Verilux HappyLite Mini Plus VT01 User Manual
Sunshine supplement light system
Hide thumbs
Also See for HappyLite Mini Plus VT01:
- Product manual (6 pages) ,
- Owner's manual (10 pages)
Related Manuals for Verilux HappyLite Mini Plus VT01
Summary of Contents for Verilux HappyLite Mini Plus VT01
- Page 1 VT01 VT01_MAN_Rev5v3.indd 1 VT01_MAN_Rev5v3.indd 1 4/22/09 2:53 PM 4/22/09 2:53 PM Job#: 0.0612 Title: VT01 Manual Date: 04/22/09 Version: VT01-MAN-Rev5v3...
- Page 2 To request a free copy of our catalog, call our toll-free number 1-888-544-4865. You may also visit us on the web at www.Verilux.com to learn more about all ® our quality Verilux products.
-
Page 3: Table Of Contents
Contents Warnings and Precautions ......4 Features ......... . . 5 Set-up Instructions . -
Page 4: Warnings And Precautions
Warnings and Precautions • Please read these instructions before using this lamp. • For indoor use only. • Do not place near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. • Do not block any ventilation openings. •... -
Page 5: Features
® • Use only the type of bulb and maximum wattage indicated by Verilux • Never cover the lamp when it is in operation. • To prevent risk of shock or personal injury when cleaning lamp, make sure you have turned off and unplugged the lamp, and allow suffi... -
Page 6: Package Contents
Package Contents Unpacking Lamp Diffuser Bulb VT01_MAN_Rev5v3.indd 6 VT01_MAN_Rev5v3.indd 6 4/22/09 2:53 PM 4/22/09 2:53 PM... -
Page 7: Set-Up Instructions
Set-up Instructions Bulb Installation To install the bulb, insert bulb into lamp by fi rmly holding bulb base and pushing down and rotating slightly in a clockwise direction to seat properly. VT01_MAN_Rev5v3.indd 7 VT01_MAN_Rev5v3.indd 7 4/22/09 2:53 PM 4/22/09 2:53 PM Job#: 0.0612 Title: VT01 Manual Date: 04/22/09... -
Page 8: Diffuser Installation
Set-up Instructions continued Diffuser Installation 1. Attach the diffuser to the lamp body by first inserting the tab located at the bottom of the diffuser (A) into the opening of the lamp base (B). Top Track 2. Insert one diffuser corner at a time into the side track and gently down into place into the bottom track. -
Page 9: Selecting A Location
Tab A Selecting a Location ® ® • Place your Verilux HappyLite Mini Plus Sunshine Supplement Light System on a table or other flat surface. • For best performance, place the lamp within 18 inches of you. -
Page 10: Operation
Operation Instructions for Use Light therapy consists of sitting close to the HappyLite ® Mini with your eyes open. While staying oriented toward the light, feel free to engage in other activities such as reading, writing, hobbies and crafts, sewing, needlepoint, applying makeup, painting, or working at your computer or desk. -
Page 11: Recommended Usage
Operation continued Recommended Usage Hours Hours Hours 5-12” 12-18” 18”+ From From From Light Light Light Recommended exposure time is a function of output and distance Individual results may vary *2,500 LUX at 5” Optimum time depends upon how your body uniquely responds to light. Typical ®... -
Page 12: Bulb Removal And Replacement
Bulb Removal and Replacement ® ® Your HappyLite uses a bulb manufactured only by Verilux . To order a ® replacement bulb, please call Verilux , toll-free, at 1-800-454-4408. To Replace the Bulb: 1. Unplug the lamp from power outlet. -
Page 13: Troubleshooting
Troubleshooting ® Before requesting service on your Verilux lamp, please read the following: • Make sure all power connectors, cords, and plugs are inserted fully and securely. • Be sure the bulb is securely seated in the socket. (See pages 6 and 7) •... -
Page 14: Disclaimer
Operating Temperature: 15°C to 35°C; 56°F to 95°F Storage Temperature: 0°C to 40°C; 32°F to 104°F Relative Humidity: 5% to 95% non-condensing Bulb ® Replacement bulb: 26-Watt 10,000-hour bulb (replace with Verilux brand only, Model number CFS26GU24VLX) Power Input Power: AC 120V~60Hz UL Listed VT01_MAN_Rev5v3.indd 14... -
Page 15: Warranty
During the limited warranty period, Verilux, Inc. will, at its option, repair or replace defective parts of this product, at no charge to the customer, subject to the following limitations. This limited warranty does not include any postage, freight, insurance or delivery fees. - Page 16 Representatives are available 8 a.m. – 10 p.m. M – S, 9 a.m. – 8 p.m. Sunday EST 340 Mad River Park, Waitsfi eld, VT 05673 Printed in China for: Verilux, Inc. © Copyright 2009 Verilux, Inc. All rights reserved. VT01-MAN-Rev5 VT01_MAN_Rev5v3.indd 16 VT01_MAN_Rev5v3.indd 16...
