Introduction

Congratulations on your selection of the Lifebreath Clean
Air Furnace. This is a very advanced unit that combines
an electric furnace with the tremendous health benefits of
year-round fresh air ventilation in every room of your
house.
With the addition of Lifebreath T.F.P. Air Cleaner (option-
al) you will have the ultimate in comfort and healthy indoor
air quality. (See back cover of this manual)
Once it is correctly installed, safety will never be an issue
with your Lifebreath furnace. No flames, fumes or flue
gases to be concerned about.
This Operating and Installation Guide will help you learn
about your Lifebreath Clean Air Furnace quickly and easi-
ly. The table of contents will show you where to find
information on every feature of this unit along with easy to
understand operating instructions. If, however, you do
encounter a question that is not covered in this Guide you
should call the Lifebreath dealer who installed your fur-
nace. Chances are that he will be able to give you a
satisfactory answer but if he is unable to do so then we
invite you to contact us directly.
Model 60ELE
"ELECTRIC" CLEAN AIR FURNACE MANUAL

General

The purpose of this manual is to act as an
installation guide only for the Lifebreath Clean Air
Furnace.
All national and local code requirements must be met
when installing a Lifebreath Clean Air Furnace. Be sure to
consult the proper authorities.

Table of Contents

Introduction ......................................................................1
Table of Contents.............................................................1
General ............................................................................1
Specifications................................................................2-4
Installation...................................................................5-10
Wiring Diagram ..............................................................11
Start-up Procedure.........................................................12
Operation .......................................................................13
Troubleshooting .............................................................14
Maintenance and Service Record ..................................15
CAF-03
0606

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLEAN AIR FURNACE 60ELE and is the answer not in the manual?

Questions and answers

Summary of Contents for Lifebreath CLEAN AIR FURNACE 60ELE

  • Page 1: Table Of Contents

    The purpose of this manual is to act as an installation guide only for the Lifebreath Clean Air Furnace. All national and local code requirements must be met when installing a Lifebreath Clean Air Furnace. Be sure to consult the proper authorities. Table of Contents Introduction ...1 Table of Contents...1...
  • Page 2: Specifications

    Specifications Core Ventilation system has patented aluminum heat recovery core for energy-efficient ventilation. Filters Washable air filters in exhaust and supply air streams of ventilation section, 1" Pleated in return plenum side. Case Prepainted galvanized steel for superior corrosion resis- tance.
  • Page 3 Specifications Core Ventilation system has patented aluminum heat recovery core for energy-efficient ventilation. Filters Washable air filters in exhaust and supply air streams of ventilation section, 1" Pleated in return plenum side. Case Prepainted galvanized steel for superior corrosion resistance. Dimensions &...
  • Page 4 Figure 1 Blower Performance Curve...
  • Page 5: Installation

    Installation The purpose of this manual is to give the contractor guide- lines for installing the Lifebreath Clean Air Furnace. All national and local codes relating to this type of equipment must be followed. Locating The Unit The Clean Air Furnace is designed to be installed vertical- ly, in a conditioned space,where the surrounding temperature does not fall below 50°F (10°C).
  • Page 6 Installation Figure 3 Option 2 - Ventilation Ports Off Right Side Remove styrofoam knockout Model 60ELE Penetrations from sheet metal screws used to fasten the ductwork to the cabinet of the unit should only be placed into the duct flange provided. This is to avoid contact and damage of the heating/air conditioning coils and internal wiring.
  • Page 7: Weatherhood Installation

    Installation Locating the Exhaust Weatherhoods The Exhaust Weatherhood should be located as fol- lows: * At least 4-6' from the supply inlet. * At least 18" above grade or expected snow accu- mulation. * At least 3' from gas meters, combustion vents, or dryer vents.
  • Page 8 Installation Pitot Tube Air Flow Balancing It is necessary to have balanced air flows in an HRV. The volume of air brought in from the outside must equal the volume of air exhausted by the unit. If the air flows are not properly balanced then: * The HRV may not operate at its maximum efficiency * A negative or positive air pressure may occur in the house...
  • Page 9 Installation For general balancing it is sufficient to move the Pitot tube around in the duct and take an average or typical reading. Repeat this procedure in the other (supply or return) duct. (Fig. B.). Determine which duct has the highest airflow (highest reading on the gauge).
  • Page 10 Installation Drain Line The ventilation portion of the Clean Air Furnace has two drain pans for removing condensation, which may occur on the heat recovery core during cold weather. See Fig. 5, for connection. Figure 5 Drain Line Diagram DRAIN SPOUT KNOCKOUT 2"...
  • Page 11: Wiring Diagram

    Wiring Diagram R - W = Heat R - G = Fan Only (optional dehumidistat) G - R - Y - C = A/C Electrical The Clean Air Furnace operates at 240V, single phase and requires a maximum 100amp fused circuit or breaker. 240/1 240VAC THR1...
  • Page 12: Start-Up Procedure

    Start Up Procedure In order for any appliance to work properly it must be set up and tested by a knowledgeable technician. The following conditions must be met prior to start-up 1. Blower wheel rotates freely inside its housing. 2. Wiring connections are tight. 3.
  • Page 13: Operation

    Operation Heating/Cooling When the room thermostat calls for heat, the furnace blower switches on to heating speed and will start circu- lating air across the coil, which picks up heat and delivers it to the rest of your home. Once the thermostat's temperature is reached the ele- ments will shut off, and the blower will return to its pre-set speed or off.
  • Page 14: Troubleshooting

    Troubleshooting Lack of heat 1. Check that the room thermostat is set to the desired temperature. 2. Ensure there is power to the unit. 3. Verify that the airflow in and out of the system matches designed specs. If airflow is low, check for blockage in the filter or some other obstruction.
  • Page 15: Maintenance And Service Record

    Maintenance and Service Record Date: Particulars...
