew the central holding screw. Take the washer off. Take the disk off. Remove the bearing by turning disk upside down. Parts should look as above.
- Page 11 Install filters on disk Make sure the lower bearing and washer are centred. Install disk. Make sure the disk clears Gently push down the disk, while the mechanical index on the lower rotating to the right. You should feel left. If needed, use a pen tip to lower the force of the spring below.
-
Page 12: 5Technical Information Summary
Rotate the wheel module back, and Tighten back the screws. attach to camera. Technical Information Summary Atik One 6.0 Atik One 9.0 Sensor Type Sony ICX694/5 Sony ICX814/5 Resolution 2750x2200 3380x2704 pixels pixels Pixel Size 4.54x4.54μm 3.69x3.69μm 16 bit 16 bit... - Page 13 The following table gives the angular resolution per pixel with certain focal distances. The formula to calculate any other focal length is: (Pixel Size (μm) / Focal Distance (mm)) * 206.3 = angular resolution (arcseconds/pixel) Atik One 9.0 Focal Length Atik One 6.0...
-
Page 14: 6Declaration Of Conformity
Declaration of Conformity EU Declaration of Conformity. This product carries the CE Mark in accordance with the related European Directive. CE Marking is the responsibility of: Perseu, SA R. Dr. Agostinho Neto, 1D 2690-576 Sta Iria da Azoia Portugal Critical Applications. This product is not designed for any “critical applications”. -
Page 15: 7Servicing
This means that Atik Cameras will repair or replace the equipment at its sole option, at no charge to the purchaser for parts or for labour, if the fault is reported within the guarantee period, provided however that Atik Cameras is able to duplicate the defect or problem at its facilities.
